Nokia C3-01 Manual de usuario
Nokia C3–01 User Guide
Issue .0
2
Contents
Safety 4
Get started 5
Keys and parts 5
Insert the SIM card and battery 6
Insert or remove a memory card 7
Charge the battery 7
Charge the battery over USB 8
GSM antenna 9
Attach a strap 9
Attach the stylus 10
Switch it on 10
Network services and costs 10
Access codes 10
Switch the device on or off 11
Lock the keys and screen 11
Touch screen actions 11
Touch screen settings 13
Interactive home screen elements 13
Change the volume of a call, song, or
video 13
Indicators 14
Copy contacts or pictures from your old
device 14
Functions without a SIM card 15
Use your device offline 15
Flashlight 16
Device management 16
Support 16
My Nokia 16
Update device software using your
device 17
Restore original settings 17
Organise files 18
Synchronise your calendar and contacts
with Ovi by Nokia 18
Back up your pictures and other content
to a memory card 18
Telephone 19
Make a call 19
View your missed calls 19
Call the last dialled number 19
Divert calls to your voice mailbox or
another phone number 19
Save a number from a received call or
message 20
About internet calls 20
Make an internet call 20
Make a conference call 21
Allow calls only to certain numbers 22
Prevent making or receiving calls 22
Contacts 22
Save a name and phone number 22
Use speed dial 22
Send your contact information 23
Create a contact group 23
Move or copy contacts to your SIM
card 23
Write text 24
Switch between text input modes 24
Traditional text input 24
Predictive text input 25
Messaging 25
Send a message 25
Send a message to a group of
people 26
Save an attachment 26
View a conversation 27
Listen to voice messages 27
Send an audio message 27
Mail and Instant Messaging 28
Nokia Messaging mail 28
Nokia Messaging IM 29
2Contents
Personalisation 30
About the home screen 30
Add a shortcut to the home screen 31
Add your important contacts to the
home screen 31
Personalise the Go to menu 31
Personalise the home screen 32
Change the look of your device 32
Create your own profile 32
Personalise your tones 32
Connectivity 33
Connectivity security 33
Bluetooth 33
USB data cable 36
Connect to a WLAN 37
Nokia's Ovi services 38
Ovi by Nokia 38
Access Nokia's Ovi services 39
About Nokia Ovi Suite 39
Ovi Player 39
Time management 40
Change the time and date 40
Set an alarm 40
Snooze an alarm 40
Time your workout 40
Set the countdown timer 41
Calendar 41
Make a shopping list 42
Lunar calendar 42
Pictures and videos 43
Take a picture 43
Record a video 43
Send a picture or video 43
Photos 44
Print a picture 44
Music and audio 45
Media player 45
FM radio 47
Use voice recorder 49
Web 49
About the web browser 49
Browse the web 49
Clear browsing history 50
Games and applications 50
About games and applications 50
Improve your gaming experience 50
Download a game or application 50
About Communities 51
Use the calculator 51
Convert currency and
measurements 51
Protect your device 52
Lock your device 52
Password protect your memory
card 53
Format a memory card 53
Prepare your device for recycling 53
Green tips 54
Save energy 54
Recycle 54
Nokia original accessories 54
Practical rules about accessories 55
Battery 55
Product and safety information 56
Index 72
Contents 3
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES AND OTHER ACCESSORIES
Use only batteries, chargers and other accessories approved by Nokia for use
with this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do not hold the device near your
ear when the loudspeaker is in use.
4Safety
Get started
Keys and parts
1Earpiece
2Display
3Call key
4Microphone
5End/Power key
6Keypad
7Nokia AV connector (3.5 mm)
8Micro USB connector
9Volume up key
10 Volume down key
11 Keylock button
12 Camera key
13 Loudspeaker
Get started 5
14 Camera flash
15 Camera lens
16 Charger connector
To ensure optimum performance, remove the protective foil that covers, for example,
the display and the camera lens.
Insert the SIM card and battery
This device is intended for use with a BL-5CT battery. Always use original Nokia batteries.
The SIM card and its contacts can be easily damaged by scratches or bending, so be
careful when handling, inserting, or removing the card.
1 Slide the cover, and remove it. If the battery is inserted, lift the battery out.
2 Insert a SIM card. Make sure the contact area of the card is facing down.
3 Line up the contacts of the battery and the battery compartment, and insert the
battery. To replace the back cover, direct the top locking catches toward their slots,
and slide the cover, until it locks into place.
6Getstarted
Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card,
device does
cards may damage
and may corrupt data stored on the card.
a
micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure)
smaller than the standard SIM card. This
in this device. A micro SIM card is
not support the use of micro-SIM cards and use of incompatible SIM
the card or the device,
Insert or remove a memory card
Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on the
card.
Your device supports memory cards with a capacity of up to 32 GB.
Insert a memory card
1 Remove the back cover.
2 Make sure the contact area of the card is facing down. Push the card in, until you
hear a click.
3 Replace the back cover.
Remove the memory card
You can remove or replace the memory card without switching the device off.
1 Remove the back cover.
2 Push the card in, until you hear a click, and pull the card out.
3 Replace the back cover.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge it
before you can switch on your device for the first time.
If the device indicates a low charge, do the following:
Get started 7
Important: Do not remove the memory card when an application is using it.
Doing so may damage the memory card and the device, and corrupt data stored on the
card.
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the charger from the device,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use the
device while it is charging.
If the battery is completely discharged, it may take several minutes before the charging
indicator appears on the display or before any calls can be made.
If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then disconnect and reconnect it.
Charging the device while listening to the radio may affect the quality of reception.
Charge the battery over USB
Battery low, but you don't have a charger with you? You can use a compatible USB cable
to connect to a compatible device, such as a computer.
To avoid breaking the charger connector, be careful when connecting or disconnecting
the charger cable.
Charging over USB can take longer to start, and may not work if you connect through a
non-powered USB hub. Your device charges more quickly when connected to a wall
outlet.
If connected to a computer, you can synchronise your device while charging.
8Getstarted
GSM antenna
The figure shows the GSM antenna area marked in grey.
Avoid touching the antenna area unnecessarily while the antenna is transmitting or
receiving. Contact with antennas affects the communication quality and may cause a
higher power level during operation and may reduce the battery life.
Attach a strap
Get started 9
Attach the stylus
Tip: Attach the stylus to the device as you would a wrist strap.
Switch it on
Network services and costs
Your device is approved for use on the GSM 850/900/1800/1900 MHz networks and
WCDMA 850/900/1900/2100 MHz networks. To use the device, you need a subscription
with a service provider.
Using network services and downloading content to your device may result in data
traffic costs. Some product features require support from the network, and you may
need to subscribe to them.
Access codes
PIN code — This code protects your SIM card against unauthorised use. The PIN code (4
- 8 digits) is usually supplied with the SIM card.
PIN2 code — This code (4 - 8 digits) is supplied with some SIM cards, and is required to
access some functions in your device.
If you forget an access code, contact the network service provider whose SIM card is in
your device. After three consecutive incorrect PIN or PIN2 code entries, the code is
blocked, and you need the PUK code to unblock it.
10 Switch it on
Important: Use only a stylus approved by Nokia for use with this device. Using
any other stylus may invalidate any warranty applying to the device and may damage
the touch screen. Avoid scratching the touch screen. Never use an actual pen or pencil
or other sharp objects to write on the touch screen.
