O2 Xda Manual de usuario

O2 ODM 00 –

Paul Mayes 3

17.02.09 127x127 100

We’re better, connected

Quick Start Guide

Xda Guide

O2 ODM 00 –

Paul Mayes 3

17.02.09 127x127 100

We’re better, connected

Welcome to the ø Xda Guide

Use this booklet to get your Xda Guide

up and running fast.

O2 ODM 00 –

Paul Mayes 3

17.02.09 127x127 100

Your new Xda Guide

What’s in the box? 1

Tour of the Xda Guide 3

Inserting your sim card 6

Installing the battery 6

Installing a microSD™ card 7

Charging the battery 8

Assembling the in-car holder 9

Get connected

Switching on 11

Connection settings 12

The TouchFLO™ home screen 13

Making the first call 15

Typing text 16

Basic settings 17

Adding favourite contacts 21

Sending a text message 23

Sending an MMS message 23

HTC Footprints™ 24

Using Wi-Fi 27

Setting up an internet email account 28

Mobile internet 30

Bluetooth 31

Appointments 33

Things to do 34

Taking photos and shooting videos 35

Viewing photos and videos 36

Connecting to a computer 39

Synching your Xda Guide with

your computer 41

Copying files to your Xda Guide 43

Synching music files 44

Listening to music 45

Resetting your Xda Guide 46

Contents

O2 ODM 00 –

Paul Mayes 3

17.02.09 127x127 100

Your new Xda Guide

What’s in the box?

Xda Guide handset Battery

Power adaptor

Screen protector

Wired stereo headset

USB cable

Pouch

In-car holder

Car charger

1GB MicroSD™ card

O2 ODM 00 –

Paul Mayes 3

17.02.09 127x127 100

Quick Start Guide

Getting Started CD

Getting Started Disc

Includes: Windows MobileTM software

Microsoft® ActiveSync® 4.5 (for XP)

Windows Mobile Device Center (for Vista)

Microsoft® Outlook® 2007 60-day trial

Full User Manual

2008 Microsoft Corporation

Xda Guide

We’re better, connected

Quick Start Guide

Xda Guide

O2 ODM 00 –

Paul Mayes 3

17.02.09 127x127 100

Tour of your ø Xda Guide

LED indicator status

Green – Battery is fully-charged

Flashing green – SMS, MMS or email reminders

Amber – Battery is charging

Flashing amber – Battery level is low

Speaker

Back Cover

Strap Holder

Earpiece

receiver

LCD Touch

Screen

Notification LED

HTC Footprints

GPS

Talk / Send End Key

Navigation Key

with Enter button

Speaker

Back Cover

Strap Holder

3.2 Megapixel Camera

Power

Microphone

Sync Connector

O2 ODM 00 –

Paul Mayes 3

17.02.09 127x127 100

Stylus

Volume Down

Volume Up

O2 ODM 00 –

Paul Mayes 3

17.02.09 127x127 100

Inserting your sim card

Before you start using your Xda Guide you’ll need to insert your sim card. This contains

your mobile phone number.

Make sure the Xda Guide is turned off.

Remove the back cover by using your thumb or finger to

lift it from the bottom.

Remove battery. Look for the sim card slot (top right of

the space) and place the sim card in it with the gold

contacts facing down and the cut-off corner matching

the shape of the slot.

Slide the sim card completely into place.

Installing the battery

Line up the battery’s copper contacts with the connectors in

the battery compartment and push it into place.

Make sure that the free end of the ribbon is showing above the

battery (you will use this to pull the battery out again when you

need to).

Replace the back cover.

Installing a microSD™ card

Using a microSD card gives you additional memory to store anything you want.

We’ve included one with your Xda Guide which contains map data for the CoPilot®

(Sat Nav) application, but you can use the available space on it to store other things,

such as photos and music files.

Remove the back cover and you’ll see the microSD slot on the top right above the

battery compartment.

Slide in the microSD card with the gold contacts facing down and make sure it clicks

fully into place.

To remove, press the microSD card until it clicks and releases.
