Nokia 6275 Manual de usuario

Nokia Customer Care

6275/6275i (RM-154)

Mobile Terminals

Issue 1 - September 2006 Company Confidential

Assembly

6275/6275i (RM-154)

Assembly Nokia Customer Care

Page 2 Company Confidential Issue 1 - September 2006

Contents Page

Safety Information ......................................................................................................................................... 3

ESD Protection .............................................................................................................................................3

Assembly Instructions ................................................................................................................................... 4

1. Insert the Camera Module ...................................................................................................................4

2. Insert the Camera Key and Volume/Zoom Key ...............................................................................5

3. Insert the Battery Floor .........................................................................................................................6

5. Insert the Microphone and DC Jack ..................................................................................................6

6. Insert the Flash Module ........................................................................................................................7

7. Insert the IHF Speaker and IHF Module ...........................................................................................7

8. Insert the LCD Module and PWB ........................................................................................................8

9. Assemble the UI Module and Keymat ...............................................................................................9

10. Insert the A-Cover, Antenna Cover, and B-Cover .....................................................................11

Nokia Customer Care Assembly

6275/6275i (RM-154)

Issue 1 - September 2006 Company Confidential Page 3

Safety Information

Adhere to the following guidelines when assembling and disassembling the mobile

terminal.

•QUALIFIEDSERVICE

Only qualified personnel may install or repair mobile terminal equipment.

• ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible

products.

• CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user’s guide for detailed safety

instructions. Do not connect incompatible products.

ESD Protection

Nokia requires that mobile terminal repair centers have sufficient ESD protection against

static electricity when servicing mobile terminals. Use the following guidelines:

• A mobile terminal that is ready for use can be handled normally without ESD

protection. The battery can be replaced in normal conditions of use.

• Use ESD protection when replacing a color cover, except for the mobile terminal

covers which can be replaced by the customer.

• All electronic parts of the mobile terminal, including the display, are susceptible

to ESD. Resistors also can be damaged by static electricity discharge.

• All ESD-sensitive parts must be packed in metallized protective bags during

shipping and handling outside any ESD Protected Area (EPA).

• Every repair action involving opening the mobile terminal or handling the mobile

terminal components must be done under ESD protection.

• ESD-protected spare part packages MUST NOT be opened/closed outside an EPA.

For more detailed information about ESD protection and EPAs, contact your local Nokia

Customer Care representative.

6275/6275i (RM-154)

Assembly Nokia Customer Care

Page 4 Company Confidential Issue 1 - September 2006

Assembly Instructions

Use the following steps to assemble the mobile terminal.

1. Insert the Camera Module

Use a soldering jig or the C-cover assembly as support to replace the camera module.

Ensure that the notch on the camera module aligns properly with the slot on the PWB.

Insert the camera module.

Nokia Customer Care Assembly

6275/6275i (RM-154)

Issue 1 - September 2006 Company Confidential Page 5

Ensure that the camera fastens in place evenly.

2. Insert the Camera Key and Volume/Zoom Key

Use tweezers to insert the camera key.

Use tweezers to insert the volume and zoom key.

6275/6275i (RM-154)

Assembly Nokia Customer Care

Page 6 Company Confidential Issue 1 - September 2006

3. Insert the Battery Floor

Insert the battery floor, and click all of the snaps into their latches.

5. Insert the Microphone and DC Jack

Insert the microphone, and lock it into the assembly.

Nokia Customer Care Assembly

6275/6275i (RM-154)

Issue 1 - September 2006 Company Confidential Page 7

Use the DC plug to insert the DC jack into the assembly.

6. Insert the Flash Module

Insert the flash module. Ensure that the plastic clips are click into their places correctly.

7. Insert the IHF Speaker and IHF Module

Use the tweezers to insert the earpiece into the IHF module.

6275/6275i (RM-154)

Assembly Nokia Customer Care

Page 8 Company Confidential Issue 1 - September 2006

Insert the IHF module into the D-cover. Ensure that all the snaps click into place.

8. Insert the LCD Module and PWB

Replace the adhesive on the assembly.

Align the guide tabs on the LCD module with the grooves in the assembly.

Nokia Customer Care Assembly

6275/6275i (RM-154)

Issue 1 - September 2006 Company Confidential Page 9

Assemble the PWB onto the D-cover.

Carefully align and press down on the flex connector until it snaps to the PWB.

9. Assemble the UI Module and Keymat

Align the metal clips on the UI module, and insert it into the assembly.

6275/6275i (RM-154)

Assembly Nokia Customer Care

Page 10 Company Confidential Issue 1 - September 2006

Insert the six screws.

Set the correct torque. To prevent damage to the plastic threads, turn the screws left

first, then tighten them.

Apply the correct torque in the order shown.
