Nokia E7 Manual de usuario

Nokia E7 User Guide

9223790

Issue 1

Cyan

Magenta

Yellow

Black

Contents

Safety 3

Start using your device 4

About this user guide 4

Use the in-device user guide 4

Get started 4

Keys and parts 4

Change the volume of a call, song, or

video 6

Lock or unlock the keys and screen 7

Flashlight 7

Insert or remove the SIM card 7

Charge your device 8

Switch the device on or off 9

Nokia account and Nokia's Ovi

services 9

Device set-up 9

Touch screen actions 10

Keyboard shortcuts 11

Interactive home screen

elements 12

Predefined home screens 12

Call a phone number 13

Search for a contact 13

Save phone numbers and mail

addresses 13

Send a message 13

Mail 14

About Mail 14

Add a mailbox 14

Use separate calendars for work and

free time 15

Navigate to a destination 15

Personalise your device 16

Personalise your tones 16

Personalise the home screen 16

Add items to the home screen 16

Install Nokia Ovi Suite on your PC 17

Visit Nokia's Ovi Store 18

Back up files 18

Connect a USB mass storage

device 18

Find more help 19

Support 19

Keep your device software and

applications up to date 19

Access codes 20

Protect the environment 21

Save energy 21

Recycle 21

Product and safety information 21

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Safety

Read these simple guidelines. Not

following them may be dangerous or

illegal. Read the complete user guide for

further information.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when

mobile phone use is not

allowed or when it may cause

interference or danger, for

example, in aircraft, near

medical equipment, fuel,

chemicals, or blasting areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep

your hands free to operate the

vehicle while driving. Your first

consideration while driving

should be road safety.

INTERFERENCE

All wireless devices may be

susceptible to interference,

which could affect

performance.

QUALIFIED SERVICE

Only qualified personnel may

install or repair this product.

CHARGERS AND OTHER ACCESSORIES

Use only chargers and other

accessories approved by Nokia

for use with this device. Do not

connect incompatible

products.

KEEP YOUR DEVICE DRY

Your device is not water-

resistant. Keep it dry.

GLASS PARTS

The front cover of the device is

made of glass. This glass can

break if the device is dropped

on a hard surface or receives a

substantial impact. If the glass

breaks, do not touch the glass

parts of the device or attempt

to remove the broken glass

from the device. Stop using the

device until the glass is

replaced by qualified service

personnel.

PROTECT YOUR HEARING

Listen to a headset at a

moderate level, and do not hold

the device near your ear when

the loudspeaker is in use.

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Start using your device

1 Insert the SIM card. See "Insert or

remove the SIM card", p. 7.

2 Charge the battery. See "Charge the

battery", p. 8.

3 Press the power key. See "Switch the

device on or off", p. 9.

4 Follow the displayed start-up

instructions:

•Accept to receive Nokia tips to

find out what you can do with

your device.

•Register a Nokia account, so you

can access all Nokia's Ovi services.

See "Nokia account and Nokia's

Ovi services", p. 9.

•Copy your personal content from

your previous Nokia device to

your new device. See "Device set-

up", p. 9.

5 Personalise the home screen or main

menu. See "Personalise your

device", p. 16.

About this user guide

This short user guide helps you get started

with your device. With a shortprinted user

guide, Nokia helps save energy and paper.

Your device contains a complete in-device

user guide, which you can refer to for

additional information about your device.

To read the in-device user guide, select

Menu > Applications > User guide.

For even more support information, go to

www.nokia.com/support, or using a

mobile device, nokia.mobi/support.

Use the in-device user guide

Select Menu > Applications > User

guide.

Open the user guide from an

application

Select Options > User guide. This is not

available for every application.

Search the user guide

When the user guide is open, select

Options > Search, and enter a letter or a

word in the search field.

Switch between the user guide and an

application

Press and hold the menu key, swipe left or

right, and select the desired application.

indicates a link to a web page. Links to

related topics may be at the end of

instructions.

Get started

Keys and parts

Top

1Nokia AV connector (3.5 mm)

2Power key

3HDMI™ connector

4Charging indicator

5USB connector

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Front

1Earpiece

2Light sensor

3Menu key

4Secondary camera lens

Back

1Camera flash

2Camera lens

3Loudspeaker

4Microphone

Sides

1Lock switch

2SIM card slot

3Volume/Zoom key

4Camera key

Bottom

1Microphone

Keyboard

Your device has a full keyboard. To open

the keyboard, push the touch screen up.

The display rotates automatically from

portrait to landscape when you open the

keyboard.

www.nokia.com/support

Cyan

Magenta

Yellow

Black

1Function key. To insert special

characters printed at the top of keys,

press the function key, and then press

the corresponding key. To enter

several special characters in a row,

press the function key twice. To return

to normal mode, press the function

key.

2Shift key. To switch between the

upper and lower case modes, press

the shift key twice. To enter a single

upper case letter in lower case mode,

or a single lower case letter in upper

case mode, press the shift key, and

then press the desired alphabet key.

3Sym key. To insert special characters

not shown on the keyboard, press the

sym key, and select the desired

character. To change the writing

language, press and hold the shift key,

and then press the sym key, and select

the desired language.

4Space key

5Backspace key. To delete a

character, press the backspace key. To

delete several characters, press and

hold the backspace key.

Insert a variation of a letter

You can insert, for example, letters with

accents. To insert á, press and hold the

sym key, and then press Arepeatedly,

until the desired letter is displayed. The

order and availability of letters depends

on the selected writing language.

Insert a number or special character

that is printed at the top of a key

Press and hold the desired key.

Change the volume of a call, song, or

video

Use the volume key.

You can change the volume during a call

or when an application is active.

The built-in loudspeaker allows you to

speak and listen from a short distance

without having to hold the device to your

ear.

Activate or deactivate the loudspeaker

during a call

Select or .

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Lock or unlock the keys and screen

To avoid accidentally making a call when

your device is in your pocket or bag, lock

the keys and screen of your device.

Slide the lock switch.

Set the keys and screen to lock

automatically

1 Select Menu > Settings and

Phone > Display > Screen/keylock

time-out.

2 Define the length of time after which

the keys and screen are locked

automatically.

Flashlight

The camera flash can be used as a

flashlight. To switch the flashlight on or

off, slide and hold the lock switch for two

seconds.

The flashlight can only be used when you

are in the home screen. You can switch the

flashlight on also when you are in the

home screen and the keys and screen or

the device is locked.

Do not shine the flashlight in anyone's

eyes.

Insert or remove the SIM card

Do not attach any stickers to your SIM card.

Important: Do not use a mini-UICC

SIM card, also known as a micro-SIM card,

a micro-SIM card with an adapter, or a SIM

card that has a mini-UICC cutout (see

figure) in this device. A micro SIM card is

smaller than the standard SIM card. This

device does not support the use of micro-

SIM cards and use of incompatible SIM

cards may damage the card or the device,

and may corrupt data stored on the card.

Insert the SIM card

1 Remove the SIM card holder from the

device.

2 Turn the SIM card holder over.

3 Make sure the contact area is facing

up, and insert the SIM card into the SIM

card holder.

www.nokia.com/support

Cyan

Magenta

Yellow

Black

4 Turn the SIM card holder over and

insert it back into the device.

Remove the SIM card

1 Switch the device off.

2 Remove the SIM card holder from the

device.

3 Remove the SIM card.

4 Turn the SIM card holder over.

5 Insert the SIM card holder back into

the device.

Charge your device

About the battery

Your device has an internal,

nonremovable, rechargeable battery. Use

only Nokia approved chargers designated

for this device. You can also use a

compatible USB data cable to charge your

device.

Do not attempt to remove the battery

from the device. Take the device to the

nearest authorised service facility for

replacement of the battery.

Authorised retail points may also offer a

battery replacement service.

Important: Only qualified

personnel or an authorised service facility

should replace the battery. Unauthorised

battery replacement may invalidate your

warranty.

When your device is low on power, it goes

into power save mode. To deactivate

power save mode, press , and select

Deactivate power saving. When power

save mode is activated, you may not be

able to modify the settings of certain

applications.

Charge the battery

Your battery has been partially charged at

the factory, but you may need to recharge

it before you can switch on your device for

the first time.

If the device indicates a low charge, do the

following:

www.nokia.com/support

Cyan

Magenta

Yellow

Black

You do not need to charge the battery for

a specific length of time, and you can use

the device while it is charging.

If the battery is completely discharged, it

may take several minutes before the

charging indicator appears on the display

or before any calls can be made.

If the battery has not been used for a long

time, to begin charging, you may need to

connect the charger, then disconnect and

reconnect it.

Switch the device on or off

Press and hold .

Nokia account and Nokia's Ovi services

When you switch on your device for the

first time, you can create a Nokia account,

so you can access Nokia's Ovi services.

With Ovi services and your Nokia account,

you can, for example:

•See your friends' statuses in different

social networking services

•Download games, applications,

videos, pictures, themes, and ringing

tones from Ovi Store

•Get to where you want to go with free

walk and drive navigation

•Back up and manage your contacts in

the Ovi internet service

To learn more about Ovi, go to

www.ovi.com.

To create a Nokia account later, use your

device to access an Ovi service, and you are

prompted to create an account.

Device set-up

To define some basic settings for your

device, select the Phone setup shortcut

that is in one of your home screens.

www.nokia.com/support

Cyan

Magenta

Yellow

Black

To switch between home screens, swipe

left or right.

With Phone setup, you can do the

following:

•Copy contacts, pictures, and other

content from your previous Nokia

device

•Personalise your device, by

changing the ringing tone and visual

theme

•Set up mail

•Update your device software

To define the settings later, you can also

select Menu > Applications > Tools >

Phone setup.

Touch screen actions

To interact with the user interface, tap or

tap and hold the touch screen.

Open an application or other screen

element

Tap the application or element.

Access functions quickly

Tap and hold the item. A pop-up menu

with available options opens. For

example, to send an image or delete an

alarm, tap and hold the image or alarm,

and from the pop-up menu, select the

appropriate option.

If you tap and hold the home screen,

editing mode is activated.

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Otros manuales para E7

Tabla de contenidos

Otros manuales de Teléfono móvil de Nokia

Nokia

Nokia E52 Manual de usuario

Nokia

Nokia N79 Manual de usuario

Nokia

Nokia X7 Manual de usuario

Nokia

Nokia 2855i Manual de usuario

Nokia

Nokia C2-03 Manual de usuario

Nokia

Nokia Lumia 900 Manual de usuario

Nokia

Nokia 1315 Manual de usuario

Nokia

Nokia 6316s-1 Manual de usuario

Nokia

Nokia NAVIGATOR 6210 Manual de usuario

Nokia

Nokia 6230i - Cell Phone 32 MB Manual de usuario

Nokia

Nokia X1-00 Manual de usuario

Nokia

Nokia E63 Manual de usuario

Nokia

Nokia 6820 - Cell Phone - GSM Manual de usuario

Nokia

Nokia N96 Manual de usuario

Nokia

Nokia N800 - Internet Tablet - OS 2007 Manual de usuario

Nokia

Nokia X2-01 Manual de usuario

Nokia

Nokia 7610 7610 Manual de usuario

Nokia

Nokia 6310I - Cell Phone - GSM Manual de usuario

Nokia

Nokia C6-01 Manual de usuario

Nokia

Nokia 7.1 Manual de usuario

Nokia

Nokia N73 - Smartphone 42 MB Manual de usuario

Nokia

Nokia 8390 Manual de usuario

Nokia

Nokia Lumia 1320 Manual de usuario

Nokia

Nokia 3500 - Classic Cell Phone Manual de usuario

Manuales populares de Teléfono móvil de otras marcas

Zte

Zte BLADE A520 Manual de usuario

Blackbe;rry

Blackbe;rry KEYone Manual de usuario

Bea-fon

Bea-fon X5 Premium Manual de usuario

Blackbe;rry

Blackbe;rry 8707 Series Manual de usuario

Blackbe;rry

Blackbe;rry Storm Instrucciones de funcionamiento

LG LM-X420QN Manual de usuario

LifeWatch

LifeWatch V Manual de usuario

Bea-fon

Bea-fon SILVER LINE SL860 Manual de usuario

IKI Mobile

IKI Mobile KF4.5i Manual de usuario

Hitech

Hitech HT-850 Manual de usuario

Yezz

Yezz Fashion F10 Manual de usuario

Point Mobile

Point Mobile PM60 Manual de usuario

Blackbe;rry

Blackbe;rry Q10 Manual de usuario

Blackbe;rry

Blackbe;rry Bold 9900 Manual de usuario

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manual de usuario

LG LM-K420EMW Manual de usuario

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manual de usuario

LG Thrive Manual de usuario
