Olympia IC 1280Z Manual de usuario
IP Camera with Receiver
Operating Manual
01.2016 en
…easy to operate using the
"ProHomeIPC" app from Olympia
Contents
3G
Contents
General Information 6............
General Safety Information 6........
Intended Use 7....................
Unintended Use 7.................
Legal Notice 7....................
Notations Used in this Manual 7.....
System Requirements 8............
iOS 8.................................
Android 8..............................
General Overview 9...............
Checking the Package Contents 9...
Connections and Operating Elements 9
Receiver 11.......................
Pivoting Range and Angle of Vision 11
Connecting the Camera 12.........
Inserting the MicroSD Memory Card 12
Positioning the Camera 12...........
Mounting the Camera on the
Wall/Ceiling 12..................
Connecting the Camera -
Network Cable 13................
Connecting the Camera -
Power Adapter and Receiver 13...
Operating with an Alarm System
(Protect 6xxx / 9xxx) 13...............
Registering the Receiver on the
Alarm System 14................
Use Without an Alarm System 16.....
Installing the ProHomeIPC App 17....
Contents
G4
Connecting the Smartphone/Tablet PC
to the Camera 18...............
Using the ProHomeIPC App 20.....
Operating the Camera (iOS) 22.....
Moving the Screen Section 22........
Opening the Menu Bar 22...........
Buttons in the Menu Bar 23..........
Push to Talk 23..........................
Snapshots 23...........................
Saving Image Sections as a Preset 24......
Activating Night Vision 25.................
Flipping the Image Section Horizontally 25..
Flipping the Image Section Vertically 26....
Changing the Resolution 26...............
Adapting to Environmental Conditions 26...
Start Screen of the ProHomeIPC App 27
Context Menu of the
ProHomeIPC App 28.............
Camera List 29.....................
Event 30..........................
Add Device 31.....................
QR Code 32............................
Automatic Search 33.....................
Connecting Manually 34..................
Version Information 35..............
Deleting Cameras 36...............
Settings 37........................
Camera 38..............................
Advanced Settings 42...............
Alarm Setting 47...................
Time Setting 54....................
Contents
5G
Operating the Camera (Android) 55.
Moving the Screen Section 55........
Opening the Menu Bar 55...........
Buttons in the Menu Bar 56..........
Push to Talk 56..........................
Snapshots 56...........................
Saving Image Sections as a Preset 57......
Activating Night Vision 58.................
Flipping the Image Section Horizontally 58..
Flipping the Image Section Vertically 59....
Changing the Resolution 59...............
Adapting to Environmental Conditions 59...
Start Screen of the ProHomeIPC App 60
Add Device 61.....................
QR Code 62............................
Automatic Search 63.....................
Connecting Manually 64..................
Context Menu of the Camera 65......
Reconnect 66...........................
View Event 67...........................
View Snapshot 68.......................
Remove Camera 69......................
Edit Camera 70..........................
Edit Camera 71....................
Device Setting 72........................
Advanced Setting 76................
Alarm Setting 80...................
Time Setting 87....................
Other Important Information 88.....
Guarantee 88......................
Regular Maintenance and Service 88.
Technical Modifications 88...........
Information on Disposal 88..........
CE Mark 88........................
Technical Data 89..................
Troubleshooting 90.................
General Information
General Safety Information
G6
General Information
Please read and observe the following
information and keep this operating
manual in a safe place for future reference!
General Safety Information
Observe the following safety instructions in order to pro
tect yourself from the possibility of personal injury and the
product from damage.
WARNING!
•Risk of electric shock! Never attempt to open and re
pair the device or accessories yourself. Never touch
bare contacts with metallic objects. Never plug-in or un
plug the power cable when your hands are wet.
•Risk of suffocation! Keep out of reach of children!
Keep packaging materials and protective foils out of
reach of children. Keep the device and any accessories
out of reach of children. Small children can swallow
small parts. Seek medical attention immediately if a
small part is swallowed.
CAUTION!
•Risk of hearing damage! The audio signals are emit
ted through a loudspeaker. Pay attention that a reason
able loudspeaker volume is set for transmitting the audio
signals.
ATTENTION!
Avoid the risk of property damage to your device and ob
serve the information!
•Do not use the camera in prohibited areas! Prohibit
ed areas could include public buildings or spaces, for
example. Please observe local laws and regulations!
•Protect the camera from moisture, dust, liquids, chemi
cals, vapours, heat and direct sunlight. The camera is
not waterproof, so ensure you keep it dry.
•Only use original accessories. Only connect acces
sories approved by the manufacturer to the camera and
only us the power adapter supplied.
•Property damage is possible. Only use properly in
stalled, easily accessible power sockets.
•Repairs to this device may only be completed by prop
erly qualified service personnel.
General Information
Intended Use and Notations Used in this Manual
7G
Intended Use
The IP camera (subsequently referred to as the camera)
is designed to perform video surveillance (CCTV) by day
and night. The camera is exclusively intended for use in
closed rooms. When installing and selecting the area of
application of the camera, pay attention to the personal
rights of third-parties and that the respective, applicable
local laws and regulations are not violated.
Unintended Use
The camera is not suitable for use in wet rooms or poten
tially explosive areas.
Monitoring of third-parties is not permitted without the re
spective, explicit authorisation and could have legal con
sequences.
Any use other than that described in Intended Use is con
sidered unintended use. Unauthorised modification
or reconstruction is not permitted.
Under no circumstances open the camera or accessories
or attempt to complete any repair work yourself.
Legal Notice
All the trademarks or brand names on the product and/or
accessories or which appear in this operating manual
serve solely for descriptive purposes and do not imply that
they are freely available. The trademarks and brand
names are the property of the respective proprietor of the
rights.
Notations Used in this Manual
The section below explains the presentations and nota
tions used in this operating manual.
1. This indicates the first step in a set of instructions.
2. This indicates the next step in a set of instructions.
This symbol indicates useful information which will
help you to use the camera and ProHomeIPC App.
Indicates a list.
General Information
System Requirements
G8
System Requirements
This operating manual assumes users have a basic
knowledge of connecting and configuring network-capable
devices and smartphones or tablet PCs.
iOS
In order to exploit the full functional scope of the camera
using the ProHomeIPC App for iOS, you require:
an internet-capable iPhone (from iPhone 4)
operating system iOS 7 or later
ProHomeIPC App
(refer to Chapter Installing the ProHomeIPC App)
Android
In order to exploit the full functional scope of the camera
using the ProHomeIPC App for Android, you require:
an internet-capable smartphone
operating system Android 4.0 or later
ProHomeIPC App
(refer to Chapter Installing the ProHomeIPC App)
General Overview
Checking the Package Contents
9G
General Overview
This section provides information on the package contents
as well as the connections and operating elements on the
camera.
Checking the Package Contents
Unpack the camera and check that the package contents
are complete. The camera package must contain the fol
lowing components:
Camera
Power adapter plug
Receiver
Mounting bracket
Network cable (RJ45/RJ45, Cat.5e)
Operating manual
Check for any visible signs of damage to the camera
packaging or the components supplied. If there are,
do not put the camera into operation.
Connections and Operating Elements
Before connecting the camera, familiarise yourself with
the connections and operating elements on it.
1Lens with optical zoom
(model IC 1280 Z only)
2 Infrared LEDs (night vision)
3Brightness sensor
4 Microphone
5WLAN receiving antenna
6 Loudspeaker
7Power adapter connection port
8 Port for receiver
(connection to an alarm system from the Protect
series)
9MicroSD card slot (max. 32 GB)
10 Network connection port
11 Aux output (3.5 mm connector)
12 Internal thread for mounting bracket
13 Reset button
14 Installation holes
15 Rating plate with QR code
General Overview
Connections and Operating Elements
G10
AUDIO
S/D
1 2 3 4 DC 5 V
I/O Alarm
ANT
5
6
789
10
11
12
13
14
15
1
23
4
