Oclean W1 Manual de usuario
2
English
3 –10
Čeština
11 –18
Slovenčina
19 –26
Magyar
27 –34
3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Prague 7, www.alza.cz
4
Important Safety Tips
•This product can only be used with Oclean special nozzle. Oclean will not bear the
responsibility caused using any third-party accessories.
•To prevent water from spraying toward eyes, nose, ears, or throat to cause
accidental injury, do NOT use for purpose other than oral cleaning.
•People who have just undergone oral surgery for treatment. It is recommended
those who have mouth disease such as seriously haemorrhaged gums to consult
a dentist before using it.
•It’s normal to feel a bit discomfort or bleeding slightly when use it for the first
time, situation will be much batter as gum gets healthier. If there is a large
amount of bleeding or bleeding after 3-4 weeks still, it’s recommended to consult
a dentist.
•To avoid injury caused by accidental inhalation by children or infants, this
product is only recommended for people over 12 years old.
Nozzle
The nozzle can be rotated by 360
degrees. When replacing nozzle pull lit
out vertically. Insert the closely attached
to the device body.
Mode switch button
Short press to switch modes.
Mode indicator light
Level 1 manual burst
Level 2 manual burst
Level 3 automatic burst
(Short press on power button to start
automatic burst. Support customization for
burst plans in Oclean App)
Water tank
The water tank can be removed by
pulling down with a slight force.
Power button/charging
indicator light
Press the power button to wake up the
device in stand-by mode, the mode
indicator stays in the latest memorized
mode.
Holding the power button for a
constinuous burst, relase the button to
stop.
Red light flashing: Low power remider.
White light flashing: Charging status
White light on constanly: Fully charged
Magnetic charging port
Charging starts after the charger
magnetically attached to the
charging port.
5
Instructions
1. Refill the water tank
Pull down the water tank with a little force
to detach it. Fill water or mouthwash into
the water tank (The liquid temperature
should not be over 40°C), then insert the
water back into the device.
2. Installation of nozzle
1. Fix the silicone cap to the nozzle.
2. Insert the nozzle to the device body.
3. Mode switch
Short press on modes switch choose the best fit mode, the device will memorize the
latest mode.
6
4. Bursting Instructions
Put the nozzle intermittently close to the slit between teeth. Press and hold the power
button to start cleaning. Slowly move along the gum line to the next zone, repeat the
cleaning for all slit.
Device Cleaning and Maintenance
1. Remove he nozzle, clean
the nozzle with running
water after each use.
2. Detach the water tank,
get rid of the remaining
liquid and clean the water
tank with running water.
3. Wipe the surface of the
device with a soft wet cloth
to keep it clean.
Important Tips
•It’s normal that the first few bursts may be only gas, it will become a mixture of
air and water burst when water reaches the nozzle.
•Do NOT soak the device body in water, se dry cloth to clean it after use.
•Id the device will be long time shelved, please empty the water tank to dry. It’s
recommended to use spray function to clear the remaining water. Clean and
store the product in a cool and dry place. Do NOT expose it in direct sunlight.
•It’s normal that the device heats up a little during cleaning process.
•It’s normal there’s a little plastic smell in the first few tanks of cleaning, the smell
will disappear after several times of use.
•Please empty the water tank and wipe it dry before putting into the travel case.
7
Specifications
Product Name
Oclean W1 Smart Oral Irrigator
Model
Oclean W1
Water Tank Capacity
30 ml
Waterproof level
IPX5
Input Power
2.5 W
Charging
Oclean magnetic charging
Input
5V 0.5A
Battery Life*
30 days
Battery Capacity
1200 mAh
Charging time
3 hours
Standard
GB 4706.1-2005 GB 4706.59-2008
* Remark: Battery life is calculated based on default mode, working once/day, 1
tank/time
Other Tips
•It’s recommended to change the nozzle every 4-6 months. If the nozzle is
seriously blocked or cannot be installed on the device body normally and tightly,
it also needs to be replaced immediately.
8
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
9
EU Declaration of Conformity
Identification data of the manufacturer's / importer's authorized representative:
Importer: Alza.cz a.s.
Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7
CIN: 27082440
Subject of the declaration:
Title: Smart Oral Irrigator
Model / Type: W1
The above product has been tested in accordance with the standard(s) used to
demonstrate compliance with the essential requirements laid down in the
Directive(s):
Directive No. 2014/30/EU
Directive No. 2011/65/EU as amended 2015/863/EU
10
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.
