N-1000-III/IV

Installation and

Programming

Manual

TD1064 rev0400 - NCI

ADEMCO Part # K4788

N-1000-III/IV

Notices

Fire Safety Notice: Never connect any card reader devices or locks to door, gates or barriers

without first consulting the local fire codes. You must consult with and get approval of, local fire

officials before installing locks or devices on any doors that may be fire exits. Use of egress push

buttons may not be legal. Single action exit may be required. Always obtain proper permits and

approvals in writing before installing equipment.

Notice: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environ-

ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

Notice: The information in this document is subject to change without notice.

Notice: This document and the data herein shall not be duplicated, used or disclosed to others for

procurement or manufacturing, except as authorized with the written permission of Northern

Computers, Inc. The information contained within this document or within the product itself is

considered the exclusive property and trade secrets of Northern Computers, Inc. All information in

this document or within the software product itself is protected by the copyright laws of the United

States.

Notice: Any use of this product is subject to the terms and acceptance of the Northern Computers,

Inc. “Software Agreement.” Please request a copy from Northern Computers, Inc. and review this

agreement carefully.

IBM is a trademark and/or a registered trademark of Internationl Business Machines Corporation.

MS-DOS, Windows, Windows NT, Windows ’95, Windows ‘98 are trademarks and/or registered

trademarks of Microsoft Corporation in the United States and/or other countries. The use of Cotag,

Wiegand, IDI, Continental, NCS, Dorado, Indala, Motorola & Hayes may or may not be registered

trademarks/

technologies of those respective companies.

iiii

ii N-1000-III/IV

iiiiii

iii

N-1000-III/IV

ContentsContents

Contents

UL Note............................................................................................................. vi

New and Improved Features of the N-1000-III/IV ............................................. vii

Section 1: Introduction/Access Control ............................................................. 1-1

Section 2: System Overview ............................................................................ 2-1

2-1:N-1000-III/IV ........................................................................................................................................... 2-1

2-2: Programming Devices ............................................................................................................................... 2-2

2-3:C-100-A1Converter ................................................................................................................................... 2-4

2-4:N-485-PCI-2 orHUB-2 .............................................................................................................................. 2-4

2-5:PROM Versions.......................................................................................................................................... 2-4

Section 3: Hardware Specifications .................................................................. 3-1

Section 4: Installation/Panel Layout ................................................................. 4-1

4-1:Four Reader Board (N-1000-IV only)........................................................................................................... 4-2

4-2: Terminal Blocks 1, 2, 3, 4 .......................................................................................................................... 4-4

4-3: Terminal Block 5 ....................................................................................................................................... 4-6

4-4: Terminal Block 6 ....................................................................................................................................... 4-6

4-5: Terminal Block 7 ....................................................................................................................................... 4-8

4-6: Terminal Block 8 ......................................................................................................................................4-10

4-7: Terminal Block 9 ......................................................................................................................................4-10

4-8: DIP Switch Settings ..................................................................................................................................4-12

4-9:Jumpers ..................................................................................................................................................4-14

4-10:Connectors .............................................................................................................................................4-15

4-11: LEDs.....................................................................................................................................................4-16

4-12:Restart Button ........................................................................................................................................4-18

4-13: RAM Chip ..............................................................................................................................................4-18

4-14: PROM Chip ............................................................................................................................................4-18

4-15: Additional Installation Information ..........................................................................................................4-18

Section 5: Operation ....................................................................................... 5-1

5-1: Card Reader/Keypad Operation .................................................................................................................. 5-1

5-2: Alarm Input Points .................................................................................................................................... 5-4

5-3: Relay Output Points................................................................................................................................... 5-5

5-4: Default Input Point/Output Point Interaction ................................................................................................ 5-6

5-5:Auto-Relock Operation ..............................................................................................................................5-14

5-6:Time Zone-Controlled Doors .......................................................................................................................5-14

Section 6: Wiring Requirements ....................................................................... 6-1

6-1: Card Readers ............................................................................................................................................ 6-1

6-2: Four Reader Board (N-1000-IV Only) .......................................................................................................... 6-3

6-3: Eleven Conductor Keypads ......................................................................................................................... 6-5

6-4: Alarm Input Points .................................................................................................................................... 6-7

6-5: Relay Output Points................................................................................................................................... 6-7

iviv

iv N-1000-III/IV

6-6: Communications ....................................................................................................................................... 6-7

6-6-1:PC toC-100-A1 .............................................................................................................................. 6-7

6-6-2:C-100-A1 to Panel(s)...................................................................................................................... 6-7

6-6-3:AEP-3 toN-1000-III/IV ................................................................................................................... 6-8

6-6-4:PC toN-485-PCI-2.........................................................................................................................6-12

6-6-5:N-485-PCI-2 toPanel ....................................................................................................................6-12

6-6-6:N-485-HUB-2 toPanel ..................................................................................................................6-13

6-6-7:N-485-HUB-2toModem................................................................................................................6-13

6-6-8: Bias and EOL with 485 Communication ..........................................................................................6-14

6-7: Cable Specifications .................................................................................................................................6-18

6-8: NCI Cable Part Numbers ............................................................................................................................6-19

6-9: Configurations for RS-232 Serial Communication Ports .................................................................................6-20

Section 7: Locks and Suppression .................................................................... 7-1

Section 8: Grounding ...................................................................................... 8-1

Section 9: Power ............................................................................................. 9-1

Appendix A: Programming Quick Reference Guide ..........................................A-1

Commands...................................................................................................................................................... A-5

A Command ............................................................................................................................................ A-5

C Command............................................................................................................................................. A-6

D Command ............................................................................................................................................ A-8

E Command ............................................................................................................................................ A-9

F Command............................................................................................................................................A-10

G Command ...........................................................................................................................................A-12

H Command ...........................................................................................................................................A-13

I Command ............................................................................................................................................A-13

L Command............................................................................................................................................A-14

M Command...........................................................................................................................................A-15

N Command ...........................................................................................................................................A-16

O Command ...........................................................................................................................................A-17

P Command ...........................................................................................................................................A-18

R Command ...........................................................................................................................................A-18

T Command............................................................................................................................................A-19

V Command ...........................................................................................................................................A-19

W Command (Used with the N-1000-III/IV only) ........................................................................................A-20

Z Command............................................................................................................................................A-21

OR’ing of Inputs .............................................................................................................................................A-21

Output Groups by Readers................................................................................................................................A-22

Appendix B: N-1000-III/IV Compared to N-1000-II......................................... B-1

Appendix C: Troubleshooting ...........................................................................C-1

N1000-III/IVSelf-TestCapability ........................................................................................................................C-3

Index ..............................................................................................................C-1

N-1000-III/IV

Preface

The N-1000-III/IV Installation Manual provides all information necessary for

installation of N-1000-III, N-1000-III-X, N-1000-IV, and N-1000-IV-X control panels.

All of the N-1000-III/IV versions have both the 20 mA and 485 multi-drop commu-

nications interfaces.

The N-1000-III/IV can be used in existing N-1000-II/N-800 systems provided the

existing panels have version 8.0 or higher firmware.

Note: When the N-1000-II/N-800 is configured for 485 (N-485-API-x), the

firmware version must match the 485 version in the N-1000-III/IV.

The following table identifies the different features of each version of the N-1000

panel:

Version* CardReaders MatrixKeypads Alarm Inputs** Relay Outputs Cards*** Buffers***

N-1000-III 2 2 16 4 5,000 10,200

N-1000-III-X 2 2 16 8 25,000 6,600

N-1000-IV 4 2 16 4 5,000 10,200

N-1000-IV-X 4 2 16 8 25,000 6,600

* A version with removable wiring terminal strips is available for each model and is

designated by an Rafter the version number.

**Two system alarms are independent of the sixteen zone inputs. Matrix keypads do

not use any of the 16 alarm inputs.

***These are default values. Capacity can be changed by use of the I command U

option. Refer to Appendix A: Programming Quick Reference Guide for details.

vivi

vi N-1000-III/IV

UL Note

The N-1000-III/IV panel’s alarm point monitoring only monitors the door position

(UL294). It is not intended as a proprietary burglar alarm (UL1094).

The control panel was UL294 tested as a stand alone unit only.

The N-485-HUB-2 was not investigated by UL.

The N-1000-III/IV was UL294 tested using the following card readers:

• Model 30387 (CR-1) Wiegand swipe reader.

• Model 5365BGP00 (PR-MINI-PROX) proximity reader.

• Model 5355AGN00 (PR-P-PRO) proximity reader.

The N-1000-III/IV was UL294 tested using the Basler Electric transformer part

number BE11625CAA-0042 (X-4).

viivii

vii

N-1000-III/IV

New and Improved Features of the N-1000-III/IV

The N-1000-III/IV series panels have both a number of improvements and some

unique features as compared to the N-1000-II control panels. Some of these

features are highlighted below. For a more detailed description refer to Appendix B

of this manual.

• Four layer PWB and other improvements provide greater electrical noise immu-

nity.

• High efficiency switching regulators result in reduced heat generation and

extended backup battery operation.

• A Four Reader Board allows the N-1000-IV panel to support a total of four

readers. (See Section 4-3 for details.) When this board is present all four

readers attach to it via its removable terminal strips. A Reader Function

Test is available on the Four Reader Board by shorting a pair of jumper prongs

labeled TEST. This will cause the board to generate a simulated card read from

each of the four readers.

• An improved canister has more knockouts, a larger battery bracket and im-

proved wiring space, since the board is centered in the enclosure. (The old

enclosure can be field retrofitted for the new board.)

• The processor speed is substantially faster than the standard N-1000-II, increas-

ing the speed of internal processing. At the same time, communications output

is the same as the N-1000-II panels so they can be used in the same loop.

• An additional Terminal Block (TB9) has been added in the upper left quadrant

of the board. This terminal block has an Earth Ground connection; a battery

plus and minus (in addition to the soldered-in battery wires); AC connections 1

and 2 (there are no spade lugs for AC or battery); the Tamper and External

Power Status inputs with common posts; and a place to tie the RS-485 shields.

• The N-1000-III/IV firmware (version 08.01.29 or later) has a built-in test

capability that can be used to check the functioning of most of the circuit

board’s hardware. This feature is detailed in Appendix C: Trouble Shooting.

• There are both RS-485 and RS-232 communications ports in addition to the 20

milliamp port. The RS-485 port is selected by a change of Jumper 1 in lieu of

the 20 milliamp. The RS-232 port can be used in addition to or instead of the

other ports.

• A 16.5 volt AC power source is now required, allowing the charging of a 12 volt

battery for back-up as well as the supply of 12 volt reader and PIR egress power

from the N-1000-III/IV.

• A 12 volt, 500 mA output is available for powering 12 volt readers or PIR

egress detectors. Connections for this are at TB9 terminals 7 (+) and

8 (Common).

viiiviii

viii N-1000-III/IV

• Detection of a primary power failure by either the internal sensor or the

input from the relay on the external supply will generate an Alarm 19 not

Alarm 8. Alarm Point 8 is now available for use as a standard alarm point

• Automatically resetting solid state fuses are used.

• The Green Low-V OK LED will go off to indicate low 12 Volt battery (indicator

turns off at approximately 10.1 volts, the panel shuts down at approximately

9.9 volts) or disconnected RAM back-up (JP9 removed).

• A special set of connectors for the AEP-3 Relay Expansion board is provided. J1

is a connector for the present AEP-3 Board design. J2 is a double connector and

will be used for a future development.

• There are screw terminals for the reader cable shield connections. These are

nearer to where the wires come in, eliminating the need to run the shield wire

around the board.

• The terminals on Terminal Block 8 are used exclusively for 11 wire Keypads.

This makes all regular inputs available even when a keypad is used. The K

option is no longer needed. The P option must still be entered for use with

PINs. Screw Terminal 4 is used for the Black (Ground) wire of the Keypad.

• There is a separate Tamper Input located on TB9. This makes Input 12 (termi-

nal now located on TB6) available as a regular alarm input.

• Each input can be individually programmed for both Normally Open or Normally

Closed and Supervised or Non-Supervised operation.

• There are several changes to the System inputs.

Alarm 17 Communications status alarm, but now it reports for either 20 mA

or 485 failures.

Alarm 18 Reserved for future reporting of an Auxiliary Communications Status

(the RS-232 port.)

Alarm 19 Primary Power Fail alarm.

Alarm 20 Tamper alarm (with special terminal connections on Terminal

Block 9).

Alarm 21 Input Ground Fault alarm. If the input is shorted to Earth Ground

this alarm will be generated. (Some fault conditions may generate

an ALARM rather than TROUBLE from the point, but no ground fault

will be interpreted as NORMAL.)

Alarm 22 Reserved for future use.

Alarm 23 Indicates an external 5 volt reader power short circuit.

Alarm 99 Generated at restart either due to the Push Button or the watch dog

timer. (This alarm cannot be stored in the history buffer.) A 99

trouble is communicated on a cold boot-up reset when the RAM

memory is being initialized.

•Relays are heavy duty inductive load rated. They have a maximum load rating

of 30 VDC, 5 A Resistive, 2 A Inductive. They also have circuitry which is less

susceptible to electrical switching noise.

Section 1: Access ControlSection 1: Access Control

Section 1: Access Control N-1000-III/IV 1–1

INTRODUCTION

Section 1: Access Control

Access control is computerized control over entry to any area that can be secured

with a lock and key. Entry is only allowed to authorized people at authorized times.

Control of who is allowed to come and go is easily maintained.

The weakness of a lock and key security system is the common key. The key is a

readily duplicated piece of metal that gives anyone who holds it access to an area.

The risk of lost or stolen keys, with the expense of changing locks, is a costly

problem. Access control is an effective and affordable solution to this problem.

With access control, each person receives a card or keycode which restricts access

to authorized areas at authorized times. A small, programmable control panel

allows or denies access. If a card is lost or stolen, or if a keycode is no longer

secure, the control panel can be reprogrammed quickly and easily.

An additional benefit of access control is report capability. The system provides

reports of all card/keycode activity, including whether access was granted or

denied, and why. A permanent record of all entries to an area can be maintained.

Otros manuales para N-1000-III

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Panel de control de Northern

Northern

Northern N-1000-III Instrucciones de montaje

Manuales populares de Panel de control de otras marcas

RDZ

RDZ PC-HRX Manual de usuario

STG-BEIKIRCH

STG-BEIKIRCH MZ3 Manual técnico

Efka

Efka Variocontrol V810 Manual de usuario

Cebora

Cebora 208-10 Manual de usuario

AMX

AMX AutoPatch CP-15 Manual de usuario

Satel

Satel CA-6 KLED-S Manual de usuario

Evolution

Evolution IQ plus 800 Manual de usuario

Fagor

Fagor 8040 TCO CNC Manual de usuario

Trane

Trane ComfortLink II XL950 Control Manual de usuario

AKO

AKO PROCool AKO-17635-2 Manual de usuario

ABB

ABB 6136/30M-101 Manual de usuario

Telikou

Telikou BK-603 Belt Pack Manual de usuario

Mapei

Mapei Mapeheat Thermo Touch Manual de usuario

Bosch

Bosch D9412GV4 Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries SC-SL4-AE2/1 Manual de usuario

Sminn

Sminn BOX L VF1L EI Manual de usuario

Balboa

Balboa TP600 Manual de usuario

Nice

Nice HSCU1 Especificaciones técnicas
