Nokia N95-4 Hoja de especificaciones
Get started
Nokia N95-4
9207276, Issue 1 EN
2
Keys and parts (front)
Model number: Nokia N95-4.
Hereinafter referred to as Nokia N95 8GB.
1Power key
2Selection keys to select commands and access Options
3Menu key to access the main menu
4Call key
5Edit key to open a list of commands when you
edit text
6Scroll key to move around the menus and to
select items
7Numeric keypad
8Clear key
9End key
10 Multimedia key to access the multimedia menu and
open the music player
11 Light sensor
12 Secondary camera with lower resolution
3
Keys and parts (landscape)
1Media keys under the 2-way slide
•Next key
•Play/pause key
•Stop key
•Previous key
2Zoom/volume key
3Review key to view the last stored image or
video clip
42-stage capture key for auto-focus, still image
capture, and video recording
When you open the media keys under the 2-way slide,
the media mode is activated and the display is shown in
landscape orientation.
Use the media keys to control music and video players.
To activate the main camera, press and hold the capture
key. To lock the focus on an object, press the capture key
halfway down. To take a picture, press the capture key down.
To activate the video mode, select in the active
toolbar. To shoot video, press the capture key down.
4
Keys and parts (back)
1Charger connector
2Mini-USB connector to connect to a compatible PC
3Stereo speakers with 3D sound effect
4Main camera for high resolution image capture and
video recording (up to 5 megapixel)
5Camera flash
6Nokia AV Connector (3.5 mm) for compatible headsets,
headphones, and TV-out cables, for example, the Nokia
Video Connectivity Cable
7Infrared (IR) window
5
Insert the (U)SIM card and battery
A USIM card is an enhanced version of the SIM card and is
supported by UMTS mobile phones.
Always switch the device off and disconnect the charger before
removing the battery.
For availability and information on using SIM card services, contact
your SIM card vendor. This may be the service provider or other vendor.
1With the back of the
device facing you, press
and hold the release
button, slide the cover,
and lift it up.
2To release the (U)SIM
card holder, lift the
holder up from the handle.
3Insert the (U)SIM card. Make sure that the contact area
on the card is facing the connectors on the device and
the bevelled corner on the card is facing the base of
the device.
4Close the holder, and lock it into place.
5Insert the battery. To secure the battery into place,
press it gently.
6Replace the cover so that the locking catches are
directed towards their slots, and slide the cover
into place.
6
Switch the device on
1Press and hold the power key.
2If the device asks for a (U)PIN
code or lock code, enter it, and
press the left selection key.
The factory setting for the lock
code is 12345.
Your device has internal antennas.
Note: As with any radio
transmitting device, avoid
touching an antenna unnecessarily when the
antenna is in use. For example, avoid touching the
cellular antenna during a phone call. Contact with a
transmitting or receiving antenna affects the quality
of the radio communication, may cause the device to
operate at a higher power level than otherwise
needed, and may reduce the battery life.
1Cellular antenna
2Bluetooth
technology/wireless
LAN antenna
3GPS receiver
Charge the battery
1Connect a compatible
charger to a wall outlet.
2Connect the power cord
to the device. If the
battery is completely
discharged, it may take a
while before the charging
indicator starts scrolling.
3When the battery is fully
charged, the charging indicator stops scrolling.
Disconnect the charger from the device, then from
the wall outlet.
Tip: Disconnect the charger from the wall outlet
when the charger is not in use. A charger that is
connected to the outlet consumes power even
when it is not connected to the device.
7
Transfer content
Transfer personal content from
another Nokia device
With the Switch application, you can transfer content,
such as contacts, between two compatible Nokia devices
using Bluetooth connectivity or infrared. To transfer data
to your Nokia N95 8GB, press , and select Tools >
Utilities > Switch.
Transfer content from PC
You can use your device with a variety of compatible PC
connectivity and data communications applications. You
can, for example, transfer music, images, and videos
between your device and a compatible PC by using a
compatible USB data cable, Bluetooth connectivity, or
Nokia Nseries PC Suite installed on your compatible PC.
Always create the connection from the PC to synchronise
with your device.
Support
Help
The help function provides instructions when using the
applications in the device. To access it from an application,
select Options > Help.
User guide
Refer to the user guide for other important information
about your device.
Online
Check www.nseries.com/support or your local Nokia
website for the latest guides, additional information,
downloads, and services related to your Nokia product.
Tip: You can also access the support pages from the
web browser in your device.
8
Keypad lock (keyguard)
When the keys are locked, is displayed.
To lock the keys, press the left selection key, then the right
selection key.
To unlock the keys, open the 2-way slide, or press the left
selection key, then the right selection key.
To have the keypad lock activated automatically after a
time-out or when the 2-way slide is closed, press , and
select Tools > Settings > General > Security > Phone
and SIM card.
Tip: If you want to close the 2-way slide without
activating the keypad lock, press any key after you
close the slide.
When the keypad lock is on, calls may be possible to the
official emergency number programmed into your device.
Shortcuts
•To switch between open applications,
press and hold .
•To open Music player, press and hold the
multimedia key.
•In many applications, to view the most
used option items, press the scroll key.
•To open Gallery, press once.
•To call your voice mailbox (network service), press and
hold .
•To open the multimedia menu, press the multimedia key.
•To change the profile, press the power key, and select
a profile.
•To switch between Normal and Silent profiles, press
and hold . If you have two phone lines (network
service), this action switches between the two lines.
•To open the last dialed numbers list, press the call key.
•To use voice commands, press and hold the right
selection key.
•To start the Web browser (network service), press and
hold .
9
Personalization
In the personalization menu, you can change several settings
in your device. Press , and select Tools > Settings >
General > Personalization and from the following:
•Themes — to change the theme, wallpaper and power
saver settings
•Display > Light time-out — to adjust the
backlight timeout
•Display > Font size — to
adjust the size of the text
and icons on the display
•Standby mode > Active
standby — to switch the
active standby on or off.
The active standby
display shows application
shortcuts and events
from applications.
•Standby mode > Shortcuts — to assign a shortcut to
the selection keys in the standby mode
•Standby mode > Active standby apps. — to change
the default shortcut icons in the active standby mode.
Some shortcuts may be fixed, and you cannot
change them.
There are also other items you can modify:
•To modify a profile, press , and select Tools > Profiles >
Options > Customize. You can, for example, customise
the ringing tones and message alert tones.
•To change the clock shown in the standby mode, press
, and select Applications > Clock > Options >
Settings > Clock type.
10
Nokia Video Center
With Nokia Video Center (network service), you can
download and stream video clips over the air from
compatible internet video services.
Nokia Video Center supports files with extensions such as
.3gp, .mp4, or .rm.
To connect to the internet to browse available services that
you can add to Nokia Video Center, select Add new services.
To find and view videos, do the following:
1Press , and select
Video center.
2To connect to a service,
select the desired
video service.
3Some video clips can be
streamed over the air,
but others must be first
downloaded to your
device. To download
a video clip, select
Options > Download.
The downloaded videos are saved in Video center >
My Videos.
You can also transfer your own videos to Nokia Video
Center and view them in My Videos.
Tip: To convert video files into mobile format, use
Nokia Video Manager in Nokia Nseries PC Suite.
1To view your device on your compatible PC as a mass
memory device, make the connection with a
compatible USB cable.
2Select Data transfer as the connection mode.
3Select the videos you want to copy from your PC.
4Transfer the videos to E:\My Videos in the mass
memory of your device.
Video files in other folders of your device are not displayed
in My Videos.
