214 Solid State Relays G3@-VD G3F/G3FD
Solid State Relays G3@-VD
G3F/G3FD
Refer to Warranty and Application Considerations (page 1), Safety
Precautions (page 4), and Technical and Safety Information (page 6).
International Standards for G3F Series,
Same Profile as MY Power Relays
• Shape-compatible with mechanical relays.
• Certified by UL, CSA, and VDE (model numbers with a suffix of
“-VD”).
• Socket type, same size as MY Power Relays.
• Operation indicator provided to confirm input (model numbers
with “N” before the suffix).
Model Number Structure
■Model Number Legend
1. Basic Model Name
G3F: Solid State Relay
2. Rated Load Power Supply Voltage
2: 200 VAC
3. Rated Load Current
02: 2 A
03: 3 A
4. Terminal Type
S: Plug-in terminals
5. Zero Cross Function
Blank: Equipped with zero cross functions
L: Not equipped with zero cross function
6. Operation Indicator
Blank: Not equipped with operation indicator
N: Equipped with operation indicator
7. Certification
VD: Certified by UL, CSA, and VDE
1. Basic Model Name
G3F: Solid State Relay
2. Load Power Supply Type
D: DC
3. Rated Load Power Supply Voltage
X: 50 VDC
1: 100 VDC
4. Rated Load Current
02: 2 A
03: 3 A
5. Terminal Type
S: Plug-in terminals
6. Operation Indicator
Blank: Not equipped with operation indicator
N: Equipped with operation indicator
7. Certification
VD: Certified by UL, CSA, and VDE
1234 56 7
G3F-@@@@@-@
1234 56 7
G3FD-@@@@-@
Solid State Relays G3@-VD G3F/G3FD 215
Ordering Information
■List of Models
Note: 1. Product is labelled “250 VAC”.
2. Product is labelled “50 VDC”.
3. When ordering, specify the rated input voltage.
■Accessories (Order Separately)
Connecting Sockets
Refer to page 297 for details.
Specifications
■Ratings (at an Ambient Temperature of 25°C)
Input
Isolation Zero cross
function Indicator Rated output load Rated input voltage Model
Photocoupler Yes Yes 3 A at 100 to 240 VAC (See note 1.) 5 to 24 VDC G3F-203SN-VD
2 A at 100 to 240 VAC (See note 1.) 100/110 VAC G3F-202SN-VD
200/220 VAC
Phototriac coupler No 3 A at 100 to 240 VAC (See note 1.) 5 VDC G3F-203SLN-VD
12 VDC
24 VDC
Photocoupler 3 A at 4 to 48 VDC (See note 2.) 5 to 24 VDC G3FD-X03SN-VD
2 A at 5 to 110 VDC 100/110 VAC G3FD-102SN-VD
200/220 VAC
5 to 24 VDC
Photocoupler Yes No 3 A at 100 to 240 VAC (See note 1.) 4 to 24 VDC G3F-203S-VD
Phototriac coupler No 5 VDC G3F-203SL-VD
12 VDC
24 VDC
Photocoupler 3 A at 4 to 48 VDC (See note 2.) 4 to 24 VDC G3FD-X03S-VD
2 A at 5 to 110 VDC G3FD-102S-VD
Item PYF08A-E PY08 PY08-02 PY08QN(2)
Connecting Front connecting Back connecting
Mounting method/
Terminal type Track mounted/
screw terminals Solder terminals PCB terminals Wrapping terminals
Hold-down clip PYC-A1 PYC-P
Model Rated voltage Operating voltage Impedance Voltage level
Must operate voltage Must release voltage
G3F-203SN-VD 5 to 24 VDC 4 to 28 VDC 15 mA max. (See note.) 4 VDC max. 1 VDC min.
G3F-202SN-VD 100/110 VAC 75 to 125 VAC 41 kΩ±20% 75 VAC max. 20 VAC min.
200/220 VAC 150 to 250 VAC 72 kΩ±20% 150 VAC max. 40 VAC min.
216 Solid State Relays G3@-VD G3F/G3FD
Note: Constant-current input circuit.
Output
G3F-203SLN-VD 5 VDC 4 to 6 VDC 390 Ω±20% 4 VDC max. 1 VDC min.
12 VDC 9.6 to 14.4 VDC 900 Ω±20% 9.6 VDC max.
24 VDC 19.2 to 28.8 VDC 2 kΩ±20% 19.2 VDC max.
G3FD-X03SN-VD 5 to 24 VDC 4 to 28 VDC 1.5 kΩ+20%/–10% 4 VDC max.
G3FD-102SN-VD 5 to 24 VDC 4 to 28 VDC 1.5 kΩ+20%/–10% 4 VDC max.
100/110 VAC 75 to 125 VAC 41 kΩ±20% 75 VAC max. 20 VAC min.
200/220 VAC 150 to 250 VAC 72 kΩ±20% 150 VAC max. 40 VAC min.
G3F-203S-VD 4 to 24 VDC 3 to 28 VDC 15 mA max. (See note.) 3 VDC max. 1 VDC min.
G3F-203SL-VD 5 VDC 4 to 6 VDC 390 Ω±20% 4 VDC max.
12 VDC 9.6 to 14.4 VDC 900 Ω±20% 9.6 VDC max.
24 VDC 19.2 to 28.8 VDC 2 kΩ±20% 19.2 VDC max.
G3FD-X03S-VD 4 to 24 VDC 3 to 28 VDC 1.5 kΩ+20%/–10% 3 VDC max.
G3FD-102S-VD
Model Rated voltage Operating voltage Impedance Voltage level
Must operate voltage Must release voltage
Model Rated load
voltage Applicable load
Load voltage range Load current Inrush current
G3F-203SN-VD
G3F-203SLN-VD
G3F-203S-VD
G3F-203SL-VD
100 to 240 VAC 75 to 264 VAC 0.1 to 3 A 45 A (60 Hz, 1 cycle)
G3F-203SN-VD 100 to 240 VAC 75 to 264 VAC 0.1 to 2 A 45 A (60 Hz, 1 cycle)
G3FD-X03SN-VD
G3FD-X03S-VD 4 to 48 VDC 3 to 52.8 VDC 0.1 to 3 A 18 A (10 ms)
G3FD-102SN-VD
G3FD-102S-VD 5 to 110 VDC 3 to 125 VDC 0.1 to 2 A 10 A (10 ms)
Solid State Relays G3@-VD G3F/G3FD 217
■Characteristics
Item G3F-203SN-VD
G3F-202SN-VD
G3F-203S-VD
G3F-203SLN-VD
G3F-203SL-VD G3FD-X03SN-VD
G3FD-X03S-VD G3FD-102SN-VD G3FD-102S-VD
Operate time 1/2 of load power
source cycle + 1 ms
max. (DC input)
3/2 of load power
source cycle + 1 ms
max. (AC input)
1 ms max. 0.5 ms max. 0.5 ms max. (DC in-
put)
20 ms max. (AC input)
0.5 ms max.
Release time 1/2 of load power
source cycle + 1 ms
max. (DC input)
3/2 of load power
source cycle + 1 ms
max. (AC input)
1/2 of load power
sourcecycle+1ms
max.
2 ms max. 2.5 ms max. (DC in-
put)
20 ms max. (AC input)
2.5 ms max.
Output ON voltage drop 1.6 V (RMS) max. 1.5 V max.
Leakage current 5 mA max. (at
100 VAC)
10 mA max. (at
200 VAC)
2.5 mA max. (at
100 VAC)
5 mA max. (at
200 VAC)
5 mA max. (at
50 VDC) 0.1 mA max. (at
100 VDC) 0.1 mA max. (at
100 VDC)
Insulation resistance 100 MΩmin. (at 500 VDC)
Dielectric strength 2,000 VAC, 50/60 Hz for 1 min 1,500 VAC, 50/60 Hz for 1 min
Vibration resistance Destruction: 10 to 55 to 10 Hz, 0.75-mm single amplitude
Shock resistance Destruction: 1,000 m/s2
Ambient temperature Operating: –30°C to 80°C (with no icing or condensation)
Storage: –30°C to 100°C (with no icing or condensation)
Ambient humidity Operating: 45% to 85%
Certified standards G3F: UL508, CSA C22.2 No. 14, EN60947-4-3
G3FD: UL508, CSA C22.2 No. 14, EN60950
Weight Approx. 50 g
218 Solid State Relays G3@-VD G3F/G3FD
Engineering Data
Load Current vs. Ambient Temperature Characteristics
One Cycle Surge Current: Non-repetitive
Dimensions
Note: All units are in millimeters unless otherwise indicated.
Ambient temperature (°C) Ambient temperature (°C)
Load current (A)
Load current (A)
G3F-203SN-VD/203S-VD/203SLN-VD/
203SL-VD
G3FD-X03SN-VD/X03S-VD
G3F-202SN-VD
G3FD-102SN-VD/102S-VD
2010
Non-repetitive (Keep the inrush current to half the rated value if it occurs repetitively.)
G3FD-X03SN-VD/X03S-VD G3FD-102SN-VD/102S-VD
Inrush current (A. Peak)
Ener
g
ized time (ms)
Inrush current (A. Peak)
Ener
g
ized time (ms)
Inrush current (A. Peak)
Ener
g
ized time (ms)
G3F-203SN-VD/203S-VD/202SN-VD/
203SLN-VD/203SL-VD
1
5
9
13
4
8(+)
12(−)
14
−+
−+
(+)
(−)
( )
Load
Input
Load
Input voltage
28 max.
21.5 max. 36.5 max.
42.5 max.
Terminal Arrangement/
Internal Connections
Load power
supply
Note: The plus and minus symbols shown
in parentheses are for DC loads.
In the interest of product improvement, specifications are subject to change without notice.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
Cat. No. K055-E1-05
Solid State Relays G3@-VD G3F/G3FD 219
Safety Precautions
■Precautions for Correct Use
Please observe the following precautions to prevent failure to
operate, malfunction, or undesirable effect on product performance.
Connection
The SSR for DC switching use can connect to a load regardless of
the polarity of the positive and negative output terminals.
Close Mounting of Multiple Relays
If multiple Relays are mounted side by side, be aware that the outer
wall of each SSR works as a heat sink.
The SSR casing serves to dissipate heat. Install the Relays so that
they are adequately ventilated. If poor ventilation is unavoidable,
reduce the load current by half.
Protective Terminal
When using for AC inductive loads, connect the load terminals of the
SSR to an inrush absorber (varistor).
