Omron S8VS-01524 Manual de usuario

S8V POWER SUPPLIES

High capacity in a compact format

» Long life – switch mode power supplies

» performance and reliability

» Complete single and 3 - phase ranges

All the power to suit your needs...

Benefits S8VS

All the power to run your application

• Full range from 0.65 A up to 20 A in only 6 models

Ideal for global use

• Wide input range 100 – 240VAC

Global availability

• We are present on all continents/in all countries

Suited for marine applications

• Lloyd’s Register certified

S8VS single phase power supplies

Compact series

The S8VS is our most compact single-phase power supply range.

The dimensions of these compact power supplies mean that less

panel space and depth are required. The range starts at 0.65A

and goes up to 20A at 24VDC. The 20A model is the latest

addition to our successful S8VS series. This model is able to

supply a short-duration 30A peak output current. The S8VS range

offers reliability with compactness and combines high capacity

with natural (fan-less) cooling. All models are designed for easy

click-on DIN-rail mounting and give full power in a wide ambient

temperature range. The terminal locations are situated at the

upper and lower side of the power supply, so that input- and

output-terminals are separated.

Our S8V series of industrial compact power supplies

offers the power you need for your application.

Available with single-phase and three-phase input

voltages, the single-phase S8VS range goes up to 20A

and the three-phase S8VT range extends to 40A.

The S8V series has many practical features that make

these power supplies safe and easy to install.

240 W / 10 A120 W / 5 A60 W / 2,5 A30 W / 1,3 A15 W / 0,65 A

The S8VT is our series of compact three-phase input power

supplies with a wide input range from 400 to 500VAC. The

S8VT offers one of the best power-to-footprint ratios on the

market. The range comprises four models available with power

ratings of 5, 10, 20 or 40A at 24VDC. All models are fuse

protected to secure protection of the power supply and your

DC application.

S8VT 3-phase power supplies

Performance in robust housing

Benefits S8VT

All the power to run your application & reduce panel space

• Full range from 5A up to 40A in only 4 models with best

power-to-footprint ratio

Prevent imbalance in main supply

• Wide 3-phases input range

To increase output voltage or power

• Parallel or serial connections possible

The S8VT range is designed for industrial use and therefore

features DIN-rail mounting, a strong metal case and gives full

power without the need for additional ventilation.

Furthermore, all models are equipped with double connection

for the DC supply, making wiring easier. On top of this you can

use the S8VT as well as a single-phase DC/DC converter with

an input voltage up to 810 VDC. The series conforms to

industrial standards around the world.

120 W / 5 A

240 W / 10 A 480 W / 20 A

960 W / 40 A

480 W / 20 A

'#-,

(#*

)#,

(, *' -' ()' )+' +/' 0-'

J/MJj`e^c\g_Xj\ J/MK*$g_Xj\

)+M;:

'#-,

(#*

)#,

()'

)+'

+/'

0-'

J/MJj`e^c\g_Xj\

J/MK*$g_Xj\

)+M;:

J/MJj`e^c\g_Xj\

J/MK*$g_Xj\

Benefits S8VT

All the power to run your application & reduce panel space

• Full range from 5A up to 40A in only 4 models with best

power-to-footprint ratio

Prevent imbalance in main supply

• Wide 3-phases input range

To increase output voltage or power

• Parallel or serial connections possible

Practical features that make

the S8V safe and easy to use

Wide voltage input range

Ideal for global use.

DIN-rail mounting

Sturdy, quick and

safe mounting.

Finger protection covers

Prevents accidental contact

with active terminals.

Built-in main supply fuses

No additional external fuses

needed.

Double output terminals

Maximum convenience

for easy wiring.

Output voltage control

• LED indication output ON

• Output adjustable <-10%

to +15%>

Model Description

S8VS Single Phase Power Supplies

S8VS-01524 Power supply, plastic case, 22.5mm wide DIN rail or direct panel mounting,100/240VAC supply, 15W 24VDC 0.65A output

S8VS-03024 Power supply, plastic case, 22.5mm wide DIN rail or direct panel mounting,100/240VAC supply, 30W 24VDC 1.3A output

S8VS-06024 Power supply, 60W, 100-240VAC input, 24VDC 2.5A output, DIN rail mounting

S8VS-12024 Power supply, 120W, 100-240VAC input, 24VDC 5A output, DIN rail mounting

S8VS-24024 Power supply, 240W, 100-240VAC input, 24VDC 10A output, DIN rail mounting

S8VS-48024 Power supply, 480W, 100-240VAC input, 24VDC 20A output, DIN rail mounting

S8VT Three Phase Power Supplies

S8VT-F12024E Power supply, 120W, 320-480VAC 3-phase input, 24VDC 5A output, DIN rail mounting

S8VT-F24024E Power supply, 240W, 320-480VAC 3-phase input, 24VDC 10A output, DIN rail mounting

S8VT-F48024E Power supply, 480W, 320-480VAC 3-phase input, 24VDC 20A output, DIN rail mounting

S8VT-F96024E Power supply, 960W, 320-500VAC 3-phase input, 24VDC 40A output, DIN rail mounting

... Find related datasheets

www.industrial.omron.eu/s8v

'#-,

(#*

)#,

(, *' -' ()' )+' +/' 0-'

J/MJj`e^c\g_Xj\ J/MK*$g_Xj\

)+M;:

'#-,

(#*

)#,

()'

)+'

+/'

0-'

J/MJj`e^c\g_Xj\

J/MK*$g_Xj\

)+M;:

J/MJj`e^c\g_Xj\

J/MK*$g_Xj\

480 W / 20 A

KPP_S8V_EN_INT01
