1) High Resolution HR4
The Ocean WayAudio HR4/HR4S Reference Monitor is an accurate, wide-dynamic-range, sound-delivery system for the
professional listening environment. It is 25.5” wide and features an integrated 2-way dual-horn, directivity-control loudspeaker
that can be placed as a pair in any environment to provide an exceptionally-accurate and revealing stereo monitoring
experience.
At the heart of the acoustic design is HR4’s dual/hybrid waveguide system. Its unique design was engineered utilizing 3D
modeling and then CNC machined from composite materials. This accurate process allows for the creation of geometrically-
complex surfaces that are accurately-matched for delivering detailed imaging.As a result, the HR4 delivers a stunning 100 x
40 degree dispersion pattern over a very wide audio range. An exceptionally wide “sweet-spot” is revealed with rich detail
across a broad area of the listening spectrum. The consistency of its stereo image, even at the far corners of the room, is
achieved due to the highly consistent directivity response of the speaker system. This is often a delightful surprise to the
listener in light of what is available today.
The HF driver is a high-definition silk fabric dome design with excellent mechanical linearity. The LF driver is a geometrically
reinforced aluminum cone with a vented cast-aluminum chassis yielding optimum strength and high-power linearity. Combined
with a rock-solid wood/composite cabinet, the system is voiced to provide an undetectable crossover transition between the
drivers. Our two-way, self-powered design delivers an unprecedented level of performance allowing for flexibility of placement
in the room with a matched uniform frequency response of 35 Hz to 25 kHz.
For those who wish to achieve even greater SPL, we offer a 3-Way version with dual 12” sub-bass cabinets –entitled HR4S.
HR4S delivers 25 Hz to 25kHz @ 118 db.
We carefully select and match each set of components getting them as close as possible to achieve our high performance
standards. Our process could easily be compared to building a fine musical instrument.
Read the information for use
Please keep this user manual in a safe place during the lifetime of the product.
Heed all warnings.
Follow all instructions.
Do not use this product near water (for example, in damp rooms or near a swimming pool).
Clean only with dry cloth.
Do not cover the heat sink. Install in accordance with the user manual.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that
produce heat.
Protect the power cord from being walked on, pinched or damaged in any other way. Pay particular
attention to plugs and the point where they exit from the Amplifier Unit.
TheAmplifier Unit can only be disconnected from the power supply by removing the plug, which must
be freely accessible at all times. Unplug this Amplifier Unit during lightning storms or when unused for
long periods of time.
Refer all servicing to qualified service personnel.
2) Safety Instructions and Warnings
Servicing
Do not attempt to service this product yourself. As opening or removing covers may expose you to
dangerous voltage or other hazards, the amplifier may only be opened by qualified personnel. Please
refer to your dealer/distributor.
Servicing and Replacement Parts
All service and repair work must be carried out by an authorized dealer/distributor. When replacement parts
are required, please ensure that the dealer/distributor only uses replacement parts specified by the
manufacturer. The use of unauthorized replacement parts may result in injury and/or damage through fire
or electric shock or other electricity -related hazards.
Ventilation and heat sink
The heat sink is provided to ensure reliable operation of theAmplifier Unit and to protect it from
overheating. The heat sink must not be blocked or covered. This product should not be installed unless
proper ventilation is provided or manufacturer’s instructions have been adhered to.
Water and Moisture
Do not use this product near water (for example, in damp rooms or near a swimming pool).
Cleaning
Unplug theAmplifier Unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners.
Power -Cord Protection
Power supply cords should be routed so that they are not likely to be walked on or pinched by items
placed upon them or against them, paying particular attention to cords and plugs, and the point where
they exit from the Amplifier Unit.
Lightning
For added protection of the product during lightning storms, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet. This will prevent damage to the product due to
lightning and power-line surges. Disconnection from the mains power supply can only be achieved by
removing the plug from the mains socket and by external disconnection of all poles from the mains.
Accessories
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall,
causing serious injury, and serious damage to the product.
Connecting
When you connect this speaker to other equipment, turn off the power and unplug all of the equipment
from the supply source. Failure to do so may cause an electric shock and serious personal injury. Read
the user's manual of the other equipment carefully and follow the instructions when making the
connections.
Sound Volume
Reduce the system volume to minimum before you turn on the amplifier to prevent sudden high levels
of sound which may cause hearing or speaker damage.
Precautions when connecting to MAINS IN
When mounting or connecting the product always disconnect it from mains. Only connect the product to
an appropriateAC circuit and outlet, according to the requirements indicated on the rating plate. If a
power cut occurs while the amplifier is switched on, it will restart automatically once the power supply
has been restored.All settings prior to the loss of power will be maintained. IMPORTANT: Always
connect the Product to mains through the MAINS IN connector on theAmplifier Unit.
DO NOT REMOVE MAINS CONNECTOR GROUND, IT IS ILLEGAL
AND DANGEROUS.
AC power 115/230v switch
Make sure to correctly configure with the correct voltage for your country.
3) Inputs and Controls HR4
Master Volume
The Master Volume allows trimming the speaker input gain when desired.
HR4
LED 1 –when illuminated indicates preset selected requires an analog signal
LED2 –when illuminated indicates preset selected requires an AES-EBU digital signal
LEDS 3 & 4 - will be illuminated or dark in combinations specified in the legend above
To indicate which of the 4 presets is currently active.
Preset 1 –default preset the speaker is shipped with. It is an analog input 2-way (full range)
configuration. Use Analog In XLR. (LED 1 on, LED 3 & 4 off).
Preset 2- Is an analog 3-way (85Hz 4th order L-R high pass filter) for use with a sub-woofer.
Use Analog In XLR (LED 1 on, LED 3 off / LED 4 on).
Preset 3 –Is an AES-EBU digital left input with 2-way response. Use Digital In XLR (LED 2 on, LED 3 on / LED 4 off).
Preset 4 –Is an AES-EBU digital right input with 2-way response. Use Digital In XLR
