E-13E6F-A

E6F-A

Absolute Rotary Encoder

E6F-A

Rugged construction

providing high-precision

timing detection for automatic

machines operation

• Stronger shaft and higher durability (120 N in radial

direction and 50 N in thrust direction) than previous

E6F Encoders.

• Drip-proof construction meets IP64F standards

• High resolution models (1024 pulses max. per revo-

lution)

• Faster response for high-speed control applications

(grey code: 20 kHz).

• Shock resistance strengthened by metal

disk. Patent

Ordering Information

Sensors

Note: 1 .For order placement add the resolution (pulses per revolution) between the part number. For example, E6F-AG5B 256 P/R.

2 .E6F-AB5C-C applied for rotary positioner connection.

Accessories (Order Separately)

Supply voltage Output form Output code Resolution

(pulses/revolution) Connection method Model

12 to 24 VDC

NPN open collector BCD 360

Pre-wired E6F-AB5C

Connector type E6F-AB5C-C

PNP open collector Pre-wired E6F-AB5B

Gray code 256, 360, 720, 1,024 Pre-wired E6F-AG5B

Item Model Remarks

Coupling

E69-C10B

Supplied with pre-wired models

E69-C610B Different end diameter

E69-C10M Metal construction

Mounting Bracket E69-2 Supplied with the product (set of 3)

Extension Cable E69-DF5

Standard stock models: 5 m, 10 m.

In addition to this 15 m, 20 m and 98 m

are available.

F502-EN2-04.book Seite 13 Dienstag, 26. Juli 2005 5:48 17

E-14 Rotary Encoders

Dimensions (Unit: mm)

Sensors

E6F-AB5C

E6F-AG5B

E6F-AB5B

E69-C10B is attached.

E6F-AB5C-C

E69-C10B is sold separately.

2,000

60 dia.

54 dia.

14 max.

(see note)

42.5

Note:

Oil-proof PVC-shielded cable of

6 dia.12 cores conductor

cross-sectional area: 0.2mm2;

insulation diameter: 1.1mm

Standard length: 2m

48 dia. 15 3

(85)

Four, M3 holes Depth: 6

1max.

40 dia.

-0.025

10 dia. 0

-0.015

(85)

60 dia.

54 dia.

14 max.

16.9 dia.

(see note 2)

(see note 1)

42.5

2,000

Note:

1. Oil-proof PVC-shielded cable of

6 dia.12 cores conductor

cross-sectional area: 0.2mm2;

insulation diameter: 1.1mm

Standard length: 2m

2.Rotary positioner (H8PR),

and Cam positioner (H8PS) connector

by Hirose electric (RP13A-12PD-13SC)

10 dia. 0

-0.015

40 dia.

-0.025

15 3

20 5

48 dia.

Four, M3 holes Depth: 6

1 max.

In the interest of product improvement, specifications are subject to change without notice.

ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.

To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.

Cat. No. E283-E2-02-X
