Onkyo SKS-22X Manual de usuario

Speaker System

SKS-22X

SKC-22X, SKR-22X

Instruction Manual

Thank you for purchasing an Onkyo

speaker system. Please read this manual

thoroughly before using your new

speakers. Following the instructions in this

manual will enable you to obtain optimum

performance and listening enjoyment from

your speaker system.

Please retain this manual for future

reference.

Contents

Getting Started

Package Contents................................ 2

Getting to Know the Speakers ............. 2

Installing & Using

Using Rubber Stoppers for more

Stable Platform ................................ 3

Wall Mounting ...................................... 3

Connecting the Speakers .................... 4

Appendix

Operating Precautions ......................... 5

Speaker Care....................................... 5

Use with a TV Set or Computer ........... 5

Specifications....................................... 6

■SKC-22X

■SKR-22X

* In catalogs and on packaging, the letter at the end

of the product name indicates the color.

Specifications and operations are the same

regardless of color.

Package Contents

Speaker SKC-22X ×1

Speaker SKR-22X ×2

Speaker cable

4 thick rubber stoppers for SKC-22X

8 thin rubber stoppers for SKR-22X

• The speaker cabinets are sensitive to

extreme temperatures and humidity, do not

put them in locations subject to direct sun-

light or in humid places, such as near an

air conditioner, humidifier, bathroom, or

kitchen.

• Do not put water or other liquids close to

the speakers. If liquid is spilled over the

speakers, the drive units may be damaged.

• As explained in this manual, mount the

speakers on a wall, or on the optional

stands/brackets, otherwise, they may fall,

causing personal injury or damage to the

speakers.

SKR-22X:

8 m (26' 3") ×2

(Green) (Gray) (Blue)

SKC-22X:

3 m (9' 10-1/8")

Getting to Know the Speakers

Speaker terminals

Keyhole slots

Speaker terminals

We recommend using the supplied rubber

stoppers to achieve the best possible sound

from your speakers. The rubber stoppers pre-

vent the speakers from moving, providing a

more stable platform. Use thick rubber stop-

pers for the SKC-22X, and thin rubber stop-

pers for the SKR-22X

The speakers can easily be wall mounted by

using the keyhole slots.

■Mounting the SKC-22X

To mount the SKC-22X speaker, use the two

keyhole slots shown to hang the speaker on

two screws that are securely screwed into the

wall.

The distance between the keyhole slots is

183 mm (7-3/16").

■Mounting the SKR-22X

To mount the SKR-22X speakers, use the key-

hole slot shown to hang each speaker on screw

that is securely screwed into the wall.

Caution:

A mounting screw’s ability to support a speaker

depends on how well it’s anchored to the wall.

If you have hollow walls, screw each mounting

screw into a stud. If there are no studs, or the

walls are solid, use suitable wall anchors.

Use screws with a head diameter of 9 mm

(5/16") or less and a shank diameter of 4 mm

(1/8") or less. With hollow walls, use a cable/

pipe detector to check for any power cables or

water pipes before making any holes.

Leave a gap of between 5 mm (3/16") and

10 mm (7/16") between the wall and the base

of the screw head, as shown.

(We recommend that you consult a home

installation professional.)

Using Rubber Stoppers for

more Stable Platform

Wall Mounting

Thin rubber stoppers

Bottom of the SKR-22X

Thick rubber stoppers

Bottom of

the SKC-22X 12 mm (1/2")

50 mm

(1-15/16")

Wall

Keyhole slot for

wall mounting

5 to 10 mm

(3/16" to 7/16")

183 mm (7-3/16")

Thick rubber

stoppers

Keyhole

slot for wall

mounting

Wall

Thick rubber stoppers

SKR-22X

5 to 10 mm

(3/16" to 7/16")

Read the following before connecting your

speakers:

• Turn off your amp/receiver before making

any connections.

• The nominal impedance of these speakers is

6 Ω. Use only an amp/receiver that supports

this impedance.

• Pay close attention to speaker wiring polar-

ity. Connect positive (+) terminals to only

positive (+) terminals, and negative (–) ter-

minals to only negative (–) terminals. If the

speakers are wired incorrectly, the sound

will be out of phase and will sound unnatu-

ral.

• Be careful not to short

the positive and nega-

tive wires. Doing so

may damage your amp/

receiver.

■Connecting the Speaker Cables

■SKC-22X

■SKR-22X

The left and right speakers are identical, so you

can use either one as the left or right speaker

and the sound quality will not be affected.

Note:

• Connect the speakers to the appropriate

speaker terminals on your amp or receiver.

See your amp or receiver’s instruction man-

ual for details.

Connecting the Speakers

1Strip the insulation

from the ends of

the speaker cables,

and twist the bare

wires tightly.

2Use the cables to connect each

speaker’s input terminals to the

corresponding speaker output ter-

minals on your amp/receiver.

To make a connection,

while pressing the ter-

minal lever, insert the

wire into the hole, and

then release the lever.

Make sure that the ter-

minals are gripping the bare wires, not

the insulation.

AC INLET

CAUTION :

SPEAKER IMPEDANCE

6 ~ 16Ω/SPEAKER

Green line

HTX-22HDX

AC INLET

CAUTION :

SPEAKER IMPEDANCE

6 ~ 16Ω/SPEAKER

HTX-22HDX

Gray line

Surround right speaker Surround left speaker

Blue line

The speakers can handle the specified input

power when used for normal music reproduc-

tion. If any of the following signals are fed to

them, even if the input power is within the

specified rating, excessive current may flow in

the speaker coils, causing burning or wire

breakage:

1. Interstation noise from an untuned FM

radio.

2. Sound from fast-forwarding a cassette tape.

3. High-pitched sounds generated by an oscil-

lator, electronic musical instrument, and so

on.

4. Amplifier oscillation.

5. Special test tones from audio test CDs and

so on.

6. Thumps and clicks caused by connecting or

disconnecting audio cables (Always turn

off your amplifier before connecting or dis-

connecting cables.)

7. Microphone feedback.

• The speakers contain strong magnets, so do

not put magnetic or iron objects such as

screwdrivers close to them. If you do, the

object may be attached to the magnets, caus-

ing personal injury or damage to the dia-

phragm.

Wipe the cabinet occasionally with a dry silica

or soft cloth. For heavier dirt, after dampening

a soft cloth in a weak solution of mild deter-

gent and water and wringing it out dry, wipe

off the dirt. Then, dry immediately with a

clean cloth. Do not use rough material, thin-

ners, alcohol or other chemical solvents or

cloths since these could damage the finish,

remove the panel lettering, or cause discolor-

ation. If you are using a chemical cloth, always

follow the instructions that come with the

cloth. For dust accumulated on grilles, use a

vacuum cleaner or brush it off.

TVs and computer monitors are magnetically

sensitive devices and as such are likely to suf-

fer discoloration or picture distortion when

conventional speakers are placed nearby. To

prevent this, the SKC-22X and SKR-22X

speaker features internal magnetic shielding.

In some situations, however, discoloration may

still be an issue, in which case you should turn

off your TV or monitor, wait 15 to 30 minutes,

and then turn it back on again. This normally

activates the degaussing function, which neu-

tralizes the magnetic field, thereby removing

any discoloration effects. If discoloration prob-

lems persist, try moving the speakers away

from your TV or monitor. Note that discolor-

ation can also be caused by a magnet or

demagnetizing tool that’s too close to your TV

or monitor.

Operating Precautions

Speaker Care

Use with a TV Set or Computer

■SKC-22X

Type: Full Range Bass-reflex

Impedance: 6 Ω

Maximum input power: 40 W

Sensitivity:

84 dB/W/m

Frequency response: 70 Hz - 20 kHz

Cabinet capacity: 1.4 L (0.05 cubic feet)

Drivers unit: 8 cm (3-1/4") Cone

Terminal: Spring type color coded

Keyhole slot: 2

Grille: Fixed

Dimensions:

230 (W)

102 (H)

113 (D) mm

(9-1/16"

4-7/16")

(incl. grille and projection)

Weight: 0.9 kg (2.0 lbs.)

Others: Magnetic shielding

■SKR-22X

Type: Full Range Bass-reflex

Impedance: 6 Ω

Maximum input power: 40 W

Sensitivity:

80 dB/W/m

Frequency response: 70 Hz - 20 kHz

Cabinet capacity: 1.0 L (0.036 cubic feet)

Drivers unit: 8 cm (3-1/4") Cone

Terminal: Spring type color coded

Keyhole slot: 1

Grille: Fixed

Dimensions:

101 (W)

161 (H)

111 (D) mm

(4"

6-5/16"

4-3/8")

(incl. grille and projection)

Weight: 0.8 kg (1.76 lbs.)

Others: Magnetic shielding

Specifications and appearance are subject to change for improvement without prior notice.

Specifications

Memo

SN 29400385

I1003-1

Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN

Tel: 072-831-8023 Fax: 072-831-8163

ONKYO U.S.A. CORPORATION

18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.

Tel: 800-229-1687, 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/

ONKYO EUROPE ELECTRONICS GmbH

Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY

Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/

ONKYO EUROPE ELECTRONICS GmbH (UK BRANCH)

The Coach House 81A High Street, Marlow, Buckinghamshire, SL7 1AB, UK

Tel: +44-(0)1628-473-350 Fax: +44(0)-1628-401-700

ONKYO CHINA LIMITED

Unit 1&12, 9/F, Ever Gain Plaza, Tower 1, 88, Container Port Road, Kwai Chung,

N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039

http://www.ch.onkyo.com/

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de altavoces de Onkyo

Onkyo

Onkyo LS7200 Manual de usuario

Onkyo

Onkyo SKS-HT200 Manual de usuario

Onkyo

Onkyo HTP-370 Manual de usuario

Onkyo

Onkyo HTP-2 Manual de usuario

Onkyo

Onkyo HTP-L50 Manual de usuario

Onkyo

Onkyo HTX-22HD Manual de usuario

Onkyo

Onkyo D-035 Manual de usuario

Onkyo

Onkyo HTP-120 Manual de usuario

Onkyo

Onkyo SKF-201 Manual de usuario

Onkyo

Onkyo D-30PC5X Manual de usuario

Onkyo

Onkyo SKF-4700 Manual de usuario

Onkyo

Onkyo D-309H Manual de usuario

Onkyo

Onkyo HTP-980 Manual de usuario

Onkyo

Onkyo D-105F Manual de usuario

Onkyo

Onkyo PCS-207 Manual de usuario

Onkyo

Onkyo SKF-4800 Manual de usuario

Onkyo

Onkyo SKF-3600 Manual de usuario

Onkyo

Onkyo D-325 Manual de usuario

Onkyo

Onkyo D-N3XA Manual de usuario

Onkyo

Onkyo HR-l0 Manual de usuario

Onkyo

Onkyo SKW-501 Manual de usuario

Onkyo

Onkyo EnvisionCinema LS-T10 Manual de usuario

Onkyo

Onkyo LS3200 Manual de usuario

Onkyo

Onkyo SKS-4700 Manual de usuario

Manuales populares de Sistema de altavoces de otras marcas

JVC

JVC CA-MXK5R Manual de usuario

LG NB4532B Manual de usuario

JVC

JVC CA-FSH100 Manual de usuario

5Core

5Core Pro Series Manual de usuario

EAW

EAW MQV1394e Manual de usuario

Lynx

Lynx GXR-LA10A Manual de usuario

iLive

iLive ITB066B Manual de usuario

RDX

RDX QuickStation 4 Manual de usuario

Electro-Voice

Electro-Voice S-122 Manual de usuario

Sven

Sven SPS-619 GOLD Manual de usuario

Pioneer

Pioneer CS-7070 Manual de usuario

EAW

EAW UB82e Manual de usuario

Sondpex

Sondpex Active Speaker System and Digital Music... Manual de usuario

JVC

JVC NX-PN7 Manual de usuario

Marshall Amplification

Marshall Amplification AR-DM61-BT Manual de usuario

Yamaha

Yamaha NX-A01 - Speaker Sys Manual de usuario

SE Audiotechnik

SE Audiotechnik I-LINE Manual de usuario

Gemini

Gemini WRX-843 Series Manual de usuario
