TECHNICAL FEATURES
· Voltage: 230 V AC +/- 10%.
· Power supply wire cross-section: 2,5 mm2.
· Output voltage: 24 V DC +/- 20%.
· Output wire cross section: 2,5-6 mm2.
· Working temperature: -5ºC to 25ºC.
· Class: I.
· IP30.
· Number of outputs: 8.
· Maximum current: 3,5 A by output.
· Type of fuse for the outputs: 4A · 250 V.
· Control capacity: Up to 120 ttings.
· Dimensions: C24i-300: 587 x 460 x 187 mm.
· Type of fuse for the batteries: 16A · 250 V.
· Number of auxiliary inputs: 3.
· Number ouf auxiliary outputs: 3.
· Type of fuse for F2 input: 16A · 250 V.
2
1 A 147 m
2 A 74 m
3 A 49 m
1 A 245 m
2 A 123 m
3 A 82 m
WIRE SECTION
* Length for double wire and charge at end of line.
DISTANCE*
MAXIMUM INTENSITY
1,5 mm2
2,5 mm2
2 x 12 V · 18 Ah2 x 12 V · 12 Ah2 x 12 V · 9 Ah2 x 12 V · 7 Ah 2 x 12 V · 24 Ah
9,946,624,973,86 4,392,922,191,70 1,951,300,970,76 13,25 5,85 2,60
1 h1 h1 h1 h 3 h3 h3 h3 h 8 h8 h8 h8 h 1 h 3 h 8 h
234 W154 W115 W88 W 105 W66 W48 W36 W 42 W27 W19 W14 W 314 W 136 W 58 W
Batteries
Autonomy
Total power
output (W)
Maximum current (A)
Remarks:
Prevent the lines connecting
each output of the control panel
to the emergency luminaires
from running through the same
tray as other power lines. If
corrugated conduit is used, do
not use the same conduit for the
output lines of the control panel
and other power lines.
Normalux recommends the use
of twisted shielded wire for
the output lines. Connect the
cable shield to the earth of the
installation.
