Numatic NX300 Manual de usuario

Original Instructions

CAUTION, Read instructions before using the machine.

Översättning av den ursprungliga användarhandboken

VARNING, Läs anvisningarna innan du använder maskinen.

numatic.com

GBGB

NUC244NX

COMPACT

SCRUBBER DRYER

GBGB//SESE

KOMPAKT

KOMBISKURMASKIN

In the event of a breakdown contact

your Numatic dealer

Machine Overview ................................. Pages 2 & 3

Control Panel Overview ................................. Page 4

Quick Set up Guide ................................. Page 5

Brush tting ................................. Page 5

Floor tool and vacuum hose tting.................... Page 5

Main tank assembly removal............................ Page 5

Clean water tank removal & lling .................... Page 6

Battery tting & water ow setting .................... Page 7

Machine handle operation ............................... Page 8

Storage & Transportation ................................. Page 9

Regular maintenance ................................. Page 10

Separator removal & cleaning ........................ Page 10

Clean water tank outlet cleaning .................... Page 10

Float valve removal & cleaning ........................ Page 11

Emptying Tanks ................................. Page 11

Changing the oor-tool blades .................... Page 12

Retting the oor-tool blades ........................... Page 12

Battery removal & charging........................... Page 13

Removing the battery ................................. Page 13

Battery Charging ................................. Page 13

Twintec Maintenance ................................. Page 13

Specications ................................. Page 14

Troubleshooting ................................. Page 14

Rating Label / Personal Protective Equipment /

Recycling ................................. Page 15

Information for Scrubber Dryer..................... Page 16

Recommended Spare Parts ........................... Page 17

Schematic Diagram ................................. Page 17

Lithium-Ion Battery Warranty............................ Page17

EU Declaration Document .............................. Page 17

Company Address ................................. Page 36

Index

After the removal of all the packaging,

carefully open and check the contents

● Owner Manual

● Battery Charger & Lead

● Battery Pack ● Scrub Brushes x 2

● Squeegee Assembly

PLEASE READ

BEFORE COMMENCING

OPERATION.

KEEP FOR FUTURE REFERENCE

Machine Overview

1Operator control panel

2Triggers

3Waste-water tank

4Clean-water tank

5Brush deck

6Squeegee blades

7Clean water ow adjustment taps

8Clean-water lling / emptying cap

9Floor-tool vacuum hose

10 Vacuum hose

11 Separator

12 Battery

13 Battery charger

14 Clean tank ll view windows

15 Storage lever

16 Floor-tool release lever

17 Transport / Storage wheels

Machine Overview

1Battery Charge Level Meter

2Vacuum On / O󰀨

3Water Flow On / O󰀨

4Triggers

5Handle Lock Button (In the upright position)

6Handle Release Lever

7Start Button

Control Panel Overview

In the event of a breakdown contact

your Numatic dealer

Floor tool and vacuum hose tting

Main tank assembly removal

NUC244NX CONTENTS

● Owner Manual

● Battery Charger & Lead

● Battery Pack

● Scrub Brushes x 2

● Squeegee Assembly

Remove the tank assembly from the front of

the machine. Using the inset handle on the

front of the tank assembly (A), lift the tank

assembly up towards the main handle.

Lift and tilt the top of the tank assembly away from the handle as you remove. Place

the tank assembly on a suitable surface in its upright/uppermost position.

Push the brush / pad holder onto the

brush motor mounts (1 & 2). Note: Gloves

are recommended to be worn whilst tting

and removing the brushes.

Make sure the handle is locked in upright

position and storage wheels are retracted.

Remove the tank assembly (and battery if

tted) gently lay machine on its front

To remove the brushes, place your ngers

behind the brush deck in locations shown

and gently wiggle o󰀨.

Make sure battery is removed

before tting or removing brushes.

Push the oor tool carrier handle down and push the oor tool onto the retaining clips (1 & 2).

Take the hose and t it into the hose retaining clips then push the open end securely over the centre tting on the oor tool. Follow

the arrows for the correct t. Make sure part (A) of the hose stays loose and is not over stretched.

Quick Set-up Guide

PLEASE READ BEFORE COMMENCING ANY

OPERATION AFTER THE REMOVAL OF ALL THE

PACKAGING, CAREFULLY OPEN AND CHECK THE

CONTENTS.

! !

Brush Fitting

Pour in the chemical (follow chemical manufactures dilution rates). Only ll the tank to the MAX ll line with clean water using a tap,

hose or suitable water container. DO NOT OVER FILL. Slide the tank back into the main tank body, make sure the front of the clean

water tank is lifted to enter the recess (A).

Push the tank all the way in until you hear it click, make sure it is securely tted before tting the tank assembly back on the machine.

Remove the clean water tank from the main body of the tank holder (4&5). To ll remove the rubber stop from the lling neck.

Note: There is a T piece keeping the rubber stop from being completely removed.

Slide your hand under the tank and curl

your ngers up in the space in front of the

tank, use your ngers to pop the tank out.

Remove the clean water tank from the

main body of the tank holder.

Over head cut away viewOver head cut away view

After lifting onto a suitable work surface,

tilt the tank assembly slightly forward and

slide your hand under the tank.

Quick Set-up Guide

Clean water tank removal and lling

Lift the battery using the battery handle.

Place the battery into the battery

compartment ensuring it is securely

in place and the orientation is correct

(battery handle folds down towards the

machine handle (A)).

Ret the main tank onto the machine.

Tilt the bottom of the tank towards the

handle above the battery.

Line the tank up against the machine

handle and lower the tank down. Make

sure it is securely tted.

Clean water tank full and tted to the

machine.

Located on the left and right side of the

machine are the individual water taps for

each brush.

Push the uid control levers on the

Left and Right of the machine to set

the desired ow required, this will vary

depending on what brush / pad and oor

type the machine is being used on.

Note: On rst use open the water taps fully

and run the machine for a short period to

purge the water ow then adjust taps to

desired ow. Make sure each lever is set

to the same position.

Quick Set-up Guide

Battery tting and water ow settings

Trigger

Machine Handle Operation

To start the machine pull one or both triggers in and press the start button with the deck down, this will start the brushes spinning

and the battery power indicator will illuminate to show the power level.

With either trigger pulled in press the water on button, this lights

up blue to indicate it is on.

Press the vacuum on button, this lights up blue to indicate it is on

and the vacuum starts. You are now ready to start cleaning.

Trigger Start button

Water On / O󰀨 Vacuum On / O󰀨

To lower the oor-tool, press down on the left foot pedal lever at the rear of the machine (8-A).

To lower the machine deck to the ground. Stand behind the machine, grip the handles.

With your right foot push the right pedal forward (9-B). (By pushing lever the front support

wheel retracts under the deck (9-C)).

Pull the small lever on the right hand side of the handle upwards (10-D) and then pull the

handle backwards.

To raise the oor-tool (for over-scrubbing without picking up water) use the toecap

locations to the rear of the oor-tool (E or F).

Quick Set-up Guide

To put the machine into storage mode start with the handle locked in the upright position and the oor-tool down (1), pull the handle

backwards until the oor-tool moves up and the transport wheels click out into position the front support wheel is deployed (2).

Rest the machine back onto the transport wheels (3).

(no button or lever action is required). Note: Do not let go of the handle.

To raise the oor-tool use the toecap locations to the rear of the oor-tool and lift up (A). To raise the machine deck o󰀨 the ground.

Stand behind the machine, grip the handle. With your right foot push the right pedal down (B) while pulling the machine backwards until

the storage wheels click into position and the front support wheel extends.

Storage and Transport mode option 1

Storage and Transport mode option 2

Make sure the handle is in the upright position and locked in place, push the handle lock button and locate handle in correct position.

Handle lock

button

Storage and Transport

!! MAKE SURE THE HANDLE IS LOCKED IN THE UPRIGHT POSITION

BEFORE LETTING GO OF THE HANDLE.

Once the separator has been removed, wash thoroughly under a

tap making sure to run water through the tubes and to clean the

grid lter (A).

Once clean thoroughly check the rubber seal for any damage or

cracks (B).

If any damage or cracks are found on the rubber seal replace

the separator. Failure to replace could cause loss in suction and

machine performance.

Using thumb and index nger grip the tab of the

separator and pull forwards.

Make sure the clean water tank is empty.

Unscrew the two clean water outlets, A

and B.

Remove the clean water outlets from the

clean water tank.

Wash the clean water outlets thoroughly

under a tap, make sure the lter is clean

with no blockages. Check for any damage

(if any damage is found replace the clean

water outlets).

Lift the separator away from the tank. Take the separator to a suitable cleaning station.

Regular Maintenance

Separator removal and cleaning

Clean water tank outlets
