Nova Comet Manual

Travel in

comfort and style

ORTHO-MED, INC.

Commitment to Caring

NovaOrtho-Med.com

•Folds Easily

•Lightweight

•Padded for Comfort

Transport Chair Guidebook

This transport chair has not been approved as a seat surface to

be used within a vehicle.

Do not operate this wheelchair on streets or roadways.

Do not attempt inclines unassisted.

Engage the wheel locks upon entering or leaving the wheelchair.

Wheelchair must be on a level surface when transferring user to

or from seat.

Footrests should be no less than 21⁄2inches from the floor.

Do not stand on or put pressure on footrests when entering or

exiting the wheelchair.

Do not lean over the top of the wheelchair back. This can cause

the wheelchair to tip over.

Do not use the wheel locks to slow your descent down an incline.

When going down an inclined, changing directions can cause

instability.

WARNING

DO NOT ADJUST, MAINTAIN OR OPERATE THIS TRANSPORT

CHAIR WITHOUT READING, UNDERSTANDING AND FOLLOWING

THE PROPER INSTRUCTIONS INCLUDED WITH THIS PRODUCT.

Comet Series

Quick Release

Fold-Down

Back

Locking

Rear Wheels

Folding

straps

Removable

footrests

Padded

Upholstery

& Armrests

Folds quickly for easy

transport and storage

Non-skid footplates

Adjustable

hex screw

Usage Instructions

To Open

1. Pull armrests apart to unfold chair.

2. Swing folded-down back up and lock upright into place on back

supports.

3. Attach footrests on each side by inserting the holes onto the

vertical pegs of the frame. Swing footrests inward to lock in place.

To Fold

1. Push button release on both back uprights to fold back down

behind chair.

2. Pull folding straps on outer seat edges towards each other to fold

chair.

3. To remove footrests, pull silver release lever to unlock. Lift the

footrests off the hooks.

To Transfer Patient

1. Push forward on brake handle to lock rear wheels and secure chair

from rolling.

2. Swing footplates up to outer sides or turn both footplates upward

to a vertical position.

To Adjust Length of Footrests

1. Locate tool wrench included with the footrests.

2. Turn wheels so they are in the “wheeled” position (as pictured).

3. Use the tool wrench to slightly loosen the silver hex screw located

on the bottom of the footrests by turning the screw left.

4. Pull on the footplate to desired length. Footrests should be a

minimum of 21

/2" from the ground to ensure proper clearance.

5. Re-tighten the hex screw.

6. Repeat on other side.

Care and Maintenance

General Care

Wipe off all metal parts at least once a week using a soft cloth. Dry

chair immediately if it is exposed to moisture. Abrasive cleaners or

materials will scratch the surface of the chair.

Tires

Minimal maintenance is required for rubber tires. Wipe with a damp

cloth occasionally. If tires become cracked or worn, replace immedi-

ately.

Front Casters

Inspect casters periodically and lubricate them when necessary. To

lubricate, remove the fork and grease the caster bearings. Remove the

wheel from the fork and grease the wheel bearings. The wheel and

fork can be reassembled by tightening the nuts until there is no play

remaining, but the wheel rolls freely. The fork will revolve freely when

adjusted correctly. The caster will flutter if the nut is too loose or be

difficult to steer if the nut is too tight.

Wheels

Inspect monthly for correct tightness. If the wheel seems to be loose

or wobbly, release the lock nut and tighten the axle bolt. Lean chair to

one side and spin adjusted wheel to check for correct adjustments.

Wheel Locks

Wheel locks should be checked for correct locking action before actu-

al use. Pushing the handle completely forward activates the wheel

locks. If the wheel locks are working correctly they will be embedded

into the tire at least 1/8". To adjust wheel locks, loosen nut on carriage

bolt. Slide clamp toward rear wheel until lock shoe is embedded at

least 1/8" into rear tire when lock handle is engaged. Tighten nut to

secure into position.
