Olympus WS-750M Manual de usuario
Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer
WS-750M
• High quality WMA/MP3
music playback
• Retractable USB connector
• Built-in stereo microphones • Recording Scenes
• Playback Scenes • 5 folders for file storage,
200 messages per folder
• Easy to use: large LCD,
operation by one large
central button
• 8 languages on board:
English, German, French,
Spanish, Italian, Russian,
Polish, Chinese
Your personal note taker which connects to PC
Designed for the fast-paced lifestyles of people who need to save their thoughts on the fly but don’t have time to lose. Eliminating
the need for a pen and paper, these lightweight recorders slip easily into any pocket. They boast outstanding Olympus recording and
playback quality while offering exceptional value for money. Stylish and high-performing, each of the latest models offers unparalleled
ease-of-use. Operating menus are a breeze to navigate and phenomenal extended recording possibilities make it a cinch to capture
every thought - from a quick note-to-self to a lecture or daily to-do list.
Specifications
Storage Media
Internal / Removable Media Internal + Removable
SD / SDHC Slot No
microSD / microSDHC card Yes
Internal memory 4GB
USB functionality
USB Speed USB 2.0 High Speed
USB Classes USB Audio class
USB Storage class
USB HID
Display
Display colour White
Display Backlit Yes
Display Size 27.6 x 23.9mm / 1.36''
Display Type Full Dot Matrix Display
Font size setting No
Contrast Adjustment Yes
Device operation
Main Switch Push
HOLD switch Yes
Power switch Yes
Recording Modes
Recording format WMA / MP3
STXQ 67h
STHQ 134h
STSP 270h
HQ 270h
SP 532h
LP 1058h
256 kbps 34h
192 kbps No
128 kbps 69h
44.1kHz / 16bit 6h 10min
Playback Modes
Playback format PCM (WAV) / MP3 / WMA
Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer
Sampling frequency
STXQ 44.1kHz / 128kbps
STHQ 44.1kHz / 64kbps
STSP 22kHz / 32kbps
HQ 44.1kHz / 32kbps
SP 22kHz / 16kbps
LP 8kHz / 8kbps
MP3 44.1kHz / 128kbps 44.1kHz /
256kbps
PCM 44.1kHz / 16bit
Frequency response
STXQ 40 - 19.000Hz
STHQ 40 - 16.000Hz
STSP 40 - 9.000Hz
HQ 40 - 13.000Hz
SP 40 - 8.000Hz
LP 40 - 3.000Hz
256 kbps 40 - 20.000Hz
192 kbps 40 - 19.000Hz
128 kbps 40 - 17.000Hz
44.1kHz 40 - 21.000Hz
Record function
Index Up to 16 per file
Operation
Auto recording VCVA recording
Voice Sync
Recording Scenes Meeting
Conference
Lecture
Dictation
Speech-Recognition
User Defined Setting
Sound control Rec Monitor
Low Cut-Filter
Playback function
Playback Scenes Voice 1, Voice 2, Music 1,
Music 2, Music 3
Playback speed Adjustable Fast: 20 Steps,
max +300% / Slow: 5 Steps,
min. -50%
Playback control Playback Speed Control
File operation Forward / Reverse Skip
Fast forward and rewind
Repeat functions Single music file repeat
Single music folder repeat
Partial Repeat
Repeat playback
Automatic playback Continuous playback
Sound enhancement Noise canceling function
Voice Filter
Equalizer
EUPHONY
Data organisation
No. of folders for Voice 5
Files per folder 200
File move No
Time/date info Yes
Folder Music 300
Folder Audible no audible support
Folder Podcasts no podcast support
Erase Erase all files
Erase single files
Workflow function
Author ID Setting No
Worktype ID Setting No
Priority setting No
Pending File No
Other Features
Configurable Firmware No
Audible support No
Podcast support No
Remote Control No
Voice feedback / guidance No
Beep signal (system sound) Yes
Daisy Support No
Image support No
Text to Speech Processing No
Visual Index function No
Voice commands No
LED REC (red) / PLAY (green)
Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer
Software
Corresponding Audio software
(name)
Sonority
Interfaces Input
SD / SDHC interface no function
Microphone sensitivity / gain High / Middle / Low
Power jack No
PC interface USB Storage class
Microphone jack 3.5 ø mm jack, impedance 2
k� or more
Microphones Built-in stereo microphones
Interfaces Output
Speaker Diameter Built-in ø 18 mm round
dynamic speaker
Max. working output 250 mW or more (8 � speaker)
Earphone jack 3.5 ø mm jack, impedance 8�
or more
Power Supply
Power Supply 1 x AAA Ni-MH rechargeable
battery (charge inside device)
or AAA battery
Alkaline battery life Recording: 25h (LP mode)
Playback: 30h via earphones
Ni-MH battery life Recording: 24h (LP mode)
Playback: 28h via earphones
Docking station with recharge
function
No
Device standalone recharge
function via USB
Yes
Device standalone recharge
function via AC adapter
No
Dimensions
Weight 51g (incl. batteries)
WxHxD 98.5 x 40 x 11mm (without
protrusions)
Housing colour Silver Grey
Housing material Plastic
Languages
Languages Audio Using
Instruction
No
Menu languages English, German, French,
Spanish, Italian, Russian,
Polish, Chinese
Hardware Security
Lock single files Yes
Device lock by PIN code No
Device Locky by Fingerprint No
