Oki B B930n Manual de usuario

Contents Table des matières

Printer Overview ........................5

Using the Printer Menu...............8

Print Media ...............................10

Loading Trays 1 & 2.....................10

Loading the MPT Tray...................12

Loading the HCF Tray...................14

Jams.........................................17

Trays 1-2 ...................................18

Multi-Purpose Tray (MPT) .............20

High Capacity Feeder Tray ............22

Additional Jam Locations ..............24

Finisher ....................................34

Troubleshooting .......................37

Replacement Supplies ..............40

Service & Support....................41

Survol de l’imprimante. . . . . . 42

Utilisation du menu

d’impression .......................... 45

Support d’impression ............... 47

Chargement des bacs 1 et 2..........47

Chargement du bac

multifonction.............................49

Chargement de l’alimentateur

haute capacité ..........................52

Bourrages ................................ 55

Bacs 1 et 2 .................................56

Bac multifonction.........................58

Alimentateur haute capacité..........60

Autres emplacements de

bourrages.................................62

L’unité de finition..................... 72

Dépannage............................... 75

Fournitures de remplacement .. 78

Service et support.................... 79

Generalidades de la

Impresora . . . . . . . . . . . . . . 80

Cómo utilizar el menú de la

impresora ...............................83

Medios de impresión.................85

Cómo cargar las Bandejas 1 y 2 ....85

Cómo cargar la Bandeja

Multiuso ...................................87

Bandeja del Alimentador de

Alta Capacidad ..........................90

Atascos.....................................93

Bandejas 1 y 2............................94

Bandeja Multiuso.........................96

Alimentador de Alta Capacidad ......98

Otros lugares donde el papel

se atasca................................ 100

Acabador ................................110

Resolución de problemas........113

Suministros ............................116

Servicio y Soporte ..................117

Visão geral da impressora . .118

Utilização dos menus da

impressora ........................... 121

Mídia de impressão ................ 123

Colocação de mídia de impressão

nas bandejas 1 e 2 .................. 123

Colocação na bandeja

multifuncional .........................125

Colocação na bandeja do AAC .....128

Atolamentos de papel (mídia de

impressão)........................... 131

Bandejas 1 a 2..........................132

Bandeja multifuncional (MF)........134

Bandeja do alimentador de

alta capacidade .......................136

Outros locais de atolamento........ 138

Alceador................................. 148

Diagnóstico e solução de

problemas ............................ 151

Suprimentos de reposição...... 154

Assistência técnica e suporte . 155

Contenido Sumário

Printer Overview

Front View

1FrontDoor

2 Paper Trays (1 and 2)

3 Duplex Unit

4 Multi-Purpose Tray (MPT, Tray 5)

5 Standard top bin output tray and transport to

optional finisher

6 Optional High Capacity

Feeder (HCF)

7 Optional tabloid tray or

tandem tray (Trays 3

and 4)

8 Optional finisher

9 Finisher main stacker

(3000 sheets)

10Finisher upper stacker

(500 sheets)

11Exit 2: used in

conjunction with the

optional duplexer and

the optional finisher.

Present only if the

optional duplexer is

installed.

READY light

Off:

printer is idle

On:

printer is active

Blinking: printer is waiting, processing

ATTENTION light

Off:

no error

On:

there is an error requiring user

intervention

CANCEL Button

Cancel a print job.

ON-LINE Button

Toggles the printer on-line and off-

line.

MENU Button

Press to enter or exit the menu.

SELECT Button

Press to select the Menu or Submenu

shown on the second line of the

display or choose and save the setting

shown on the second line of the

display.

NEXT/PREVIOUS Buttons

Press to move to the

(

) or

(

) Menu, Submenu, or

Setting within the same level of the

menu structure.

FORWARD/BACK Buttons

Press to move

Forward

(

) or

Back

(

) one level in the menu structure to

the menu shown on the first line of

the display.

Printer Overview

Operator Panel Overview

Print a Summary of the

Printer’s Settings

Press the

Info

button on the Operator

Panel to print a configuration

summary including:

• Status of menu options

• Media selections in trays

• Installed options

Cancel a Print Job at the

Printer

At the Operator Panel:

1. Press the

Cancel

button.

2. Press the

On-line

button.

Note that pages that are printing at

the moment will finish printing.

Reset Printer to Factory

Defaults

At the Operator Panel:

1. Press

2. Press

(

) until

Maintenance

is displayed.

3. Press

Select

. You may be

prompted to enter a password.

4. Press

Forward

(

) until

Reset

is displayed.

5. Press

Select

to reset the menus to

their factory defaults (i.e.,

“execute”).

6. Press

. The printer resets and

goes back to the Ready to Print

state.

Printer Overview

Basic Operator Panel Functions

Using the Printer Menu

Changing Settings

1. Press

2. Press

(

) and

(

)

to scroll through the

menus

until

the one you want is displayed.

3. Press

Select

4. Press

Forward

(

) and

Back

(

)

to cycle through the

submenus

for

the selected menu until the one

you want is displayed.

5. Press

Select

6. Press

(

) and

(

)

to scroll through the

options

until

the one you want is displayed.

7. Press

Select

An asterisk appears next to the

setting.

8. To exit Menu mode, press 3 or

press the Menu button.

Note

: If there is a conflict between

settings in the menu, Printing

Preferences, or Embedded Web Server

and printer settings set via your

application, the application settings

supersede any other setting.

C96


NETWORK MENU

How to Enter a Pin Number

at the Operator Panel

1. Press

. Press

(

) until

the

Print Jobs

menu is displayed.

Press

Select

2. Press

Forward

(

). You are

prompted to enter a pin number.

3. Use

(

) and

(

)

to specify the first digit in the pin

number, then press

Forward

(

)

to enter the digit.

4. Repeat step 3 until all digits are

entered. Press

Select

5. Press

(

) until the

is displayed. Press

Select

6. Press

(

) until your

document is displayed. Press

Select

7. To print the document: Press

(

) to specify the number of

copies. Press

Select

to print.

Using the Printer Menu

Entering a Pin Number

Loading Media in Trays 1-2

Note: Put side to be printed face up.

Slide the paper tray back into the

machine

If custom sizes of paper

are used, make the appropriate

changes in your Printer Properties

and at the Operator Panel as

needed.

For Letterhead stationery:

Long edge feed—face

up, top toward the

front of the printer.

Short edge feed—

face up, top to the

left:

Print Media

Loading Trays 1 & 2
