OmniPrint DIRECT HEAT Manual de usuario

DIRECT HEAT

Official User Manual

2021 Edition

Vacumm Platen

What’s Included .............................................................................3

Direct Heat Vacuum Platen Specifications .................................4

Direct Heat Vacuum Platen Safety Instruction ...........................4

Direct Heat Vacuum Platen Safety Marks ...................................5

Controller Thermostat Functions ................................................5

Direct Heat Vacuum Platen Installation ......................................6

Direct Heat Vacuum Platen Operation ........................................7

Anatomy of a Direct Heat Vacuum Platen ...................................8

Table of Contents

[1] Direct Heat Vacuum Platen

with controller thermostat

[1] Power Cord

[2] Hoop & loop cable ties [2] Pedal

What’s Included In The Direct Heat

Vacuum Platen Package:

Direct Heat Vacuum Platen Specifications

Direct Heat Vacuum Platen Safety Instruction

Size (Unit: mm)

457.2 (L) X 336.55 (W) X 96.266 (H)

Weight:

4.7173 KG

1 Controller Thermostat

1 Power Cord

Read this manual carefully before using this equipment with

your printer.

• Following instructions are to prevent damage to the equipment

or your health.

• Do not use the heating system on flammable or explosive

material.

• Whenever performing maintenance or service, make sure to

switch off the machine and to disconnect the power cable.

Direct Heat Vacuum Platen Safety Marks

Controller Thermostat Functions

Down Button: press this button if you need to lower the set temperature.

Up Button: press this button if you need to raise the set temperature.

Timer Button:

Power Button: This button ONLY turns the controller on and off, make sure

to turn it off first before turning off the direct heat vacuum plate completely.

The caution sign on the

machine indicates points

where the operator needs to

take special care during

operation.

• The surface heats up

gradually.

Direct Heat Vacuum Platen Installation

1. Place the Direct Heat

Vacuum Platen on the Freejet

printer.

2. Carefully pass the control

back and move the gantry

forward.

3. On the back side, connect

the power cord.

4. Attach the two Hoop and

loop cable ties and cable tie

mounts as shown in the

picture to hold the power

cord and thermostat

controller cable.

5. Place the control on the

printer.

6. Connect the power cord to

power outlet.

Direct Heat Vacuum Platen Operation

1. Turn on the controller for

the Direct Heat Vacuum

Platen.

2. Turn on the controller.

3. Set the temperature on the

control to the one that best

suits your need (it is

recommended to start with a

temperature of 40° C).

Fig 1 - Rear View of Direct Heat Vacuum Platen.

Fig 2- Side View of Direct Heat Vacuum Platen.

Anatomy of a Direct Heat Vacuum Platen
