Oce 9300 Manual de usuario

Océ 9300

User Manual

or transmitted in any form or by any means without written permission from

Océ.

Océ-Technologies B.V. makes no representation or warranties with respect to

the contents hereof and specifically disclaims any implied warranties of

merchantability or fitness for any particular purpose.

Further, Océ-Technologies B.V. reserves the right to revise this publication and

to make changes from time to time in the content hereof without obligation to

notify any person of such revision or changes.

Edition 2.0

Océ-Technologies B.V.

This manual contains a description of the Océ 9300 system and a detailed

explanation of the plot functions. The introduction (chapter 1), gives a general

description of the working methods employed in using the copier and we

recommend that you read at least this chapter.

Safety information

This manual contains the following safety information:

■Appendix C lists ‘Instructions for safe use’. We advise you to read this

information before you start to actually use the copier. Technical safety

information such as safety data sheets can also be found in appendix C.

■Where applicable, cautions and warnings are used throughout this manual to

draw your attention to the safety precautions which you should follow.

Trademarks

PostScript is a trademark of Adobe Systems Inc.

HP-GL, HP-GL/2, HP-RTL are trademarks of Hewlett Packard Company.

Microsoft, MS, and MS-DOS are registered trademarks of Microsoft

Corporation.

MS-Windows is a trademark of Microsoft Corporation.

CalComp is a trademark of California Computer Products Inc.

TIFF is a trademark of Aldus Corporation.

CALS is a military standard.

Table of Contents 3

Table of Contents

Chapter 1

Getting started

The Océ 9300 printer 8

The printer operating panel 9

Buttons 10

Display 11

Turning the printer on or off 12

Chapter 2

Installing the printer

Connect the printer to your host environment 14

Centronics 15

Serial 16

Handshake protocol 16

Baud rates 17

Bits combination 18

Serial parity and stop bits 18

Port type 19

Turnaround delay 20

Inter-character delay 21

Configuring the printer's memory 22

Input buffer 22

Bitmap buffer 23

Chapter 3

(Re)load media and toner

Inserting a new print media roll 26

Automatic roll switching 26

Reloading rolls 27

Cutting print media to attain a straight leading edge 30

Printing using the manual feed 33

Programming media settings 34

Refilling toner 37

4 Océ 9300 User Manual

Chapter 4

Printing files

Printing files 40

Océ application 41

Océ drivers 41

Cut method 42

Plot Center 42

Leading/trailing edge 43

Demo plot 44

Cancel plot 44

Chapter 5

Customizing defaults

Defining pen settings 46

Defining language settings 48

Automatic language sensing 48

Data format recognition 49

Manual data format selection 50

Océ languages (VDF/BGL) 51

Océ print origin 51

Océ step size 52

Océ pen priority 53

HP-GL 54

HP-GL print origin 54

HP-GL page advance 54

Merge mode 55

HP-GL/2 56

HP-GL/2 print origin 56

HP-GL/2 page advance 56

HP-GL/2 pen priority 57

Designjet compatibility 58

Merge mode 58

Line Attribute 59

HP-RTL 60

CalComp 61

CalComp print origin 61

Checksum parameter 62

CalComp pen priority 62

Merge mode 63

End of Message parameter 63

Synchronization code parameter 64

Double synchronization code parameter 65

CalComp step size 66

Table of Contents 5

Raster formats 67

CALS 67

NIRS 67

TIFF 67

C4 (EDMICS) 67

PostScript level 2 68

PostScript data format selection 68

Manual data format selection 68

PostScript page layout 69

Default PostScript page size 69

Chapter 6

Advanced menu functions

Introduction 72

End of plot time out 73

Selecting the media saver 74

Nesting 74

Autoposition 76

Media saver time-out 77

Flush media saver 77

Media saver plot size 78

Replot 79

Setting the number of copies 79

Quality setup 80

Poster mode 80

Rendering 81

Image type 82

Transformation 83

Print rotation 83

Print scaling 83

Autoscaling 84

Password 87

Dump configuration 88

Service 89

Chapter 7

Solving problems

Solving problems 92

Printer warnings 92

Operator recoverable errors 93

Clearing paper jams 94

Machine-recoverable errors 96

6 Océ 9300 User Manual

Appendix A

Overview and tables

Product specifications 98

Interfaces 99

Centronics protocol 99

Serial protocols 99

Ethernet protocol 100

Centronics port configuration 101

Serial port configuration 102

Print media that can be used 103

Appendix B

Hardware components and operating panel

Océ 9300 106

Operating panel 107

Appendix C

Safety information

Instructions for safe use 110

Safety data sheets 111

Safety data sheet Océ 9300 printer 112

Appendix D

Miscellaneous

How to read this manual 114

User survey 115

Addresses of local Océ organizations 117

Index 119

Océ 9300

User Manual

Chapter 1

Getting started

This chapter contains a general description Océ 9300 of

how to install and set up the printer to be ready for use.

8 Océ 9300 User Manual

The Océ 9300 printer

The Océ 9300 is a wide-format printing system. The machine is equipped with

an automatic 1- or 2-roll dispenser. The Océ 9300 prints on paper,

transparencies, vellum, and polyester film. Its powerful digital technology

offers users optimal ease of use and the reliability that you have come to expect

of Océ.

The following are some of the features included in this machine:

■automatic language sensing and remote control

■multiple interfaces

■fast, high quality printing

■autoscaling of vector data

■media saver

Optional features:

■automatic 2-roll unit

■memory extension modules

■PostScript level 2

■Ethernet interface

■high-capacity delivery tray

Note: The optional features can vary from one country to another.

Getting started 9

The printer operating panel

The operating panel located on the right-hand side of the printer console is easy

to use (see figure 1). The panel consists of buttons and a display.

[1] Printer operating panel

During normal operation, the printer can process print jobs and provide a 2-line

display of the current printer status (e.g. ‘READY’’ or ‘RASTERIZING’’).

The buttons on the operating panel allow you to enter the Program mode and

easily set up the printer according to your requirements.

next/select

cancel/

continue

program

READY

10 Océ9300 User Manual

Buttons

‘Program’To activate the program mode and to enter the top level menu. In

this mode, the user can use ‘next/select’ the ‘previous’ and or buttons to

step through the menu.

Press‘Program’ again. If no action takes place for 1 minute in Program mode,

the machine will return to the status mode.

Note: If you press the Program button while the printer is printing, the LED

above the program button flashes. As soon as the printing process is ready, you

will automatically enter the program mode. Keep in mind that the printer will

not print in Program mode.

‘Next/select’To select an option or a setting in the menu. Or, if a submenu is

present, enter a lower-level menu.

‘Previous’Pressing this button takes you one level higher in the menu

structure.

Browse buttons or These two buttons are used to select another mode

at the same menu level, or to display the next or previous option from the

option list.

‘Cancel/continue’This button is used to cancel the current print job or to

continue after an operator-recoverable error.
