Get started
9247663, Issue 2 EN
Nokia N73-1
2
Scroll key. Press the key in the middle ( ) to
select, accept, or activate.
Keys and parts (front and side)
Selection keys ( and )
Light sensor
Call key ( )
Secondary camera with lower resolution
Zoom / Volume key
2-stage capture key ( )
Clear key ( )
Menu key ( )
Review key ( ) to view the last saved
image or video clip
4
10
7
1
2
1
8
11
2
3
4
5
6
7
8
End key ( )
9
10
11
12
13
Model number: Nokia N73-1.
Hereinafter referred to as Nokia N73.
9
56
13
12
Edit key ( ) opens a list of commands
when you edit text.
Multimedia key ( ) is a shortcut to
multimedia content.
3
3
Main camera for (higher resolution) image cap-
ture and video recording
Pop-Port™ connector for the USB data cable,
headset, and other compatible enhancements
Slide for camera protection, activation, and
control.
Keys and parts (back)
Camera flash
Charger connector
Memory card slot for a compatible miniSD card
(sold separately)
Infrared (IR) window
15
14
17
18
Power key
Stereo speakers
21
12
13
14
15
16
17
18
19
20
16
20
21
22
19
11
22
15
4
Insert the (U)SIM card and battery
The USIM card is an enhanced version of the SIM card and is supported by UMTS
mobile phones.
Keep all SIM cards out of the reach of small children.
Always switch the device off, and disconnect the charger before removing the
battery.
1. With the back of the device facing you, press the
release button (1), slide the cover (2), and lift it up (3).
2. Slide the (U)SIM card into the holder (4). Make sure
that the bevelled corner on the card is facing the base
of the device, and that the contact area on the card is
facing the connectors on the device.
5
Switch the device on
1. Press and hold the power key ( ).
2. If the device asks for a (U)PIN code or lock code, enter
it, and press . The factory setting for the lock code is
12345.
Your device has two internal antennas.
Note: As with any radio transmitting device, avoid touching an antenna
unnecessarily when the antenna is in use. For example, avoid touching the cellular
antenna during a phone call. Contact with a transmitting or receiving antenna affects
the quality of the radio communication, may cause the device to operate at a higher
power level than otherwise needed, and may reduce the battery life.
When you switch on the device for the first time, it may prompt you to set the
following information: Select current city:, Time:, and Date:. Use the scroll key
and the number keys. To find the city, enter the first letters of the city name. The city
you select also defines the time zone for the clock in your device.
3. Insert the battery (5).
4. Replace the back cover.
6
Your Nokia N73 normally has MMS, GPRS, streaming, and mobile Internet settings
automatically configured in the device, based upon your service provider or network
operator information.
Press to open the main menu.
Your service provider may have requested that certain features be disabled or not activated in your device.
If so, they will not appear on your device menu. Your device may also have been specially configured. This
configuration may include changes in menu names, menu order, and icons. Contact your service provider for
more information.
Keypad lock (keyguard)
Use the keypad lock to prevent the keys from being accidentally pressed.
To lock: In the standby mode, press , then . When the keys are locked,
is shown on the display.
To unlock: Press , then .
When the keypad lock is on, calls may be possible to the official emergency number
programmed into your device.
To turn on the display light when the keypad lock is on, press .
7
Insert the memory card (sold separately)
Use only compatible miniSD cards approved by Nokia for use with this device. Nokia
uses approved industry standards for memory cards, but some brands may not be
fully compatible with this device. Incompatible cards may damage the card and the
device and corrupt data stored on the card.
You can purchase a compatible miniSD card as extra storage space to save the
memory on your device. You can also back up information from your device to the
memory card.
Keep all memory cards out of the reach of small children.
1. To insert the memory card (1), place your nail in the
recess below the door of the memory card slot, and
open the door.
2. Insert the memory card in the slot (2). Make sure that
the contact area on the card is facing up and towards
the slot.
8
3. Push the card in. You can hear a click when the card locks into
place.
4. Close the door. You cannot use the memory card if the door is
open.
Eject the memory card
1. Before you eject the card, press , and select Remove mem. card. All
applications are closed.
2. When Remove memory card and press ‘OK’ is displayed, open the door of
the memory card slot.
3. Press the memory card to release it from the slot.
4. Remove the memory card. If the device is switched on, select OK.
Important: Do not remove the memory card in the middle of an operation
when the card is being accessed. Removing the card in the middle of an operation
may damage the memory card as well as the device, and data stored on the card
may be corrupted.
Transfer content from another device
To use the Data transfer application, see the user guide.
9
Nokia Content Copier is available in Nokia PC Suite to copy content from a
compatible Nokia phone. See the CD-ROM supplied with your device. Nokia Content
Copier supports several Nokia phone models. For more information on the devices
supported by each Nokia PC Suite, refer to the www.nokia.com/pcsuite pages.
Take pictures
You can use both cameras to take still
pictures and record videos. The secondary
camera on the front is used in portrait
mode, and the main camera on the back
in landscape mode.
1. To start the main camera, open the slide. The viewfinder opens in landscape
mode. To zoom in and out, press the zoom key.
2. To take a picture, press the capture key. The picture is automatically saved to
Gallery.
• To record video, select Switch to video mode from the active toolbar.
• To use the secondary camera, select Options > Use secondary camera.
The viewfinder opens in portrait mode.
• To send a picture you have just taken, select Send from the active toolbar.
10
Active toolbar in camera and gallery
The active toolbar shows shortcuts during camera use. Scroll to items,
and press . If you want the active toolbar to be visible only a while
when you need it, select Options > Hide icons. You can activate the
active toolbar by pressing .
Share your pictures
1. To send a picture you have just taken, select or press .
2. Select Options > Send > via multimedia. The MMS editor opens.
3. Enter recipients or groups from contacts, or enter the recipient’s phone number
4. Press to send the message.
You can also send video clips and choose other sending methods such as e-mail,
Bluetooth connectivity, and infrared. You can also upload your photos and video
clips into your online album. You cannot send video clips that are saved in the .mp4
format in a multimedia message.
Print your pictures
You can print pictures in these ways:
• On a compatible printer using the USB cable (PictBridge compatible printer
required) or Bluetooth connectivity (Bluetooth Printing Profile compatible printer
