Ocean BCB 2731 TNF E A+ Manual de usuario
BCB 2731 TNF E A+
Built In Refrigerator
Fridge - Freezer
User manual
Encastrable
Réfrigérateur - Congélateur
Guide d'utilisation
Frigorífico Combi Dos Puertas
Congelador - Frigorífico
Manual de Instrucciones
Μηχανικο Ψyγeıo Cομβι
Οδηγίες Χρήσης
ﺔﺟﻣدﻣ ﺔﺟﻼﺛ
ﺔﺟﻼﺛو رزﯾرﻓ
مدﺧﺗﺳﻣﻟا لﯾﻟد
EN - 1 -
Contents
BEFORE USING THE APPLIANCE .......................................................... 2
General warnings ........................................................................................2
Old and out-of-order fridges ........................................................................4
Safety warnings ...........................................................................................4
Installing and operating your fridge freezer .................................................5
Before Using your fridge freezer..................................................................6
HOW TO OPERATE THE APPLIANCE..................................................... 6
Information about The New Generation Cooling Technology ......................6
Control panel ...............................................................................................7
Warnings for Temperature Settings............................................................................8
Accessories .................................................................................................9
Ice tray .......................................................................................................................9
Bottle holder...............................................................................................................9
Fresh dial ..................................................................................................................9
Adjustable Door Shelf ................................................................................................9
Maxi-fresh preserver ................................................................................................10
FOOD STORAGE IN THE APPLIANCE.................................................. 11
Refrigerator Compartment......................................................................... 11
Freezer Compartment ............................................................................... 11
CLEANING AND MAINTENANCE .......................................................... 14
Defrosting ..................................................................................................15
Replacing LED Lighting............................................................................................15
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION 15
BEFORE CALLING YOUR AFTER SALES SERVICE............................ 16
Tips for saving energy ...............................................................................17
PARTS OF THE APPLIANCE AND THE COMPARTMENTS ................. 18
The operating instructions apply to several models. Differences may therefore occur.
EN - 2 -
PART - 1. BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of the
appliance, it must be xed in accordance with the instructions.
WARNING: When positioning the appliance, ensure the supply
cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
Warning; Risk of re / ammable materials
(Symbol ISO 7010 W021)
• If your appliance uses R600a as a refrigerant (this information
will be provided on the label of the cooler) you should
take care during transportation and installation to prevent
the cooler elements from being damaged. R600a is an
environmentally friendly and natural gas, but it is explosive.
In the event of a leak due to damage of the cooler elements,
move your fridge away from open ames or heat sources
and ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
EN - 3 -
• This appliance is intended to be used in household and
domestic applications such as:
- staff kitchen areas in shops, ofces and other working
environments.
- farm houses and by clients in hotels, motels and other
residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, a service agent or similarly
qualied persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with
a specially grounded socket of 16 amperes. If there is no
such socket in your house, please have one installed by an
authorised electrician.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
• If the supply cord is damaged, it must be replaced by
the manufacturer, an authorised service agent or similar
qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.
EN - 4 -
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock before discarding
it, because children may get trapped inside it and may cause an accident.
• Old fridges and freezers may contain isolation material and refrigerant with
CFC or HFC. Therefore, take care not to harm environment when you are
discarding your old fridges.
• Please ask your municipal authority about the disposal of the WEEE
reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and using your appliance.
We are not responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this manual in
a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used in homes and it can only be used in domestic
environments and for the specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the appliance to be cancelled and
our company will not be responsible for losses incurred.
• This appliance is produced to be used in houses and it is only suitable for cooling / storing
food. It is not suitable for commercial or common use and/or for storing substances
except for food. Our company is not responsible for losses to be incurred in the contrary
case.
Safety warnings
• Do not connect your fridge freezer to the mains electricity supply using an extension lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children to
play with the appliance or let them hang off the door.
• Never touch the power cord/plug with wet hands as this could cause a
short circuit or electric shock.
• Do not place glass bottles or beverage cans in the ice-making
compartment as they can burst as the contents freeze.
• Do not place explosive or ammable material in your fridge freezer. Place
drinks with high alcohol content vertically in the fridge compartment
and make sure that their tops are tightly closed.
• When removing ice from the ice-making compartment, do not touch it.
Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands! Do not eat ice-cream and
ice cubes immediately after you have taken them out of the freezer
EN - 5 -
compartment!
• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes
immediately after you have taken them out of the ice-making compartment.
• Do not cover the body or top of fridge with lace. This affects the performance
of your fridge freezer.
• Secure any accessories in the fridge freezer during transportation to prevent damage to
the accessories.
• Do not use plug adapter
Installing and operating your fridge freezer
Before starting to use your fridge freezer, you should pay attention to the following points:
• The operating voltage for your fridge freezer is 220-240 V at 50Hz.
• The plug must be accessible after installation.
• Your fridge may have a smell when it is operated for the rst time. This is normal and the
smell will fade away when your fridge freezer starts to cool.
• Before connecting your fridge freezer, ensure that the information on the data plate
(voltage and connected load) matches that of the mains electricity supply. If in doubt,
consult a qualied electrician.
• Insert the plug into a socket with an efcient ground connection. If the socket has no
ground contact or the plug does not match, we recommend that you consult a qualied
electrician for assistance.
• The appliance must be connected with a properly installed fused socket. Power supply
(AC) and voltage at the operating point must match with the details on the name plate of
the appliance (name plate is located on the inside left of the appliance).
• We do not accept responsibility for any damages that occur due to ungrounded usage.
• Place your fridge freezer where it will not be exposed to direct sunlight.
• Your fridge freezer should never be used outdoors or exposed to rain.
• Your appliance should be at least 50 cm away from stoves, gas ovens and heater cores,
and at least 5 cm away from electrical ovens.
• When your fridge freezer is placed next to a deep freezer, there should be at
least 2 cm between them to prevent humidity forming on the outer surface.
• Do not place heavy items on the appliance.
• Clean the appliance thoroughly, especially the interior, before use (see
Cleaning and Maintenance).
• The installation procedure into the kitchen unit is given in the installation
manual. This product is intended to be used in proper kitchen units only.
• Before using your fridge freezer, wipe all parts with a solution of warm water
and a teaspoon of sodium bicarbonate, then rinse with clean water and dry.
Place all parts in the fridge freezer after cleaning.
EN - 6 -
Before Using your fridge freezer
• When using your fridge freezer for the rst time, or after transportation,
keep it in an upright position for at least 3 hours before plugging into
the mains. This allows efcient operation and prevents damage to the
compressor.
• Your fridge freezer may have a smell when it is operated for the rst time. This is normal
and the smell will fade away when your fridge freezer starts to cool.
Information about The New Generation Cooling
Technology
The New Generation Cooling Technology refrigerators are
different from the other static refrigerators in terms of their
operational system.
In normal fridge freezers, the humidity entering the fridge freezer
due to opening the door and the humidity inherent in the food
causes freezing in the freezer compartment. To defrost the frost
and ice in the freezer compartment, you are periodically required
to turn off the fridge freezer, place the food that needs to be kept
frozen in a separately cooled container and remove the ice
gathered in the freezer compartment.
The situation is completely different in no-frost refrigerators. Dry
and cold air is blown into the fridge and freezer compartments
homogeneously and evenly from several points via a blower
fan. Cold air dispersed homogeneously and evenly between
the shelves cools all of your food equally and uniformly, thus
preventing humidity and freezing.
Therefore your New Generation Cooling Technology fridge
freezer allows you ease of use, in addition to its huge capacity
and stylish appearance.
HOW TO OPERATE THE APPLIANCEPART - 2.
EN - 7 -
Control panel
This button allows setting temperature of the fridge. In order to set values for fridge partition,
press this button. Use this button also to activate Super Cooling mode.
1.1.1. Alarm light
In case of a problem within the fridge, the alarm led will release red light
1.1.2. Super Cooling Mode
When would it be used?
• To cooling huge quantities of food.
• To cooling fast food.
• To cooling food quickly.
• To store seasonal food for a long time.
How to use?
• Press temperature set button until super cooling light comes on.
• Super cooling led will light during this mode.
• For optimal appliance performance in maximum cooling capacity, set the appliance
to active Super Cooling mode 5 hours before you put the fresh food into the fridge.
During this mode:
If you press temperature set button, the mode will be cancelled and the setting will
be restored from MAX.
Note: “Super cooling” mode will be automatically cancelled after 5 hours.
1.1.3. Temperature Settings
• The initial temperature of the Setting Display is Middle temperature indicator.
• Press temperature set button once.
• Every time you press the button, the setting temperature will decrease.
• If you press temperature set button until super cooling symbol is displayed on your fridge
settings display and you do not press any button within the following 3 seconds, Super
cooling will blink.
Temperature
set button
Symbol of
Super Cooling Mode
Alarm
indicator led Temperature indicator
EN - 8 -
Warnings for Temperature Settings
• Do not pass to another adjustment before completing an adjustment.
• Temperature adjustments should be made according to the frequency of door openings,
the quantity of food kept inside the fridge and ambient temperature of the place of your
fridge.
• Your fridge should be operated up to 24 hours according to the ambient temperature
without interruption after being plugged in to be completely cooled.
• Do not open doors of your fridge frequently and do not place much food inside it in this
period.
• A 5 minute delaying function is applied to prevent damage to the compressor of your
fridge, when you take the plug off and then plug it on again to operate it or when an
energy breakdown occurs. Your fridge will start to operate normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature intervals stated in the
standards, according to the climate
class stated in the information label.
We do not recommend operating your
fridge out of stated temperatures value
limits in terms of cooling effectiveness.
• This appliance is designed for use at an
ambient temperature within the 16°C -
38°C range.
Climate class Ambient Temperature (oC)
TBetween 16 and 43 oC
ST Between 16 and 38 oC
NBetween 16 and 32 oC
SN Between 10 and 32 oC
• If you keep on pressing, it will restart from last value.
It ensures that the temperature settings in the cooling and freezing compartments of your
refrigerator are performed automatically. It may be set to any value ranging from MIN to
MAX. As you press temperature set button from MIN to MAX, the temperature decreases. To
save energy in winter months, operate your refrigerator in a lower position.
EN - 9 -
Accessories
Ice tray
• Fill the ice tray with water and place in the
freezer compartment.
• After the water has completely turned into
ice, you can twist the tray as shown below
to remove the ice cubes.
Bottle holder
In order to prevent bottles from slipping or falling
over, you can use the bottle holder. This will also
help to prevent the noise made by bottles when
opening or closing the door.
Fresh dial
When the humidity controler in the closed
position, it allows fresh fruit and vegetables to
be stored longer.
In case of the crisper is totally full, the fresh dial
is located in front of crisper, should be opened.
By means of this the air in the crisper and
humidity rate will be controlled and endurance
life will be increased.
If you see any condensation on glass shelf, humidity control should be taken into the open
positions.
(In some models)
(In some models)
(In some models)
Fig. 1
Fig. 2
Adjustable Door Shelf
Six different height adjustments can be made to provide storage
areas that you need by adjustable door shelf.
To change the position of adjustable door shelf ;
Hold the bottom of the shelf and pull the buttons on the side of the
door shelf direction of arrow (Fig.1).
Position door shelf the height you need by moving up and down. After
you get the position that you want the door shelf, release the buttons
on the side of the door shelf (Fig.2) Before releasing the door shelf,
move up down and make sure the door shelf is xed.
Note: Before moving door shelf is loaded, you must hold the shelf
by supporting the bottom. Otherwise, door shelf could fall off the rails
due to the weight. So damage may occur on the door shelf or rails.
(In some models)
Tabla de contenidos
Idiomas:
Otros manuales de Refrigerador de Ocean
