radius

NS-NXT4/5a

RadiuS BaSS

Owner’s Manual

The contents of this document, including all graphics, are the property of NS Design. NS Design has made

every reasonable eort to ensure that all the information contained in this manual is correct at the time of

publishing. However, NS Design reserves the right to make any changes necessary without notice as part of

ongoing product development.

Radius™ is a trademark of NS Design

Visit NS Design at http://thinkns.com

NS-NXT4/5a Radius Bass Owner’s Manual

Overview (Front) 5

Overview (Back) 7

Dual (Active/Passive) Output Mode 9

Re-Stringing and Tuning 10

Setting Up the Bass 17

Setting the intonation ........................................................................................................................19

Setting the action ..............................................................................................................................21

Adjusting the truss rod ......................................................................................................................23

Speciﬁcations 24

Accessories 25

4 NS-NXT4/5a Radius Bass Owner’s Manual

Volume

Tone

(Push-Pull)

Overview (Front)

NS-NXT4/5a Radius Bass Owner’s Manual

Overview (Front)

Overview Features

1 Aluminum headplate with ball-end string mounting slots

2 Magnetic pickups (EMG) unique design matched to the fretboard radius

3 Bridge with one piece aluminum saddle

4 Tuner housing with self-clamping precision tuning system

5 Volume pot for neck pickup

6 Volume pot for bridge pickup

7 Tone pot with push-pull switch to select active or passive

output mode

8 Output jack also used to plug in power charger for active

output mode

6 NS-NXT4/5a Radius Bass Owner’s Manual

Overview (Back)

NS-NXT4/5a Radius Bass Owner’s Manual

Overview (Back)

Overview Features

9 Electronics compartment cover

10 String aperture

8 NS-NXT4/5a Radius Bass Owner’s Manual

Dual (Active/Passive) Output Mode

NS-NXT4/5a Radius Bass Owner’s Manual

Dual (Active/Passive) Output Mode

The NXTa Radius bass oers both active and passive

output. Select the desired output mode via the push-

pull function of the tone pot:

• Pull the tone knob up for active output

• Push the tone knob down for passive output

The battery-free dual output mode electronics are

of active operation from the time of charge. For

charging the bass before use:

1 Plug the power charger (supplied with the bass)

into a 120/240 V AC outlet.

2 Plug in the power charger 1/4" stereo plug into

the output jack and wait 60 seconds. For best

performance increase the charging time up to

120 seconds for the initial 2-3 charging cycles.

3 Unplug the power charger from the the bass and

the AC outlet.

10 NS-NXT4/5a Radius Bass Owner’s Manual

Re-Stringing and Tuning

This bass accepts any standard single-ball end,

full-scale bass guitar strings. The way the strings

are clamped leaves them undamaged and without

the usual windings on the end. This lets you easily

take them out (e.g. for cleaning) and put them back

on the bass as often as desired.

1 Turn the tuning knob fully counter-clockwise to

loosen the string, until the slotted tuning arm is

in the frontmost position (towards the bridge).

The clamping mechanism opens up and you can pull

the string(s) out.
