Nokia E66 Manual de usuario

Get started

Step 1

Insert the SIM card and battery

Use only microSDHC and microSD cards approved by Nokia for use with

this device. Nokia utilises the approved industry standards for memory

cards but not all other brands may function correctly or be fully

compatible with this device.

Memory card may already be inserted in your device.

There are applications installed on the memory card. To

access them, select Menu > Installations.

To remove the memory card, press the end of it.

Do not remove the memory card in the middle of an

operation when the card is being accessed. This may

damage the memory card as well as the device, and

data stored on the card may be corrupted.

Step 2

Charge the battery

1Connect a compatible charger to a wall

outlet.

2Connect the power cord to the device. If the

battery is completely discharged, it may take

a while before the charging indicator starts

scrolling.

3When the battery is fully charged according

to the battery level indicator , disconnect

the charger from the device, then from the wall outlet.

First start-up

1Press and hold the power key .

2If prompted, enter the PIN code or lock code, and select OK.

3When prompted, enter the country in which you are located and the current date

and time. The Welcome application opens.

4Select from the various options, or Exit to close the application.

To configure the various settings in your device, use the wizards available on the

home screen and the Settings wizard application (Menu > Tools > Setting wizard).

When you switch the device on, it may recognise the SIM card provider and

configure some settings automatically. You can also contact your service provider for

the correct settings.

You can switch the device on without inserting the SIM card. The device starts up in

the offline mode, and you cannot use the network-dependent phone functions.

To switch the device off, press and hold the power key.

Keys and parts

1Power key

2Earpiece

3Light sensor

4Selection key. Press the selection key to perform

the function shown above it on the display.

5Call key

6Press and hold the key for a few seconds to

switch on Bluetooth. When writing text, press

the key and select More symbols to access

special characters.

7Microphone

8Camera (video calls only)

9NaviTM scroll key, hereafter referred to as the

scroll key. Press the scroll key to make a

selection, or to scroll left, right, up, and down on

the display. A long press left, right, up, or down

accelerates the scrolling.

10 End key. Press the end key to reject a call, and

to end active calls and calls on hold. With a long keypress, end data connections.

11 Backspace key. Press the key to delete items.

12 Shift key. When writing text, press and hold the key and select the text with the

scroll key. Press and hold this key for a few seconds to toggle between the Silent

and General profile.

13 Charger connector

Sides

1Volume up key

2Voice key. Press the voice key to mute and unmute the

active call. The voice key is also used in the Voice

commands and PTT applications.

3Volume down key

4Capture key

5Release button

6Headset connector

7Micro-USB connector

8Infrared port

Automatic display rotation

In all applications, the screen rotates automatically from portrait to landscape when

you turn the device to the left. For example, if you are browsing the web and turn

the device to the left, the image rotates accordingly and changes to full screen. To

display the control and status panes, press either selection key. The image changes

to full screen in RealPlayer, browser, and image viewer.

Illuminated One-touch keys

With the One-touch keys, you can access applications and

tasks quickly. Each key has been assigned an application and a

task. To change the tasks for contacts, calendar, and e-mail

keys, select Menu > Tools > Settings > General >

Personalisation > One-touch keys.

Key Short press 2nd short press Long press

Home key (1) Access the home

screen Open the menu

View the list of

active applica-

tions

Contacts key (2) Open the Con-

tacts application

Return to the

previous applica-

tion

Create a contact

Calendar key (3) Open the Calen-

dar application

Return to the

previous applica-

tion

Create a meeting

entry

E-mail key (4) Open your

default mailbox

Return to the

previous applica-

tion

Create an e-mail

message

Special features in your device

Slide function

To open or close the full-size keypad, push the slide up or down.

When you close the keypad, it locks. To unlock the keypad, open the

slide. To unlock the keypad without opening the slide, press the left

and then the right selection key.

You can end a call by closing the slide, unless you have a headset

connected to the device, or you select Options before closing the

keypad.

To change slide settings, select Menu > Tools > Settings > General

> Slide handling.

Scroll key lights

When you receive a message or miss a call, the scroll key starts blinking to indicate

the event. When the display light turns off, the scroll key starts blinking slowly.

The keypad lights turn on and off simultaneously with the display light.

Silence the device

To set calendar and clock alarms to snooze and to silence

incoming calls, turn the device face down.

Shortcut keys

To access the profiles, press the power key briefly.

To see the clock when the keypad is locked and the display light is off, press the scroll

key.

On the home screen, press 0to go to the web.

In the image viewer, press 5 to zoom in or 0 to zoom out, 1 or 3 to rotate the image,

or * to go to full screen.

In Camera, press volume up or down to zoom in or out, and camera key to capture

images with autofocus or the scroll key to capture images without autofocus.

Home screen

From the home screen you can quickly access features that you use the most, and

see at a glance any missed calls or new messages.

The home screen consists of the following:

1Application shortcuts. To access an application,

scroll to its shortcut and press the scroll key.

2Information area. To check an item displayed in

the information area, scroll to it and press the

scroll key.

3Notification area. To view the notifications,

scroll to a box. A box is only visible if there are

items in it.

You can define two separate home screens for

different purposes, such as one screen to show your

business e-mail and notifications, and another to

show your personal e-mail. This way, you do not

have to see business-related messages outside

office hours.

To change from one home screen to another, scroll

to and press the scroll key.

To define what kind of items and shortcuts you want

to see on the home screen, and to set the

appearance of the home screen, select Menu >

Tools > Modes.

Access tasks quickly

Whenever you see the icon on the home screen,

or in the Contacts or Calendar applications, scroll

right to access a list of available actions. To close the

list, scroll left.

When you navigate in these applications, to go back

to the previous level, scroll left.

Set up your e-mail

With the e-mail wizard, you can set up your business e-mail account, such as

Microsoft Outlook, or Microsoft Exchange; and internet e-mail account, such as

Google e-mail services.

To start the e-mail wizard:

1Go to the home screen, scroll to the e-mail wizard, and press the scroll key.

2Enter your e-mail address and password. If the wizard is not able to configure

your e-mail settings automatically, select your e-mail account type and enter

the related settings.

If your device contains any additional e-mail clients, those are offered to you when

you start the e-mail wizard.

When setting up your e-mail, you may be prompted for the following information:

user name, e-mail type, incoming mail server, incoming mail server port, outgoing

mail server, outgoing mail server port, password, or access point.

If you are setting up your business e-mail, ask your company IT department for

details. If you are setting up your internet e-mail, see your e-mail service provider’s

website for details.

Set up your net calls

With the net call service (network service), you can make and receive calls over the

internet using the VoIP (voice over internet protocol) technology.

In the home screen, scroll to Set up Internet tel. and press the scroll key. Before you

can make calls you must create a net call profile and your device must be connected

to a net call service. For more instructions, see the user guide.

Transfer content from another

device

With the Switch application, you can transfer content from a compatible Nokia

device to your new device using Bluetooth connectivity or infrared. The type of

content that can be transferred depends on the device model. Select Menu > Tools

> Switch, and follow the instructions on the device display. If the other device

supports synchronisation, you can also synchronise data between the two devices.

Download!

Select Menu > Download!

With Download!, you can browse, download, and install items, such as the latest

applications and related documents, to your device from the web. The items are

categorised under catalogues and folders provided by Nokia or independent service

providers. Some items may be chargeable, but you can usually preview them free of

charge.

Download! uses your network services to access the most up-to-date content. For

information on additional items available through Download!, contact your service

provider, or the supplier or manufacturer of the item.

Only install and use applications and other software from sources that offer

adequate security and protection against harmful software.

GPS

The Global Positioning System (GPS) is a worldwide radio navigation system. Your

device has an internal GPS receiver.

Maps

Select Menu > GPS > Maps.

Check the availability of this function from your local network operator.

With maps, you can see your current location on the map, browse maps for different

cities and countries, search for addresses and different point of interest, plan routes

from one location to another, and save locations as landmarks and send them to

compatible devices.

You can also purchase extra services, such as guides and a turn-by-turn navigation

service with voice guidance.

Further

information

User guidance

Your device has a tutorial, which

provides you information about your

device and shows you how to use it.

Select Menu > Help > Tutorial.

Your device has a help function, which

provides you detailed instructions and

information. Select Options > Help.

For other important information about

your device, see the user guide.

Nokia PC Suite

You can install Nokia PC Suite from the

CD-ROM or from the web. Nokia PC

Suite can be used with Windows XP

SP2, and Windows Vista. With Nokia PC

Suite, you can back up data in your

device, synchronise your device with a

compatible computer, move files

between your device and a compatible

computer, or use your device as a

modem.

Nokia support and contact

information

Check www.nokia-asia.com/support or

your local Nokia web site for the latest

version of the user guide, additional

information, downloads, and services

related to your Nokia product.

The website provides information on

the use of Nokia products and services.

If you need to contact customer

service, check the list of local Nokia

contact centres on www.nokia-

asia.com/contactus.

For maintenance services, check your

nearest Nokia service centre on

www.nokia-asia.com/repair.

Nokia, Nokia Connecting People,

Eseries, Nokia E66, and Navi are

trademarks or registered trademarks of

Nokia Corporation. Other company

names mentioned herein may be

trademarks or trade names of their

respective owners.

Otros manuales para E66

Tabla de contenidos

Otros manuales de Teléfono móvil de Nokia

Nokia

Nokia NPD-4 Series Guía

Nokia

Nokia Lumia 720 Manual de usuario

Nokia

Nokia N97 Manual de usuario

Nokia

Nokia 5330 Mobile TV Edition Manual de usuario

Nokia

Nokia X3 Manual de usuario

Nokia

Nokia E72 Manual de usuario

Nokia

Nokia Cellphone 3555c Manual de usuario

Nokia

Nokia 2610 - Cell Phone 3 MB Manual de usuario

Nokia

Nokia 150 Manual de usuario

Nokia

Nokia TA-1343 Hoja de especificaciones

Nokia

Nokia 5710 XpressAudio Manual de usuario

Nokia

Nokia TFE-4 Manual de usuario

Nokia

Nokia N85 Hoja de especificaciones

Nokia

Nokia 1616 Manual de usuario

Nokia

Nokia 6800 Manual de usuario

Nokia

Nokia 5500 Manual de usuario

Nokia

Nokia 1661 Manual de usuario

Nokia

Nokia 1255(RH-79) Manual de usuario

Nokia

Nokia 8265i Manual de usuario

Nokia

Nokia 7250i Manual de usuario

Nokia

Nokia XL Manual de usuario

Nokia

Nokia 6650 - Smartphone 40 MB Manual de usuario

Nokia

Nokia 9300 Manual de usuario

Nokia

Nokia NHL-10 Manual de servicio

Manuales populares de Teléfono móvil de otras marcas

Zte

Zte BLADE A520 Manual de usuario

Blackbe;rry

Blackbe;rry KEYone Manual de usuario

Bea-fon

Bea-fon X5 Premium Manual de usuario

Blackbe;rry

Blackbe;rry 8707 Series Manual de usuario

Blackbe;rry

Blackbe;rry Storm Instrucciones de funcionamiento

LG LM-X420QN Manual de usuario

LifeWatch

LifeWatch V Manual de usuario

Bea-fon

Bea-fon SILVER LINE SL860 Manual de usuario

IKI Mobile

IKI Mobile KF4.5i Manual de usuario

Hitech

Hitech HT-850 Manual de usuario

Yezz

Yezz Fashion F10 Manual de usuario

Point Mobile

Point Mobile PM60 Manual de usuario

Blackbe;rry

Blackbe;rry Q10 Manual de usuario

Blackbe;rry

Blackbe;rry Bold 9900 Manual de usuario

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manual de usuario

LG LM-K420EMW Manual de usuario

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manual de usuario

LG Thrive Manual de usuario
