Nokia 306 Manual de usuario

Nokia 306 User Guide

Issue 1.1

Contents

Safety 4

Get started 5

Keys and parts 5

Insert a SIM card and battery 6

Insert or remove a memory card 8

Charge the battery 9

Charge the battery over USB 10

Switch the phone on or off 10

GSM antenna 10

Connect a headset 11

Attach a strap 11

Basic use 11

Your touch screen phone 11

Support 14

Access codes 15

Lock the keys and screen 15

Copy contacts and other stuff from

your old phone 15

Use your phone without a SIM card 16

Switch off social notifications 16

Calls 16

Make a call 16

Divert calls to your voice mailbox or

another phone number 17

Make a conference call 17

Contacts 18

Save a name and phone number 18

Use speed dial 18

Send your contact info 18

Messaging 19

Send a message 19

Read a received message 19

Write text 20

Write text using the on-screen

keypad 20

Use the on-screen keyboard 21

Use predictive text 22

Connectivity 23

Bluetooth 23

USB data cable 24

WLAN connections 25

Clock and calendar 26

Change the time and date 26

Set an alarm 26

Browse your calendar in different

Add a calendar entry 26

Photos and videos 26

Take a photo 27

Record a video 27

Send a photo or video 27

Organise files 28

Music and audio 28

Play a song 28

FM radio 28

Phone management 30

Update phone software using your

phone 30

Update phone software using your

PC 31

Restore original settings 31

Back up your photos and other

content to a memory card 31

Web 32

About the web browser 32

Browse the web 32

Clear your browsing history 33

Maps 33

2Contents

About Maps 33

Search for a place 33

Product and safety information 34

Contents 3

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. For

further info, read the complete user guide.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may

cause interference or danger, for example, in aircraft, in hospitals or near

medical equipment, fuel, chemicals, or blasting areas. Obey all instructions

in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while

driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect

performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved by Nokia for

use with this device. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for

long periods. Exercise caution when holding your device near your ear while

the loudspeaker is in use.

4Safety

Get started

Keys and parts

1Earpiece

2Screen

3Call key

4Microphone

5Charger connector

6Micro-USB connector

7Headset connector (Nokia AV connector 3.5 mm)

8Volume up/Zoom in key

9Volume down/Zoom out key

10 Lock key

11 End/Power key

12 Camera lens. Before using the camera, remove the protective tape from the lens.

13 Memory card slot

14 Loudspeaker

Get started 5

Insert a SIM card and battery

Note: Switch the device off and disconnect the charger and any other device before

removing any covers. Avoid touching electronic components while changing any

covers. Always store and use the device with any covers attached.

Important: This device is designed to be used with a standard SIM card (see figure)

only. Use of incompatible SIM cards may damage the card or the device, and may

corrupt data stored on the card. Please consult your mobile operator for the use of

a SIM card that has a mini-UICC cutout.

Important: To prevent damage to the SIM card, always remove the battery before

you insert or remove the card.

This phone is intended for use with a BL-4U battery. Always use original Nokia

batteries.

The SIM and its contacts can be easily damaged by scratches or bending, so be careful

when handling, inserting, or removing the card.

1 Put your fingernail in the gap on the right edge of the phone, then carefully lift

and remove the back cover (1).

2 If the battery is in the phone, lift it out (2).

6Get started

3 Slide the SIM under the metal tab (3). Make sure the contact area of the card is

face down and the tab holds the SIM in place (4).

4 Line up the battery contacts, push the battery in (5), then replace the back cover

(6).

Get started 7

Insert or remove a memory card

Use only compatible microSD cards approved by Nokia for use with this device.

Incompatible cards may damage the card and the device and corrupt data stored on

the card.

Your phone supports memory cards with a capacity of up to 32 GB.

You can insert or remove the memory card without switching the phone off.

Insert a memory card

1Use your fingernail to open the cover of the memory card slot.

2 Push the memory card in with the contact area face up until it locks into place.

3 Close the cover of the memory card slot.

8Get started

Remove the memory card

Important: Do not remove the memory card when an app is using it. Doing so may

damage the memory card and the device and corrupt data stored on the card.

1 Open the memory card slot cover.

2 Push the card in until it's free, then pull it out.

3 Close the cover.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge

it before you can switch on your phone for the first time. If the phone indicates a low

charge, do the following:

1 Connect the charger to a wall outlet.

2 Connect the charger to the phone.

3 When the phone indicates a full charge, disconnect the charger from the phone,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use

the phone while it is charging.

If the battery is completely discharged, it may take several minutes before the

charging indicator is displayed or before any calls can be made.

Get started 9

Charge the battery over USB

Battery low, but you don't have a charger with you? You can use a compatible USB

cable to connect to a compatible device, such as a computer.

To avoid breaking the charger connector, be careful when connecting or

disconnecting the charger cable.

You can use USB charging when a wall outlet is not available. Data can be transferred

while charging the device. The efficiency of USB charging power varies significantly,

and it may take a long time for charging to start and the device to start functioning.

Switch the phone on or off

Press and hold the power key until the phone vibrates.

You may be prompted to get the configuration settings from your network service

provider. For more information on this network service, contact your network service

provider.

GSM antenna

The figure shows the GSM antenna area marked in grey.

10 Get started
