Nokia C1-01 Manual de usuario

Nokia C1-01/C1–02 User Guide

Issue 1.3

Contents

Safety 4

Support 5

Get started 5

Insert the SIM card and battery 5

Keys and parts 6

Switch on or off 6

Charge the battery 6

Antennas 7

Headset 7

Insert a memory card 8

Remove the microSD card 8

Connect a USB data cable 9

Attach the wrist strap 9

Access codes 10

Keypad lock 10

Use your device without a SIM card 11

Applications running in background 11

Calls 11

Make and answer a call 11

Loudspeaker 11

Dialling shortcuts 12

Write text 12

Text modes 12

Traditional text input 12

Predictive text input 12

Navigate the menus 13

Messaging 13

Text and multimedia messages 13

Flash messages 15

Nokia Xpress audio messages 15

Nokia Messaging Service 15

Voice messages 15

Message settings 16

Contacts 16

Photos 17

Capture images and record video

clips 17

View your images and video clips 18

Music 18

Music player 18

FM radio 19

Call log 20

Web or Internet 20

Connect to a web service 20

Settings 21

Profiles 21

Tones 21

Display 21

Date and time 21

Shortcuts 21

Synchronisation and backup 22

Connectivity 22

Call and phone 23

Accessories 24

Configuration 24

Restore factory settings 24

Applications 25

Alarm clock 25

Gallery 25

Extras 25

Voice recorder 26

To-do list 26

Operator menu 26

SIM services 26

Green tips 27

Save energy 27

2Contents

Recycle 27

Product and safety information 27

Index 35

Contents 3

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read

the complete user guide for further information.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may

cause interference or danger, for example, in aircraft, near medical

equipment, fuel, chemicals, or blasting areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while

driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect

performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do not hold the device near your

ear when the loudspeaker is in use.

4Safety

Support

When you want to learn more about how to use your product or you are unsure how

your device should function, go to www.nokia.com/support, or using a mobile device,

nokia.mobi/support.

If this does not resolve your issue, do one of the following:

•Reboot your device. Switch off the device, and remove the battery. After about a

minute, replace the battery, and switch on the device.

•Restore the original factory settings.

•Update your device software.

If your issue remains unsolved, contact Nokia for repair options. Go to www.nokia.com/

repair. Before sending your device for repair, always back up the data in your device.

Get started

Insert the SIM card and battery

The SIM card and its contacts can be easily damaged by scratches or bending, so be

careful when handling, inserting, or removing the card.

Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card, a

micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure)

in this device. A micro SIM card is smaller than the standard SIM card. This device does

not support the use of micro-SIM cards and use of incompatible SIM cards may damage

the card or the device, and may corrupt data stored on the card.

1 Place your finger in the recess at the bottom of the device, and carefully lift and

remove the back cover (1).

2 If the battery is inserted, lift the battery out (2).

3 Insert the SIM card. Make sure the contact area of the card is facing down (3, 4).

4 Line up the contacts of the battery and the battery compartment, and insert the

battery (5). To replace the back cover, direct the top locking catches toward their

slots (6), and press down until the cover locks into place (7).

Support 5

Safe removal. Always switch the device off and disconnect the charger before removing

the battery.

Keys and parts

1Headset connector (3.5 mm)

2Earpiece

3Display

4Selection keys

5Navi™ key (scroll key)

6Call key

7End/Power key

8Keypad

9Charger connector

10 Micro USB connector

11 Loudspeaker

12 Camera lens (Nokia C1–01 only)

13 Microphone

Switch on or off

Press and hold the power key.

Charge the battery

Your battery has been partially charged at the factory. If the device indicates a low

charge, do the following:

1 Connect the charger to a wall outlet.

2 Connect the charger to the device.

6Getstarted

3 When the device indicates a full charge, disconnect the charger from the device,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the

device while it is charging. If the battery is completely discharged, it may take several

minutes before the charging indicator appears on the display or before any calls can be

made.

Antennas

Your device may have internal and external antennas. Avoid touching the antenna area

unnecessarily while the antenna is transmitting or receiving. Contact with antennas

affects the communication quality and may cause a higher power level during operation

and may reduce the battery life.

Headset

Warning:

When you use the headset, your ability to hear outside sounds may be affected. Do not

use the headset where it can endanger your safety.

When connecting any external device or any headset, other than those approved by

Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume

levels.

Do not connect products that create an output signal as this may cause damage to the

device. Do not connect any voltage source to the Nokia AV Connector.

Get started 7

Insert a memory card

Use only compatible microSD cards approved by Nokia for use with this device. Nokia

uses approved industry standards for memory cards, but some brands may not be fully

compatible with this device. Incompatible cards may damage the card and the device

and corrupt data stored on the card.

Your phone supports microSD cards with a capacity of up to 32 GB.

A compatible memory card may be supplied with the device, and may already be

inserted in the device. If not, do the following:

1 Open the back cover.

2 Make sure the contact area of the card is facing down. Push the card in, until you

hear a click.

3 Replace the back cover.

Remove the microSD card

Important: Do not remove the memory card during an operation when the card

is being accessed. Doing so may damage the memory card and the device, and corrupt

data stored on the card.

You can remove or replace the memory card during phone operation without switching

the device off, but you need to ensure that no application is currently accessing the

memory card.

8Getstarted

Connect a USB data cable

Connect a compatible USB data cable to the USB connector. You may need to purchase

a USB data cable separately.

To modify the USB settings, select Menu > Settings > Connectivity > USB data

cable and the desired mode.

Attach the wrist strap

Thread the wrist strap, and tighten it.

Nokia C1–01:

Nokia C1–02:

Get started 9

Access codes

The security code helps to protect your device against unauthorised use. The preset

code is 12345. You can create and change the code, and set the device to request the

code. Keep the code secret and in a safe place separate from your device. If you forget

the code and your device is locked, your device will require service. Additional charges

may apply, and all the personal data in your device may be deleted. For more

information, contact a Nokia Care point or your device dealer.

The PIN code supplied with the SIM card protects the card against unauthorised use.

The PIN2 code supplied with some SIM cards is required to access certain services. If you

enter the PIN or PIN2 code incorrectly three times in succession, you are asked for the

PUK or PUK2 code. If you do not have them, contact your service provider.

The module PIN is required to access the information in the security module of your SIM

card. The signing PIN may be required for the digital signature. The barring password

is required when using the call barring service.

To set how your device uses the access codes and security settings, select Menu >

Settings > Security.

Keypad lock

To prevent accidental keypresses, select Menu, and press *within 3.5 seconds to lock

the keypad.

To unlock the keypad, select Unlock, and press *within 1.5 seconds. If the security

keyguard is activated, enter the security code when requested.

To set the keypad to lock automatically after a defined length of time when the device

is not being used, select Menu > Settings > Phone > Automatic keyguard > On.

To answer a call when the keypad is locked, press the call key. When you end or reject

a call, the keypad locks automatically.

When the device or keypad is locked, calls may be possible to the official emergency

number programmed into your device.

10 Get started
