Numatic NUC244NX Manual de usuario

DRAFT

Caution! Read instructions before using the machine

Original Instructions

NUC244NX

COMPACT SCRUBBER DRYER

www.numatic.com

DRAFT

COMPACT SCRUBBER DRYER

Index

After the removal of all the packaging,

carefully open and check the contents

● Owner Manual

● Battery Charger & Lead

● Battery Pack ● Scrub Brushes x 2

● Squeegee Assembly

PLEASE READ

BEFORE COMMENCING

OPERATION.

KEEP FOR FUTURE REFERENCE

NUC244NX

Machine Overview ................................. Pages 1 & 2

Control Panel Overview ................................. Page 3

Quick Set up Guide ................................. Page 4

Brush tting ................................. Page 4

Main tank assembly removal............................ Page 4

Clean water tank removal & lling .................... Page 5

Battery tting & water ow setting .................... Page 6-7

Machine handle operation ............................... Page 7

Storage & Transportation ................................. Page 8

Regular maintenance ................................. Page 9

Separator removal & cleaning ........................ Page 9

Clean water tank outlet cleaning .................... Page 9

Float valve removal & cleaning ........................ Page 10

Emptying Tanks ................................. Page 10

Changing the oor-tool blades .................... Page 11

Retting the oor-tool blades ........................... Page 11

Battery removal & charging........................... Page 12

Removing the battery ................................. Page 12

Battery Charging ................................. Page 12

Twintec Maintenance ................................. Page 12

Specications ................................. Page 13

Troubleshooting ................................. Page 13

Rating Label / Personal Protective Equipment /

Recycling ................................. Page 14

Safety Precautions ................................. Page 15

Recommended Spare Parts ........................... Page 16

Schematic Diagram ................................. Page 16

EU Declaration Document .............................. Page 17

Warranty ................................. Page 18

Company Address ................................. Page 19

Machine Overview

1Operator control panel

2Triggers

3Waste-water tank

4Clean-water tank

5Brush deck

6Squeegee blades

7Clean water ow adjustment taps

8Clean-water lling / emptying cap

9Floor-tool vacuum hose

10 Vacuum hose

11 Separator

12 Battery

13 Battery charger

14 Clean tank ll view windows

15 Storage lever

16 Floor-tool release lever

17 Transport / Storage wheels

DRAFT

Machine Overview

DRAFT

COMPACT SCRUBBER DRYER

1Battery Charge Level Meter

2Vacuum On / O󰀨

3Water Flow On / O󰀨

4Triggers

5Handle Lock Button (In the upright position)

6Handle Release Lever

7Start Button

Control Panel Overview

In the event of a breakdown contact

your Numatic dealer or the

Numatic Technical

help line +44 (0)1460 269268

NUC244NX

www.numatic.com

Quick Set-up Guide

NUC244NX CONTENTS

● Owner Manual

● Battery Charger & Lead

● Battery Pack

● Scrub Brushes x 2

● Squeegee Assembly

Push the brush / pad holder onto the brush motor

mounts (1 & 2). Note: Gloves are recommended to

be worn whilst tting and removing the brushes.

Make sure the handle is locked in upright position

and storage wheels are retracted. Remove the tank

assembly (and battery if tted) gently lay machine

on its front

To remove the brushes, place your ngers behind

the brush deck in locations shown and gently

wiggle off.

Take the hose and t it into the hose retaining clips

then push the open end securely over the centre

tting on the oor tool. Follow the arrows for the

correct t. Make sure part (A) of the hose stays

loose and is not over stretched.

Push the oor tool carrier handle down and push the oor tool onto the retaining clips (1 & 2).

Remove the tank assembly from the front of the

machine. Using the inset handle on the front of

the tank assembly (A), lift the tank assembly up

towards the main handle.

Lift and tilt the top of the tank assembly away from the handle as you remove. Place the tank assembly

on a suitable surface in its upright/uppermost position.

PLEASE READ BEFORE COMMENCING ANY OPERATION. AFTER THE REMOVAL OF

ALL THE PACKAGING, CAREFULLY OPEN AND CHECK THE CONTENTS. !!

Floor tool and vacuum hose tting

Main tank assembly removal

Brush tting - Make sure battery is removed before tting or removing brushes.

5www.numatic.com

Quick Set-up Guide

Pour in the chemical (follow chemical manufactures dilution rates). Only ll the tank to the MAX ll line with clean water using a tap, hose or suitable water

container. DO NOT OVER FILL. Slide the tank back into the main tank body, make sure the front of the clean water tank is lifted to enter the recess (A).

Push the tank all the way in until you hear it click, make sure it is securely tted before tting the tank assembly back on the machine.

After lifting onto a suitable work surface, tilt the

tank assembly slightly forward and slide your hand

under the tank.

Remove the clean water tank from the main body of the tank holder (4&5). To ll remove the rubber stop from the lling neck.

Note: There is a Tpiece keeping the rubber stop from being completely removed.

Slide your hand under the tank and curl your

ngers up in the space in front of the tank, use your

ngers to pop the tank out.

Remove the clean water tank from the main body of

the tank holder.

Clean water tank removal and lling

Over head cut away viewOver head cut away view

www.numatic.com

Quick Set-up Guide

Battery tting and Water ow setting

Lift the battery using the battery handle. Place the battery into the battery compartment ensuring it is

securely in place and the orientation is correct (battery handle folds down towards the machine handle (A)).

Tilt the bottom of the tank towards the handle

above the battery.

Located on the left and right side of the machine

are the individual water taps for each brush.

Line the tank up against the machine handle and

lower the tank down. Make sure it is securely tted.

Ret the main tank onto the machine.

Clean water tank full and tted to the machine.

Push the uid control levers on the Left and Right of the machine to set the desired ow required, this will

vary depending on what brush / pad and oor type the machine is being used on. Note: On rst use open

the water taps fully and run the machine for a short period to purge the water ow then adjust taps to

desired ow. Make sure each lever is set to the same position.

7www.numatic.com

Quick Set-up Guide

To start the machine pull one or both triggers in and press the start button with the deck down, this will start the brushes spinning and the battery power

indicator will illuminate to show the power level.

With either trigger pulled in press the water on button, this lights up blue to

indicate it is on.

Press the vacuum on button, this lights up blue to indicate it is on and the

vacuum starts. You are now ready to start cleaning.

Trigger Start button Trigger

Water On / O󰀨 Vacuum On / O󰀨

To lower the oor-tool, press down on the left foot pedal lever at the rear of the machine (10-A).

To lower the machine deck to the ground. Stand behind the machine, grip the handles. With your right foot

push the right pedal forward (11-B). (By pushing lever the front support wheel retracts under the deck (11-C)).

Pull the small lever on the right hand side of the handle upwards (12-D) and then pull the handle backwards.

To raise the oor-tool (for over-scrubbing without picking up water) use the toecap locations to the rear of

the oor-tool (E or F).

Machine handle operation

www.numatic.com

Storage and Transport

To put the machine into storage mode start with the handle locked in the upright position and the oor-tool down (1), pull the handle backwards until the oor-

tool moves up and the transport wheels click out into position the front support wheel is deployed (2). Rest the machine back onto the transport wheels (3)

(no button or lever action is required). Note: Do not let go of the handle.

MAKE SURE THE HANDLE IS LOCKED IN THE UPRIGHT POSITION

BEFORE LETTING GO OF THE HANDLE. !!

To raise the oor-tool use the toecap locations to the rear of the oor-tool and lift up (A). To raise the machine deck off the ground. Stand behind the machine, grip

the handle. With your right foot push the right pedal down (B) while pulling the machine backwards until the storage wheels click into position and the front support

wheel extends.

Storage and Transport mode option 1

Storage and Transport mode option 2

Make sure the handle is in the upright position and locked in place, push the handle lock button and locate handle in correct position.

Handle lock button

9www.numatic.com

Regular Maintenance

Once the separator has been removed, wash thoroughly under a tap

making sure to run water through the tubes and to clean the grid lter (A).

Once clean thoroughly check the rubber seal for any damage or cracks (B).

If any damage or cracks are found on the rubber seal replace the separator.

Failure to replace could cause loss in suction and machine performance.

Separator removal and cleaning

Clean water tank outlets

Using thumb and index nger grip the tab of the

separator and pull forwards.

Make sure the clean water tank is empty. Unscrew

the two clean water outlets, A and B.

Remove the clean water outlets from the clean

water tank.

Wash the clean water outlets thoroughly under a

tap, make sure the lter is clean with no blockages.

Check for any damage (if any damage is found

replace the clean water outlets).

Lift the separator away from the tank. Take the separator to a suitable cleaning station.
