18 slot PXIe System
User‘s Manual
Product Number:
14579-040
Doc-No. 63972-381_R1.5 January 2021
Impressum:
Schroff GmbH
Langenalber Str. 96 - 100
75334 Straubenhardt, Germany
The details in this manual have been carefully compiled and
checked - supported by certified Quality Management System
to EN ISO 9001/2000
The company cannot accept any liability for errors or misprints.
The company reserves the right to amendments of technical
specifications due to further development and improvement of
products.
Copyright2021
All rights and technical modifications reserved.
R1.0 July 2019 Preliminary release
R1.1 February 2020 Manual supplemented
R1.2 March 2020 Minor corrections
R1.3 April 2020 Front panel added
R1.4 October 2020 Updated
R1.5 January 2021 Clock specifications added
14579-040 (PXIe System)
R1.5, January 2021 I
1 Safety ....................................................................................................................... 1
1.1 Safety Symbols used in this document.............................................................................. 1
1.2 General Safety Precautions ............................................................................................... 1
1.3 References and Architecture Specifications...................................................................... 2
2 Product Overview ..................................................................................................... 3
2.1 Key features ...................................................................................................................... 3
2.2 System Overview............................................................................................................... 4
3 18 Slot PXIe Backplane (23007-518) .......................................................................... 5
3.1 Backplane Topology .......................................................................................................... 6
3.2 PCIe-to-PCI bridge ............................................................................................................. 7
3.3 PCIe Switch........................................................................................................................ 7
3.4 System Synchronisation Clocks ......................................................................................... 8
3.4.1 Clock specifications............................................................................................ 9
3.5 Schroff PXIe Chassis Management Module (CMM) ........................................................ 10
3.5.1 Chassis status LED............................................................................................ 11
3.6 PXI Trigger Bus ................................................................................................................ 12
3.7 Power Supply................................................................................................................... 13
3.7.1 Available electrical power................................................................................ 14
3.7.2 Per slot power.................................................................................................. 15
3.7.3 Grounding/Earthing ......................................................................................... 15
3.8 Power-on behaviour........................................................................................................ 16
3.9 Voltage monitoring ......................................................................................................... 16
4 Cooling ................................................................................................................... 17
4.1 Temperature Settings...................................................................................................... 18
4.1.1 Maximum cooling ............................................................................................ 18
5 System Controller ................................................................................................... 19
5.1 Fan Speed and Trigger Bridge settings ............................................................................ 20
5.2 General Installation Guidelines ....................................................................................... 21
5.2.1 Unpacking ........................................................................................................ 21
5.2.2 Ensuring Proper Airflow................................................................................... 21
5.3 Initial Operation .............................................................................................................. 21
6 Service.................................................................................................................... 22
6.1 Technical support and Return for Service Assistance ..................................................... 22
6.2 Scope of Delivery............................................................................................................. 23
6.3 Accessories...................................................................................................................... 23
6.4 Spare Parts ...................................................................................................................... 23
7 Technical Data ........................................................................................................ 24
8 Dimensions............................................................................................................. 25
14579-040 (PXIe System)
II R1.5, January 2021
14579-040 (PXIe System)
R1.5, January 2021 Safety 1
1 Safety
The intended audience of this User’s Manual is system integrators and hardware/software
engineers.
1.1 Safety Symbols used in this document
1.2 General Safety Precautions
• Service personnel must know the necessary electrical safety, wiring and connection
practices for installing this equipment.
• Install this equipment only in compliance with local and national electrical codes.
Hazardous voltage!
This is the electrical hazard symbol. It indicates that there are dangerous voltages inside the
Shelf.
Caution!
This is the user caution symbol. It indicates a condition where damage of the equipment or
injury of the service personnel could occur. To reduce the risk of damage or injury, follow all
steps or procedures as instructed.
Danger of electrostatic discharge!
Static electricity can damage sensitive components in a system. To avoid damage, wear ESD
wrist straps or at regular intervals touch blank enclosure parts.
Warning!
Voltages over 60 VDC can be present in this equipment. This equipment is intended to be
accessed, to be installed and maintained by qualified and trained service personnel only.
This equipment is designed in accordance with protection class 1!
It must therefore be operated only with protective GND/earth connection!
14579-040 (PXIe System)
2Safety R1.5, January 2021
1.3 References and Architecture Specifications
• PXI-5 (PCI EXPRESS eXtensions for Instrumentation)
• User Manual Schroff embedded Controller, Ord.-No: 63972-389
• User Manual PXIe Chassis Management (CMM), Ord.-No: 63972-391
14579-040 (PXIe System)
R1.5, January 2021 Product Overview 3
2 Product Overview
2.1 Key features
• Shielded 4 U Schroff ratiopacPRO-air case with mounting brackets for 19“ rack mounting
and front handles and tip-up feet for desktop use
• 84 HP / 18 slot front card cage for 3 U boards
• 18 slot 3 U backplane with:
- 1 PXIe system slot 4 - 12 HP
- 1 PXIe timing slot 4 HP
- 16 PXI Express Hybrid slots 4 HP accepting PXIe modules according to the PXI Express
(PXI-5) standard as well as PXI, CompactPCI, CompactPCI Express modules
• BNC connectors for 10 MHz clock input/output at the rear side
• Integrated power supply (1200 W) with wide range input
• Power input module with IEC 60320-C14 connector, mains/line switch, mains/line filter
and fuses
• 3x 120 mm Fans for the active cooling of the boards and the power supply, controlled and
monitored by the Chassis Monitoring Module (CMM)
• Power switch with chassis status LEDs at the front side
The system 14579-040
is described as an example below in this manual.
The system can be modified with various backplane configurations.
All pictures in this manual may differ from the latest series.
14579-040 (PXIe System)
4Product Overview R1.5, January 2021
2.2 System Overview
The 4 U case is based on the Schroff ratiopacPRO-air system with EMC shielding. The 3 U card
cage provides 1 system slot (4 - 12 HP), 1 timing slot (4 HP) and 16 peripheral slots (4 HP).
The lower guide rails of the card cage are equipped with ESD clips.
Figure 1: Front and Rear View
1PS-ON Switch with Chassis Status LEDs 7DSUB-9 Connector, female, Inhibit and voltage
monitoring
2Filler Panels 4/8 HP System Slot Extension 8BNC Connectors 10 MHz REF clock in/out
3PXIe Backplane 9Fans/Air Outlet
4Air Intake 10 Fan Speed Selector
5Power Input Module 11 Inhibit Mode Selector
6Ground stud (M5)
14579-040 (PXIe System)
R1.5, January 2021 18 Slot PXIe Backplane (23007-518) 5
3 18 Slot PXIe Backplane (23007-518)
The PXIe backplane provides:
•1PXIesystemslot
•1PXIetimingslot
• 16 PXIe Hybrid slots
- accepting CompactPCI, PXI, CompactPCI Express, and PXIe modules
• 2 PCIe-to-PCI high performance bridges
- utilize a single PCI segment for the hybrid slots
- designed to the PCI Express-to-PCI Bridge Specification 1.0 that enables applications to
migrate legacy parallel PCI bus interfaces to the advanced serial PCI Express
- each bridge is equipped with a single lane PCI Express port and a parallel bus segment
supporting the conventional PCI operation for up to eight PCI peripheral devices con-
currently.
- Primary Bus: x1 PCI Express Base Specification R1.1 compliant
- Secondary Bus: 33 MHz/32 bit PCI Local Bus Specification R3.0 compliant
• All PXIe hybrid slots with 32 bit 33 MHz PCI interface.
• 1 PXIe clock module
- generates and controls PXI specific high accuracy clocks and trigger signals.
• 4 ultra-high performance PCIe switches that operates with up to Gen 3 speeds.
• All PXIe hybrid and the timing slots have an x4 PCIe link providing a maximum data band-
width of 4 GB/s each.
14579-040 (PXIe System)
618 Slot PXIe Backplane (23007-518) R1.5, January 2021
3.1 Backplane Topology
Figure 2: Backplane Topology
