Nissin MG80 Pro Manual de usuario
Canon / Nikon / Sony
Fujifilm / Panasonic / Olympus
INSTRUCTION MANUAL
Thank you for purchasing a Nissin product
Before using this flash unit, please read this instruction manual and
refer to the manual of camera owner carefully to get a better
understanding of the proper operation to enjoy flash photography.
The flash Nissin MG80 Pro (Canon / Nikon / Sony/ Fujifilm / Panasonic /
Olympus) is an advanced commander built-in flash for wireless flash shooting.It
controls up to 8 groups of NAS (Nissin Air System) flash that have a wireless
multiple flash shooting function using NAS (radio transmission). Please note
that Nissin MG80 Pro is not usable with other branded cameras for TTL
operation.
Please refer to Nissin’s compatibility chart shown here:
http://www.nissindigital.com/compatibility-chart
Compatible cameras
1
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Nissin Air System (NAS) is a Nissin wirelessly remote control flash light system,
designed by Nissin. It consists of a Nissin radio commander (NAS commander)
and the Nissin wireless flash (NAS flash) and Nissin radio receiver (NAS receiver)
as remote slave units.
The signal of MG80 Pro is transmitted by using 2.4 GHz transmission.
2
Insert MG80 Pro on the camera hot shoe as a NAS commander.
Transmission distance is approx. 100m (330 ft.)
(Metal/ Wire/ Wall/ another 2.4 GHz radio frequency may cause a
reduction in the NAS transmission distance)
These safety instructions refer to important information on how to use this product safely
and properly. Please read the following instructions before using the product.
SAFETY INSTRUCTIONS
Do not touch the inside parts from the opening when the unit was dropped or broken.
Place the batteries correctly in position. Placing the batteries in wrong polarity may
cause leakage, exothermic heat or explosion.
CAUTIONS
Do not leave or store the commander unit in the temperature over 40ºC/ 104ºF, such as
in the automobile.
The commander unit is not water resistance. Keep the unit away from rain, snow and
humidity.
Do not use benzene, thinner or other alcoholic agents to clean the unit.
Do not use this commander unit with cameras which are not recommended in the
compatibility list at official website, otherwise it may damage the camera’s circuitry(*).
Remove the batteries when not in use for a longer period of time.
Do not use the Nissin MG80 Pro to pick up whole camera system when it installed on
your camera. To pick up the whole camera system, you should hold the handle of
camera body or the lens..
This sign refers to conditions which may cause damage or defect.
3
（*）Please refer Nissin’s compatibility chart shown here:
http://www.nissindigital.com/download.html
Names of the Components
4
Group selection button
Group on/off button
Modeling light button
(Basic/Advanced Groups button)
M/TTL Mode Button
(OPEN Mode button)
1
2
3
4
5
6
LCD panel
Select dial with buttons
Channel button
HSS button
Buzzer button
M.Zoom button
Panel Lock/Unlock button (hold 1sec.)
7
8
9
10
11
12
13
14
15
16
(1) The AF-assist lamp supports digital system cameras measuring autofocus in the center of the image field only.
It does not support other camera brands, other types of Canon, Nikon, Sony, Fujifilm, Panasonic and Olympus
cameras or camera models without our compatibility test.
(2) The shutter cable socket desinged for wireless remote shutter function on MG10 and MG8 only, the socket
cannot be use to trigger the flash. For more information, please refer to MG10 and MG8 instruction manual.
Pilot button (Test flash button)
Power On/Off button
Lock ring
Modelling Light
Micro SD card slot
(for firmware update)
Shutter cable socket (2.5mm) (2)
AF-assist light
(1)
Bounce lock
Battery compartment door
Hotshoe contacts
Inserting batteries
Energy saving
Battery status
1. Open the battery compartment door and insert 4 x 14500
Li-ion or size AA rechargeable batteries as shown in the
picture.
2. Make sure the + and - battery contacts are correctly
inserted in the battery compartment.
3. Close the battery compartment door and slide it back in
place.
Before starting wireless flash shooting.
5
2
1
2
1
Press any button Press Power button
Dim
30 sec
Sleep
2 mins
Turn Off
60 mins
A blinking signal shown on the Pilot Button mean:
- Wrong insertion of battery (battery type and/or position)
- Low battery
- Battery overheating
It is recommended to use 4 batteries in the same brand and type, and replace them all at
the same time.
Press power on to activate Nissin MG80 Pro,
hold the Power button for 7 seconds to reset to factory default setting
Default setting:
1. Mode: On-Camera
2. TTL mode: +/- 0EV
3. M Manual mode: 1/256
4. Zoom setting: Auto
5. HSS mode: off
6. Buzzer: on
Default Setting Reset
6
7
Basic Operation
NOTE
Do not use the MG80 Pro as a holder to pick up the whole camera system.
Mounting MG80 Pro on the camera
Removing MG80 Pro from the camera
Turn off MG80 Pro.
Turn off MG80 Pro.
1.
Turn the lock ring of MG80 to loosen it all the
way as shown in the picture.
2.
Slide the mounting foot of MG80 into the
hotshoe of the camera.
3.
Turn the lock ring to opposite direction and
tighten it.
4.
Turn the lock ring of MG80 to loosen it
all the way as shown in the picture.
1.
2.
Slide the mounting foot of MG80 out of the
hotshoe of the camera.
3.
Menu Screen For Main Modes
MG80 Pro Flash Mode and Functions
On-Camera Mode
Flash light automatically controlled by the
camera with the flash exposure or selecting the
desired manual power on the flash unit.
Commander Mode
Placing multiple flashes (slave flash) off camera
and controlling the lighting operation.
Slave Mode
Synchronizes to the wireless remote flash system.
The MG80 Pro can be use in 3 mode:
- On-Camera Mode
- Commander Mode
- Slave Mode
8
To change the mode in MG80 Pro,
switch on MG80 Pro, press the
3 seconds to select a mode.
On-Camera Mode
TTL flash power compensation
With the latest TTL flash control system, the flash power level is always
automatically controlled by the camera for the most appropriate exposure.
You can soften or weaken the light, or give more to the subject without
changing the environment or background exposure effect. MG80 Pro can
make it possible to adjust exposure quickly for each particular flash picture
as needed.
1. Set MG80 Pro to the camera’s hotshoe and press to switch on.
2. Press the 3 seconds to select “On-Camera” Mode.
3. Press the button to choose “TTL” mode.
4. Rotate the dial to select the power compensation.
5. TTL flash power compensation provided starts from -2EV to +2EV (12 steps) and
controlled by 1/3 EV step internal.
Take a picture and the subject is shown with required lighting effect by keeping the
background exposure level as originally expected.
9
NOTE
On some cameras, this setting is provided in its menu. When you set the TTL flash
power compensation on camera it is also set on the MG80 Pro will be counted in
addition to the compensation you selected in the camera’s menu mode. ( i.e. set +1
compensation on the flash and set +1.3 compensation on the camera it will
generate +2.3 EV in total.)
Red color bar represent 1 step, White color bar represent 1/3 step.
