Small Concrete Saw

Models:

C914P

FORM: C914P rev 8-2020

WARRANTY

Norton warrants all products manufactured by it against defects in

workmanship or materials for a period of one (1) year from the date of

shipment to the customer.

The responsibility of Norton under this warranty is limited to

replacement or repair of defective parts at Norton's Gainesville,

Georgia factory, or at a point designated by it, of such part as shall

appear to us upon inspection at such point, to have been defective in

material or workmanship, with expense for transportation borne by the

customer.

In no event shall Norton be liable for consequential or incidental

damages arising out of the failure of any product to operate properly.

Integral units such as gasoline engines, electric motors,batteries,

tires, transmissions, etc., are excluded from this warranty and are

subject to the prime manufacturer's warranty.

This warranty is in lieu of all other warranties, expressed or implied,

and all such other warranties are hereby disclaimed.

Important: Before placing equipment in operation, record the following

information.

MODEL:_________ SERIAL NO.___________

PURCHASE FROM: _____________________

ADDRESS: ____________________________

CITY_______ STATE ______ ZIP ________

TELEPHONE NO. ______________________

Before using this equipment, make sure that any person using it

reads and understands the instructions in this owner’s manual.

Table of Contents

CONTENTS PAGE

I. Preparation 4-11

A. Safety Precautions 4-6

Dust and Silica Warning 5

B. Assembly 7-9

C. C914P Series Concrete Saw Specifications 10

D. Engine Precautions 11

E. Pointer Alignment 11

II. Operation 12-20

A. Blade Installation 12-16-

B. Starting The Engine 16-18-

C. Water Supply 18-19

D. Operating The Saw 19-20

E. Cutting Technique 20

III. Maintenance 21-

A. Engine 21-23

B. Wiring Diagram C914P 9 HP Honda 24

C. Bearings 25

D. V-Belts 25-32

Adjust The C914P Belt Tension 26-29-

Belt Alignment 29

Main Causes of Belt Failures 30

E. Depth Control 31-32

F. Inspection and Cleaning 32

IV. Parts List Section 32-48

A. Ordering Information 33

B. Parts Drawing and Service Parts List 34-48

Depth Control Group 34-35

Blade Guard Group 36-37

Blade Shaft and Engine Group 38-39

Main Frame and Pivoting Frame Group 40-41

Belt Guard Group 42

Handle Bar Group 43

Pointer Group 44

Water Tank Group 45-46

Decals 47-48

Read Owner’s Manual Before Use

Safety Alert Symbol: Information Following This Symbol Is

Very Important.

Use Only Norton Diamond Blades

I. PREPARATION

A. Safety Precautions

Important! The following safety precautions must always be observed.

Hazard Symbols

Fuel (gasoline) is extremely flammable and its vapors can

explode if ignited. Store gasoline only in approved containers,

in well-ventilated, unoccupied approved areas, and away from

sparks or flames. Do not fill the fuel tank while the engine is hot

or running. Do not start the engine near spilled fuel. Never use

the fuel as a cleaning agent

Engine components can get extremely hot from operation. To

prevent burns, do not touch the engine or related parts while the

engine is running or immediately after it is turned off. Never

operate the engine with any heat shields or guards removed.

Keep all guards in place when operating any piece of equipment

Keep hands, feet, hair, and clothing away from all rotating parts

Lethal Exhaust Gas: use only in well ventilated areas. Engine

exhaust gases contain poisonous carbon monoxide, which is

odorless, colorless, and can cause death if inhaled. Avoid

inhaling exhaust fumes, and never run the engine in a closed

building or confined area.

Never tamper with the governor components of settings to

increase the maximum speed. Severe personal injury and

damage to the engine or equipment can result if operated at

speed above maximum. Always obey the maximum speed

rating of blade.

DO NOT LIFT THE SAW BY THE HANDLE

BARS

Dust and Silica Warning

Grinding/cutting/drilling of masonry, concrete, metal and other materials can

generate dust, mists and fumes containing chemicals known to cause serious or

fatal injury or illness, such as respiratory disease, cancer, birth defects or other

reproductive harm. If you are unfamiliar with the risks associated with the

particular process and/or material being cut or the composition of the tool being

used, review the material safety data sheet and/or consult your employer, the

material manufacturer/supplier, governmental agencies such as OSHA and

NIOSH and other sources on hazardous materials and make certain to comply

with all product warnings and instructions for the safe and effective use of the

material being cut. California and some other authorities, for instance, have

published lists of substances known to cause cancer, reproductive toxicity, or

other harmful effects.

Control dust, mist and fumes at the source where possible. In this regard use

good work practices and follow the recommendations of the manufacturer/supplier,

OSHA/NIOSH, and occupational and trade associations. Water should be used

for dust suppression when wet cutting is feasible. When the hazards from

inhalation of dust, mists and fumes cannot be eliminated through engineering

controls such as vacuum and/or water mist, the operator and any bystanders

should always wear a respirator approved by NIOSH/MSHA for the material being

cut.

Use Approved:

Eye Protection Hearing

Protection

Respiratory

Protection

Head Protection

1. Before mounting any blade on the saw, the blade should be inspected for

any damage which might have occurred during shipment, handling or

previous use.

2. The blade collars and arbors should be cleaned and examined for damage

before mounting the blade.

3. The blade must be properly fitted over the arbor with the drive pin on the

outside collar projecting through the drive pin hole on the blade and

inside collar.

4. The blade shaft nut, which is a left-hand thread nut, must be tightened

securely against the outside blade shaft collar.

5. The blade must be operated within the specified maximum operating

speed listed on the blade.

6. Turn water control valve to full to provide adequate coolant (4 to 6 gallons

per minute) for diamond blades and wet cutting abrasive blades.

Insufficient coolant could result in severe blade breakage or diamond

segment separation.

7. The blade guard must be in place with the nose guard down and locked

when the saw is running.

8. The operator should wear safety glasses and any other appropriate safety

equipment.

9. When starting the saw, the operator should stand away and to the side of

the blade.

10.If for any reason the saw should stall in the cut, raise the blade out of the

cut. Check the outside blade shaft collar and nut for tightness. Inspect

the blade for damage before restarting the saw. Use caution when

resuming a cut. Be certain that the blade is in alignment with the previous

cut.

11.During cutting operations do not exert excess side pressure on the

handles as a method of steering. Do not force the blade into the cut by

lowering the blade too fast or by pushing the saw too fast.

You Are Responsible For Your Safety!!!

I. PREPARATION

B. Assembly

The C914P compact concrete saw is shipped completely assembled and ready

for use except for Handle Bar, Diamond Blade, Gasoline, and Engine Oil.

Inspect the saw for shipping damage. If any damage is found, contact the

shipper immediately and file a freight claim. Norton Clipper is not responsible

for any freight-related damages.

Handle Bar Lifting Bale

Depth Adjustment

Hand Wheel

Front Pointer

(

Cuttin

Guide

)

Belt Guard

Blade Guard

Engine On/Off

Switch

Water Tank

Engine Choke,

Fuel Shut Off, and

Throttle Controls

Engine Air Cleaner

Remove the saw from the pallet. Inspect the machine for concealed shipping

damaged. Read and understand ALL instruction included in this manual.

Failure to understand and follow the instruction covered in this manual can

result in injury to persons or damage to the machine.

DO NOT LIFT THE SAW BY THE HANDLE BARS

Loosen the Handle Bar Retaining Jam Nuts and Bolts. Remove the Handle

Bars from the Frame and rotate 180° so that the Hand Crips will be towards the

Operator. Slide the Handle Bar Assembly into the frame, adjust to the

Operator’s desired height, and align the nearest Hole in the Handle Bar

Assembly with the top Retaining bolt. Tight both Handle Bar Retaining Bolts

and Tighten the Jam Nuts. See Figure: Handel Bar Assembly

¾” Garden Hose

Fitting

Quick Detach

Water Fitting with

Valve

Handle Bar Attachment

Hardware

ine On/Off Switch

Wrench and

Wrench Holder

Serial Number Plate

Water Tank Quick

Detach Fittin

s Blade Guard Water

WYE and Nozzels

Handle Bar Assembly

Level the cutting frame and check the engine oil level and add if required (See

Engine Manual) and add fuel (See Engine Manual). NOTE: Do not install the

blade until it is time to use the saw. ANSI regulations prohibit the

transportation of any concrete saw with the blade installed.

Handle Bar Installation;

DO NOT LIFT THE SAW BY THE HANDLE BARS

Handle Bar Assembly

Handle Bar Attachment

Hardware

Handle Bar Attachment

Hardware

C. C914P Series Concrete Saw Specifications

C914P

Dimensions/Weight

Length (Working) – in (mm) 57-55/64" (1,469)

Length (Transport) – in (mm) 35-37/64" (929)

Pointer Length – in (mm) 12-47/64" (323)

Width – in (mm) 37-59/64" (963)

Height – in (mm) 21-9/32" (541)

Weight Created – lbs. (kg) 198.4 (90.6)

Weight Uncreated – lbs. (kg) 169.4 (77)

Engine

Engine Mfg. Honda

Model GX370

Spec No. GX270QXC

Engine Type Single Cylinder 4 Cycle

Horse Power – Gross hp (kW) 9 HP (6.7kW) @ 3,500 RP<

Max Torque – Gross – ibf-ft (Nm) 14 (19) @ 2,500 RPM

Cooling System Air

Oil Capacity – US qt (l) 0.29 (1.1)

Fuel Capacity – US qt (l) 5.6 (1.1)

Fuel Type Unleaded Gasoline (86 pump octane)

Low Oil Sensor Yes

Air Filtration Three Stage Cyclone

Characteristics

Max Blade 14" (350)

Depth of Cut 14” (356 mm) – in (mm) 4-5/8 (117)

12” (305 mm) – in (mm) 3-5/8 (92)

10” (254 mm) – in (mm) 2-5/8 (67)

1-5/8 (41)

Arbor Bore – in (mm) 1” (25.4 mm)

Blade Shaft Locking Device Machined Into Flats On Blade Shaft

Blade Shaft Speed – RPM 2,840

Blade Shaft Diameter – in (mm) 7/8" (22)

Depth Control Hand Wheel With Screw Feed

Depth Lock Standard

One (1) Revolution of Hand Wheel ¼” (6.4mm) Change of Depth

Front Wheel DxWxB – in (mm) 3-15/16 x 1-3/8 x 0.59 (100 x 35 x 15)

Rear Wheel DxWxB – in (mm) 7-7/8 x 1-49/64 x 0.79 (200 x 45 x 20)

Number Of Belts Three (3) XPZ610 Belts

Blade Guard Type Hinged, All Steel Construction

Side of Cut Right

Lifting Bale Yes

Water Hose Connector Standard Garden Hose With Flow Control Valve

Water Tank Capacity – gal (l) 6.6 (25)

Recessed Rear Wheels Standard

Adjustable Handle Bars – in (mm) Yes 9-29/64 (245)

Stay Level Handel Bar System Yes

* = Horse power and Torque ratings are Gross Horse power and are supplied by the engine manufacturer. Actual output of the engine will vary due to many

factors including operational speed of engine, environmental conditions, maintenance, fuel, and other variables. Saint-Gobain Abrasives, Inc. makes NO

claim to actual or gross horse power and torque ratings.
