Oce TDS100 Manual de usuario

Océ TDS100

User manual

or transmitted in any form or by any means without written permission from

Océ.

Océ-Technologies B.V. makes no representation or warranties with respect to

the contents hereof and specifically disclaims any implied warranties of

merchantability or fitness for any particular purpose.

Further, Océ-Technologies B.V. reserves the right to revise this publication and

to make changes from time to time in the content hereof without obligation to

notify any person of such revision or changes.

Edition 2005-02

Océ-Technologies B.V.

Trademarks

Products in this manual are referred to by their trade names. In

most, if not all cases, these designations are claimed as trademarks

or registered trademarks of their respective companies.

Notes for the reader

Introduction

This manual helps you to use the Océ TDS100. The manual contains a

description of the Océ TDS100 and guidelines to use and operate the Océ

TDS100. There are also tips to increase your knowledge of the Océ TDS100

and to help you manage the workflow even better.

Definition

Attention Getters

Parts of this manual require your special attention. These parts provide

important, additional information or are about the prevention of damage to

your properties.

Note, Attention and Caution

The words Note, Attention and Caution indicate these important parts.

■The word Note comes before additional information about the correct

operation of the Océ TDS100 or before a hint.

■A part marked with Attention contains information to prevent damage to

items, for example the Océ TDS100 or a file.

■A part marked with Caution contains information to prevent personal

injury.

Safety information

The safety information for this product is included in a separate manual with

the title Safety manual. This manual is part of the documentation set that you

received with your product.

4 User manual

Contents 5

Contents

Notes for the reader 3

Chapter 1

Introduction to the Océ TDS100

The documentation set 8

The configurations 9

The components 10

The operator panel of the automatic 1 roll and 2 roll feed configuration 12

The operator panel of the sheet feed, multi copy configuration 16

The operator panel of the sheet feed, single copy configuration 19

Chapter 2

Use the Océ TDS100

Turn on and off the Océ TDS100 22

Turn on and off the optional dew preventer 24

Copy on a media roll (automatic roll feed) 25

Copy on cut sheet media (manual sheet feed) 27

Adjust leading and trailing strips 29

Improve the copy quality of dark and light originals 32

Check the copy quality with a test strip 33

Straighten the edge of a media roll 34

Chapter 3

Maintain the Océ TDS100

Understand message codes 36

Add toner 38

Clear an original jam 41

Clear a media jam 43

Replace a media roll 46

Clean the transparent plate 51

Appendix A

Overview and tables 53

Default values 54

Product specifications 55

Supported original types and sizes 56

Supported media types and sizes 57

6 User manual

Appendix B

Miscellaneous 59

Reader's comment sheet 60

Addresses of local Océ organisations 62

Océ TDS100

User manual

Chapter 1

Introduction to the Océ TDS100

8 User manual

The documentation set

Introduction

This manual is a part of a documentation set. The following table displays the

complete list.

Overview of the complete documentation set

Note: Visit Océ on the internet at www.oce.com for more information.

Document Publication

medium

Contents

Safety

manual

Paper book ■Instructions for safe use.

■Safety data sheets.

Quick

reference

guide

Paper book ■A short description on how to operate the

Océ TDS100.

User

manual

CD-ROM ■A complete description on how to operate

and maintain the Océ TDS100.

Introduction to the Océ TDS100 9

The configurations

Introduction

The Océ TDS100 is a wide format copier to copy large drawings. The Océ

TDS100 is available in four different configurations. The following table

displays these configurations with their functions and options.

Functions and options per configuration

[1] The Océ TDS100 configurations

Configuration Functions Options

Sheet feed,

single copy

■Manual sheet feed

■Single copy

■Original length measuring

■Reproduction scale 1:1.

■Stand

■A1 shelves and stand.

Sheet feed,

multi copy

■Manual sheet feed

■Multi copy

■Trailing strip

■Original length measuring

■Reproduction scale 1:1.

■Stand

■A1 shelves and stand

■1-roll upgrade kit

■2-roll upgrade kit

■Dew preventer.

Automatic 1 roll

feed

■Automatic 1-roll media

feed

■Multi copy

■Manual sheet feed

■Trailing strip

■Leading strip

■Test strip

■Original length measuring

■Reproduction scale 1:1.

■2-roll upgrade kit

■Dew preventer.

This configuration comes

default with a stand.

Automatic 2 roll

feed

■Automatic 2-roll media

feed

■Multi copy

■Manual sheet feed

■Trailing strip

■Leading strip

■Test strip

■Original length measuring

■Reproduction scale 1:1.

■Dew preventer.

This configuration comes

default with a stand.

10 User manual

The components

Introduction

The following illustration displays the most complete configuration of the Océ

TDS100, the automatic 2 roll feed configuration. Some options may not be

available on your TDS100 due to the differences between the configurations.

Illustration

[1] The automatic 2 roll feed configuration of the Océ TDS100

The components and functions of the Océ TDS100

Nr. Component Function

1 On / off switch Turn on and off the Océ TDS100.

Note: The on / off switch is not visible in the

illustration.

2 Operator panel Set up, start and control the copy jobs.
