Olympus FL-600R Manual de usuario

Printed in China

600R

EN INSTRUCTIONS 7

CS NÁVOD K POUŽITÍ 25

DE BEDIENUNGSANLEITUNG 43

ES INSTRUCCIONES 61

FI KÄYTTÖOHJEET 79

FR MODE D’EMPLOI 97

NL AANWIJZINGEN 115

PL INSTRUKCJA 133

RU ИНСТРУКЦИЯ 151

UK ІНСТРУКЦІЯ 169

R219110LEurcover.indd1R219110LEurcover.indd1 2012/01/1016:33:262012/01/1016:33:26

3 4

MEMO

90ab

45678

R219110LEurcover.indd2R219110LEurcover.indd2 2012/01/1016:33:262012/01/1016:33:26

Information for Your Safety

IMPORTANT SAFETY

INSTRUCTIONS

When using your photographic equipment, basic safety precautions

should always be followed, including the following:

yRead and understand all instructions before using.

yClose supervision is necessary when any ﬂash is used by or near

children. Do not leave ﬂash unattended while in use.

yCare must be taken as burns can occur from touching hot parts.

bookR219110LEur.indb5bookR219110LEur.indb5 2012/01/1322:34:032012/01/1322:34:03

yDo not operate if the ﬂash has been dropped or damaged - until it has

been examined by qualiﬁed service personnel.

yLet ﬂash cool completely before putting away.

yTo reduce the risk of electric shock, do not immerse this ﬂash in

water or other liquids.

yTo reduce the risk of electric shock, do not disassemble this ﬂash,

but take it to qualiﬁed service personnel when service or repair

work is required. Incorrect reassembly can cause electric shock

when the ﬂash is used subsequently.

yThe use of an accessory attachment not recommended by the

manufacturer may cause a risk of ﬁre, electric shock, or injury to

persons.

SAVE THESE INSTRUCTIONS

bookR219110LEur.indb6bookR219110LEur.indb6 2012/01/1322:34:032012/01/1322:34:03

EN 7

Names of Parts (Fig.

p. 3)

1Wide panel 2Light-emitting area

3Remote sensor 4AF illuminator/LED

window 5Auto light receptor 6Catch light

plate 7Control panel 8AUTO CHECK lamp

9TEST button/CHARGE lamp 0OK button

aBounce lock release button bBACK LIGHT

button cON/OFF button dLatch

eDial (a: ﬂash compensation button; b: MODE

button; c: LED light button; d: ZOOM button)

Control Panel

(Fig.

)

Details

(

11, 18

)

1Super FP ﬂash 2Flash control mode 3Guide

number (GN) 4Flash intensity control 5Zoom

position (angle of illumination) 6FOUR THIRDS

7Zoom mode 8LED light 9ISO sensitivity

0RC mode group aAperture (F) bRC mode

channel cTemperature warning dDistance units

Continuous Firing

The ﬂash may become hot when ﬁred many

times in succession, resulting in damage

or malfunction. The ﬂash should be ﬁred

no more than 10 times in succession

at intervals of 2.5 seconds, after which

it should be left unused for at least 10

minutes.

Preparing a Battery (

Sold Separately

)

Choose from the below batteries:

• AA (R6) alkaline batteries (× 4)

• AA (R6) NiMH batteries (× 4)

Note

AA (R6) manganese batteries cannot be

used.

Thank you for purchasing this Olympus product. To ensure your safety, please read this

instruction manual before use, and keep it handy for future reference.

bookR219110LEur.indb7bookR219110LEur.indb7 2012/01/1322:34:032012/01/1322:34:03

8EN

Loading Batteries

1Open the battery compartment cover.

2Insert the batteries with correct +/– polarity.

3Close the battery compartment cover.

Attaching to the Camera

Conﬁrm that both the camera and electronic ﬂash are off. Attaching or removing the electronic

ﬂash while either the ﬂash or the camera is on may result in malfunction.

11Slide the latch in the direction opposite to that

indicated by the [LOCKX] icon (1).

2Slide the ﬂash into the hot shoe until it clicks securely

into place (2).

3Slide the latch to the [LOCKX] position (3).

• To remove the ﬂash, slide the latch in the direction

opposite to the [LOCKX] arrow and slide it from the shoe.

bookR219110LEur.indb8bookR219110LEur.indb8 2012/01/1322:34:032012/01/1322:34:03

EN 9

Turning on the Electronic Flash

Attach an electronic ﬂash to the camera, and then turn the camera on.

CHARGE lamp

AUTO CHECK lamp

ON/OFF button

Control panel 1Press the ON/OFF button.

• The control panel display will turn on.

• To turn the ﬂash off, press the ON/OFF button again.

• Replace the batteries if the CHARGE lamp does not light

after:

30 seconds (Alkaline batteries)

10 seconds (NiMH batteries)

• If the CHARGE lamp and AUTO CHECK lamp blink

simultaneously, batteries are running low. Replace the

batteries.

• The ﬂash will enter sleep mode whenever the camera

enters sleep mode.

• If no operations are performed for approximately 60

minutes, the ﬂash will turn off automatically. Press the

ON/OFF button to turn it on.

bookR219110LEur.indb9bookR219110LEur.indb9 2012/01/1322:34:042012/01/1322:34:04

10 EN

Shooting

AUTO CHECK lamp

Flash control

mode

Light control range

Firing angle

Displayed according to the

focal length of the lens.

1Use camera controls to choose the ﬂash mode.

See the camera manual for details.

2Choose a ﬂash control mode.

g“Flash control mode” (p. 11)

3Press the shutter button halfway.

• The camera and ﬂash will exchange shooting

information and the ﬂash range will be displayed in the

control panel.

• Flash range varies with camera settings (ISO

sensitivity, aperture, and lens focal length).

4Press the shutter button the rest of the way down to

take the picture.

The AUTO CHECK lamp blinks for about 5 s after

shooting to indicate that the ﬂash has ﬁred successfully.

• When using a ﬂash, ﬂash light may be blocked by the lens body, lens hood, etc.

• Use the wide panel to prevent overexposure at ranges of less than 1 m (3 ft.).

bookR219110LEur.indb10bookR219110LEur.indb10 2012/01/1322:34:042012/01/1322:34:04

EN 11

Flash Control Mode

Choose a ﬂash control mode according to your subject and shooting conditions.

To select a mode, press the MODE (F) button and rotate the dial.

Control panel display Control operation

TTL-AUTO

The flash light intensity is controlled automatically according

to the camera’s setup. The flash will be adjusted based on the

brightness taken through the camera’s lens. Usually use this mode

with a camera with communication capability.

AUTO

Blinks: Out of ﬂash control

range

The flash will be adjusted based on the brightness captured

by auto light receptor on the electronic flash. If the camera has

communication capability, this mode can be used only when the

camera is an AUTO-compatible model.

bookR219110LEur.indb11bookR219110LEur.indb11 2012/01/1322:34:042012/01/1322:34:04

12 EN

Control panel display Control operation

MANUAL In this mode, the flash is emitted according to the guide number

setting. Rotate the dial to choose the guide number. The flash

displays the optimal range, which is calculated based on the guide

number and camera settings.

FP TTLAUTO Super FP flash. This mode allows you to use flash photography

even at shutter speeds faster than the flash synchronization speed

of the camera. Flash level is set automatically. Maximum output

is reduced, resulting in a smaller flash range. Flash range also

diminishes with shutter speed.

FP MANUAL The flash fires at the selected guide number. Rotate the dial to

choose the guide number. The flash displays the optimal range,

which is calculated based on the guide number and camera

settings.
