Let’s get started
Nokia N81 8GB
Copyright © 2007 Nokia. All rights reserved.
Copyright © 2007 Nokia. All rights reserved.
contents
Support 1
Keys and Parts 2
Music Mode 2
Gaming Mode 3
Multimedia Mode 4
Basic Phone Set-up 5
Insert the SIM or (U)SIM card and battery 5
Switch the device on 6
Keypad lock (keyguard) 7
Charge the battery 7
Basic set up 8
Nokia Nseries PC Suite 9
Music Experience 10
Music 10
Transfer music 10
Synchronise with Windows Media®Player 11 (WMP 11) 11
Insert Album Art 12
Nokia Podcasting 13
Radio 14
N-Gage™ Gaming 15
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Copyright © 2007 Nokia. All rights reserved. 1
support
Model number: Nokia N81-1.
Hereinafter referred to as Nokia N81 8GB.
Help
The help function provides instructions when using the device. To access it from an application, select Options > Help.
User guide
Further detailed information is given in the separate User Guide. Do not use this Get Started Guide in place of the complete
User Guide, which provides important safety and maintenance information.
Online
www.nokia-asia.com/N818GB/support
Copyright © 2007 Nokia. All rights reserved.
2
Music Mode
keys and parts
Ear Piece
Menu key
Power
3.5mm stereo audio jack for
compatible headsets and
enhancements
End Key
Clear key
Play/pause key
Lock switch
Next Key
Internet key
Toggle key
• Press and hold to switch between General
and Silent profiles or between two lines
(if your network provider support
two phone lines)
Selection key
Navi™ scroll key (hereinafter
referred to as the scroll key)
Selection key
Previous key
Send key
Stop Key
Tip: Press and hold to switch between open
applications
Caution: Leaving applications running in background
increases battery consumption and reduces battery life
2mm charger connector
Micro USB connector to
connect to a compatible PC
Tip: Press to select profile or
lock phone
Multimedia key
• Press to access Multimedia Menu
Tip: This is a quick access to the Music
Player. Press and select Music from the
Multimedia Menu
• Slide to lock/unlock keypad
• Press and hold for web access
Copyright © 2007 Nokia. All rights reserved. 3
keys and parts
Gaming Mode
Navi™ scroll key
(hereinafter referred
to as the scroll key)
• 8-way directional gameplay
Gaming keys
• To control gameplay functions
Note: Only for landscape
games
Copyright © 2007 Nokia. All rights reserved.
4
keys and parts
Multimedia Mode
Gaming keys
• Functions as zoom
in/out in gallery mode
Capture key
Tip: Press and hold to activate the main
camera to capture still images and record
video
LED flash
2 megapixel camera
Stereo speaker
Zoom/Volume key
Copyright © 2007 Nokia. All rights reserved. 5
basic phone set-up
A (U)SIM card is an enhanced version of the SIM card and
is supported by UMTS mobile phones.
Important: Keep all SIM cards out of the reach of small children. Always switch
the device off and disconnect the charger before removing the battery. For
availability and information on using SIM card services, contact your SIM
card vendor. This may be the service provider or other vendor.
Insert the SIM or (U)SIM card
and battery
1With the back of the device facing
you, press the release button (1),
and lift the cover up (2).
2Pull the SIM card holder out of
the card holder slot (3).
3 Insert the SIM card into the card
holder. Make sure that the bevelled
corner on the card is facing the
bevelled corner on the holder, and
that the gold coloured contact area
on the card is facing down. Slide the
holder back to the slot (4).
4Insert the battery (5).
5 Replace the cover so that the top of
the cover fits the back of the device
(6). Depress the cover bottom to lock
the cover into place (7).
Copyright © 2007 Nokia. All rights reserved.
6
basic phone set-up
1Press and hold .
2If the device asks for a PIN
code or lock code, enter it,
and press the left selection
key. The factory setting for
the lock code is 12345.
Your device has internal
antennas.
Switch the device on
Note: As with any radio transmitting device, avoid touching an antenna
unnecessarily when the antenna is in use. For example, avoid touching the
cellular antenna during a phone call. Contact with a transmitting or receiving
antenna affects the quality of the radio communication, may cause the
device to operate at a higher power level than otherwise needed, and may
reduce the battery life.
Bluetooth technology/
wireless LAN antenna
Cellular antenna
Copyright © 2007 Nokia. All rights reserved. 7
basic phone set-up
When the keys are locked, is displayed.
To lock or unlock the keys, slide the lock switch.
To select whether the keypad is locked when closing the
slide, press , and select Tools > Settings > General >
Slide handling > Keyguard activation > On when
closing slide, Off when closing slide, or Always ask.
To have the keypad lock activated automatically after a
time-out or when the slide is closed, press , and select
Tools > Settings > General > Security > Phone and
SIM card > Keypad autolock period.
When the keypad lock is on, calls may be possible to the
official emergency number programmed into your device.
1Connect a compatible charger
to a wall outlet.
2Connect the power cord to the
device. If the battery is
completely discharged, it may
take a while before the charging
indicator starts scrolling.
3When the battery is fully
charged, the charging indicator
stops scrolling. Disconnect the
charger from the device, then
from the wall outlet.
Charge the batteryKeypad lock (keyguard)
Copyright © 2007 Nokia. All rights reserved.
8
basic phone set-up
Basic set up
When you switch on your device for the first time,
Welcome is displayed. Select from the following to set up
your device:
Settings wizard—to configure various settings, such
as e-mail.
Switch—to transfer content (e.g. contacts and calendar
entries) via Bluetooth, from a compatible Nokia device.
• Select Continue to search for devices with Bluetooth
connectivity.
• For some models, the Switch application is sent to the
other device as a message. To install Switch, open the
message and follow the instructions.
• Select the device you wish to transfer content from,
and enter the code to pair your Nokia N81 8GB and the
device.
• Select the content you wish to transfer.
For subsequent data transfer, press > Tools > Utilities >
Switch.
Select the following to start a new transfer:
To synchronise content between your Nokia N81 8GB and
another device
To retrieve data from another device to your Nokia N81
8GB
To send data from your Nokia N81 8GB to another device
Welcome—To view a demonstration about your device.
