Nokia SERIES 40 Manual de usuario

provided by

pushTotalk

Nokia Series 40

Quick Start Guide

Press ‘Done’

Press ‘Yes’

Series 40 Quick Start Guide

The Nokia Series 40 phones have an in-built Push To Talk (PTT) client that

your PTT service utilises.

This enables you to hold one-to-one and one-to-many conversations at

a push of a button.

The screens in this guide are the standard Nokia Series 40 screens, your

screens may vary slightly depending on your handset model.

Setting up Push to Talk for

the first time

1. Firstly, ensure that your handset has been fully charged and your SI

has been activated with your PTT service and is inserted.

2. To set up PTT on your device you will receive a text message, follow the

below instructions:

Press ‘Show’ Press ‘Sa e’

Your phone will now return to the standby screen. Scroll through your main

‘ enu’, a ‘Push to Talk’ screen will appear.

This is now configured to your PTT service.

Setting up User Groups

This is done by accepting text invitations for the required user groups that are

sent to you from the provisioning system.

1. Accepting an invitation

2. Setting the group status

You need to state whether this is to be your main group or a secondary

group. Select the option from below screen that meets your requirements

for this group:

Scroll to required option and press ‘Select’

Default (or Active) = You will automatically broadcast to this group when

you press the PTT button and all calls will be

broadcast to you.

Listened = You will ‘Listen’ into calls to this channel, but you

will need to manually select it to talk to this group.

Inactive = You will not hear any conversations from this group.

Press ‘Sa e’

Press ‘View’

Contact anagement

Adding a new contact

You can add new personal contacts by adding them manually or selecting

them from a group.

1. Adding a new contact manually

Scroll to ‘contact list’ on the Push to Talk menu.

Now you can add your contact manually to your Push to Talk list by following

the below:

Select

‘Contact List’

Select contact

and press

‘Options’

Press ‘Add Contact’

Select ‘Enter

Manually’

Enter Push to

Talk address*

Select ‘Ok’

Note: If you have no existing contacts you will be asked to add a new contact.

You will now receive confirmation of it being added and sent back to your

contacts list with the new contact added.

*This is normally your mobile phone number.

2. Adding a contact from a Group List

Go to the ‘Group List’ option on the Push to Talk menu screen.

Press ‘Select’ Select ‘Members’ Select contact you

wish to add

Press ‘Sa e As’ Enter name This is now in

and click ‘OK’ your contacts

aking a Call

To start a Push to Talk call you simply talk whilst you hold down the Push to

Talk button on you handset. The recipient(s) can then respond once you have

cleared the channel by releasing the PTT button.

You will broadcast to your ‘default’ or ‘Active’ group by just pressing the PTT

button from the standby screen. To broadcast to a particular contact or group

you will need to go into the PTT menu.

1. One to One Call

Go to your ‘Contacts list’ or a ‘Group list’, scroll to the contact you wish to

speak to and hold down Push to Talk button on the side of the phone to start

a conversation.

2. Broadcasting to an ad-hoc group

From your ‘contacts list’ or ‘Group Lists’ scroll to individual contacts and

‘ ark’ them, once you have marked the contacts you wish to speak to then

press the PTT button. Recipients of that call will now respond to all users.

3. Broadcasting to a pre-set group

You can broadcast to a group by manually selecting it through the ‘Group

List’ option in the PTT menu. Simply highlight the group you wish to

broadcast to and press the Push To Talk button on the side of the phone.

Requesting a Callback

If you need to get hold of somebody but you do not want to broadcast a

message directly to them then you can request a ‘callback’. This is useful

when you are not sure of the situation they are in.

1. Select the contact you wish to reach from your ‘Contact List’ screen.

2. Press ‘Options’ and select ‘Send Callback’.

3. You will receive confirmation when this message is sent.

4. You will then be returned to the contacts screen and the recipient will

see a message asking them to contact you. They just need to press their

PTT button and this will instigate a direct one-to-one PTT call to you.
