wiring method, then place it at the position where the
radiation is to be measured, turn on the power supply
and the switch of the collector, and the radiation
value at the measurement point can be obtained.
Notice
1. Please check whether the packaging is in good
condition, and check whether the product model is
consistent with the selection;
2. Do not connect with live power. After the wiring is
completed and checked, the power can be turned on;
3. The length of the sensor line will affect the output
signal of the product. Do not arbitrarily change the
components or wires that have been soldered when
the product leaves the factory. If you need to change
it, please contact the manufacturer;
4. The sensor is a precision device, please do not
disassemble it by yourself, or touch the surface of the
sensor with sharp objects or corrosive liquid, so as
not to damage the product;
5. Please keep the verification certificate and
qualification certificate, and return it together with
the product during maintenance.
Trouble clearing
1. During the analog output, the displayed value is
obviously too large/small. Please check whether there
is dirt or debris on the sensor port; if so, wipe it off
with a clean rag;
2. During analog output, the display device indicates
that the value is 0 or not within the range. The
collector may not be able to obtain the information
correctly due to the wiring problem, please check
whether the wiring is correct and firm;
3. If not for the above reasons, please contact the
manufacturer.
Product Maintenance
1. It is not allowed to dismantle or loosen the filter
cover, so as not to affect the measurement accuracy.
Be especially careful when opening or closing the
metal cap, as the filter cover is expensive and fragile.
The filter cover should be kept clean, often wipe with
a soft cloth or fur;
2. Water should not enter the filter cover, and there
should be no condensation in the cover. Always
check whether the desiccant in the dryer becomes
damp (from blue to red or white), otherwise it should
be replaced in time or the desiccant should be dried in
the oven to make it turn back to blue before use;
3. The TBQ total radiation sensor has good
waterproof performance. Generally, it can not be
covered for a short time or when the precipitation is
small. However, if there is heavy rain (snow, ice, etc.)
or rain for a long time, in order to protect the
pyranometer, the observer should put a cover on it
according to the specific situation, and open the cover
after the rain stops;
4. The TBQ total radiation sensor has been used for
more than two years, and its sensitivity must be
re-calibrated by the manufacturer or the measurement
department.
Service commitment
TBQ total radiation sensor from the date of delivery
within 1 year due to quality problems caused by
non-human factors, the production unit is responsible
for free maintenance or replacement. If the user is
artificially damaged, the cost will be charged, but the
maintenance fee will not be charged. In addition, our
company solemnly promises to be responsible for
life-long maintenance of factory products.
Selection table
