Nokia N Series Hoja de especificaciones

Nokia, Nokia Connecting People, Nseries, N78, Navi, and Nokia Care are trademarks or registered trademarks of Nokia Corporation. Other product and

company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia

is prohibited.

9205913/Issue 3

Keys and parts (front)

1— Power key

2— Nokia AV Connector (3.5 mm) for compatible

headsets, and headphones

3— Earpiece

4— Selection keys

5— Call key

6— Menu key

7— Numeric keypad

8— Microphone

9— Navi™ wheel. Hereinafter referred to as the

scroll key.

10 — Clear key C

11 — Multimedia key

12 — End key

13 — Light sensor

14 — Secondary camera

Keys and parts (back)

2— Zoom/Volume key

3— 2-stage capture key for auto-focus, still image

capture, and video recording

4— LED flash

5— Main camera for high resolution (up to 3.2

megapixels) image capture and video recording

6— Micro USB connector to connect to a compatible

computer

7— Memory card slot for a compatible microSD card

8— Charger connector

10 — Hole for a wrist strap

1 and 9 — Stereo speakers with 3-D sound effect

Insert (U)SIM card and battery

A USIM card is an enhanced version of the SIM card

and is supported by UMTS mobile phones.

Always switch the device off and disconnect the

charger before removing the battery.

1. With the back of the

device facing you,

press and hold the

release button and

lift up the cover.

2. Insert the SIM card

into the card holder.

Ensure that the

bevelled corner on the

card is facing toward

the slot, and that the

contact area on the

card is facing down.

3. Insert the battery.

4. To replace the cover,

direct the top locking

catch toward its slot

first and then press

down until the cover

locks into place.

Switch the device on

1. Press and hold the power key.

2. If the device asks for a PIN code

or lock code, enter it, and press

the left selection key. The

factory setting for the lock

code is 12345.

Your device has internal

antennas.

Note: Your device may

have internal and external antennas. As with any

radio transmitting device, avoid touching the

antenna unnecessarily when the antenna is in use.

Contact with such an antenna affects the

communication quality, may cause the device to

operate at a higher power level than otherwise

needed and may reduce the battery life.

1— Bluetooth and wireless LAN antenna, and GPS

receiver

2— FM transmitter antenna

3— Cellular antenna

Note: The Bluetooth, WLAN, GPS, and FM transmitter

antennas are in the back cover of your device. If you

change the back cover, verify that you have a

genuine Nokia part intended for use with this

device, or these connections may stop working.

Memory card

Use only compatible microSD cards

approved by Nokia for use with this

device. Nokia uses approved industry

standards for memory cards, but some brands may

not be fully compatible with this device.

Incompatible cards may damage the card and the

device and corrupt data stored on the card.

Insert the memory card

Keep all memory cards out of the reach of small

children.

A memory card may be already inserted in the

device. If not, do the following:

1. Place your finger in the recess beside the door of

the memory card slot, and lift the door. Pull the

door to the left to reveal the hinge, and swing

the door to the side.

2. Insert a

compatible

memory card in

the slot. Make

sure that the

contact area on

the card is

facing down and

towards the

slot.

3. Push the card in.

You can hear a click

when the card

locks into place.

4. Push the hinge

back in, and close

the door. Ensure that the door is properly closed.

Eject the memory card

Important: Do not remove the memory card

in the middle of an operation when the card is being

accessed. Removing the card in the middle of an

operation may damage the memory card as well as

the device, and data stored on the card may be

corrupted.

1. Before you eject the card, press the power key,

and select Remove memory card. All

applications are closed.

2. When Removing memory card will close all

open applications. Remove anyway? is

displayed, select Yes.

3. When Remove memory

card and press 'OK' is

displayed, open the door of

the memory card slot.

4. Press the memory card to

release it from the slot.

5. Pull out the memory card. If

the device is switched on, select OK.

Charge the battery

1. Connect a compatible

charger to a wall

outlet.

2. Connect the power

cord to the device. If

the battery is

completely

discharged, it may

take a while before the charging indicator starts

scrolling.

3. When the battery is fully charged, the charging

indicator stops scrolling. Disconnect the charger

from the device, then from the wall outlet.

Tip: Disconnect the charger from the wall

outlet when the charger is not in use. A

charger that is connected to the outlet

consumes power even when it is not

connected to the device.

Navi™ wheel

Use the scroll key to move around the menus and

lists (up, down, left, or right). Press the scroll key to

select the action shown on top of the key or to show

the most used options .

When the Navi™ wheel setting is switched on in the

settings, you can scroll quickly through Photos,

Music Player, Nokia Video Centre, Contacts, and

Messaging lists, or the multimedia menu.

1. Move the tip of your finger gently around the rim

of the scroll key clockwise or counterclockwise.

Keep moving your finger until scrolling starts on

the display.

2. To continue scrolling, slide your

finger around the rim of the

scroll key clockwise or

counterclockwise.

To turn the Navi wheel setting on

or off, press , and select Tools >

Settings > General > Navi wheel > Navi

wheel.

Sleep mode indicator

When the device is on standby, the rim inside the

Navi wheel lights up slowly. The light varies

periodically as if the device was breathing. The

breathing is quicker if there are missed calls or

received messages.

To turn off breathing, press , and select Tools >

Settings > General > Navi wheel >

Breathing.
