ScanTouch 210 User's Manual i
Flatbed Scanner
ScanTouch 210
User’s Manual
Nikon
ScanTouch 210 User's Manualii
Cautions
• The reproduction of all or part of this manual without our permis-
sion is prohibited.
• The information contained in this manual is subject to change
without notice.
• We have made every effort to produce a perfect manual, but should
you find any mistakes, we would be grateful if you would kindly let
us know.
• We shall take no responsibility for consequences resulting from the
operation of this product, despite the terms mentioned above.
Indication
The indications in this manual signify important safety precau-
tions. In order to use this product safely, please read every section
where these indications are placed before beginning operation of this
product. These indications are also placed in the table of contents so
users can find them easily.
Indication
The indications in this manual signify the need for caution when
using the products. These indications are placed in sections that should
be read by users before beginning operation, in order to avoid damage to
the product.
Trademark Information
Macintosh is a registered trademark of Apple Computer, Inc.
Microsoft is a registered trademark and Windows is a trademark of Microsoft
Corporation.
IBM PC/AT is a trademark of International Business Machines Corporation.
Other brand or product names are the trademarks or registered trademarks of
their respective holders.
Nikon
ScanTouch 210 User's Manual iii
Important Safeguard
• Read all of these instructions.
• Save these instructions for later use.
• Follow all warnings and instructions marked on the product.
• When replacement parts are required, be sure the service technician has
used replacement parts specified by the manufacturer and that have the
same characteristics as the original parts. Unauthorized substitutions may
result in fire, electric shock, or other hazards.
• Do not use this product near water or in rainy or moist conditions.
• To avoid serious damage, be sure to place the product on a stable surface.
• The product should be operated only from the type of power source
indicated on the marketing label.
• Do not attempt to service this product yourself as opening or removing the
enclosure may expose you to dangerous voltage or other hazards.
• This unit has an autoranging input circuitry suitable for 120VAC and
240VAC.
• According to IEC 704-1:1982, the sound pressure level at the operator's
position is equal or less than 70dB(A).
Wichtige Sicherheitshinweise
• Bitte lesen Sie sich diese Hinweise sorgfaltig durch.
• Heben Sie diese Anleitung für den späteren Gerauch auf.
• Alle Heiweise und Warnungen die sich am Geräten befinden sind zu
beachten.
• Wenden sie sich mit allen Fragen die Service und Reparatur betreffen an
Ihren Servicepartner. Somit stellen Sie die Betriebssicherheir des Gerätes
sicher.
• Benutzen Sie dieses Produkt nicht in der Nähe von wasser oder in
regerischer/feuchter Umgebung.
• Stellen Sie es nicht auf eine unstabile Unterlage um Schaden an dem
Produkt zu vermedien.
• Das Produkt sollte nur mit der auf dem Etickert angegebenen Stromquelle
betrieben werden.
• Versuchen Sie nicht, Reparaturen selber durchzuführen, da das Öffnen oder
die Entfernung des Gehäuses Sie hoher Spannung oder anderen Gefahren
aussetzt.
• Der Arbeitsplatzbezogene Schalldurckpegel nach DIN 45 635 beträgt 70db
(A) oder weniger.
• Die Nerzanschlußsteckdose Soll nahe dem Gerät angebracht und leicht
zugänglich sein.
Nikon
ScanTouch 210 User's Manualiv
Federal Communications Commission (FCC) Radio
Frequency Interference Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Modifications
The FCC requires the user to be notified that any changes or modifica-
tions made to this device that are not expressly approved by Nikon
Corporation may void the user’s authority to operate the equipment.
SCSI Cable
Please use the SCSI cable described on page 12 of this manual. Using
other interface cables may exceed the limits of the class B Part 15 of
FCC rules.
Nikon
ScanTouch 210 User's Manual v
Notice for customers in Canada
This class B digital apparatus meets all requirements of the Canadian
Interference Causing Equipment Regulations.
ATTENTION
Cet appareil numérique de la class B respecte toutes les exigences du
Règlement sur le matériel brouilleur du Canada.
WhenTaking the Unit Out ofThe Country
The use of this product may violate local laws and restrictions in some
countries. If this is the case, we cannot bear any responsibility for any
violations resulting from the use of this product.
Nikon
ScanTouch 210 User's Manualvi
Notice concerning prohibition of copying or reproduction
Note that simply being in possession of material which has been copied
or reproduced by means of a scanner may be punishable by law.
• Items prohibited by law from being copied or reproduced
Do not copy or reproduce paper money, coins, securities, govern-
ment bonds, or local government bonds, even if such copies or
reproductions are stamped “Sample”.
The copying or reproduction of paper money, coins, or securities
which are circulated in a foreign country is prohibited.
The copying or reproduction of unused postage stamps or post cards
issued by the government without obtaining approval from the
government is prohibited.
The copying or reproduction of stamps issued by the government
and certified documents stipulated by law is prohibited.
• Cautions on certain copies and reproductions
The government has issued cautions on copies or reproductions of
securities issued by private companies (shares, bills, checks, gift
certificates, etc.), commuter passes, or coupon tickets, except when
a minimum of necessary copies are to be provided for business use
by a company. Also, do not copy or reproduce passports issued by
the government, licenses issued by public agencies and private
groups, ID cards, and tickets, such as passes and meal coupons.
• Comply with copyright notices
The copying or reproduction of works such as books, music,
paintings, woodcut prints, maps, drawings, movies, and photographs
which are copyrighted creative works is prohibited except when it is
done for personal use at home or for similar restricted and non-
commercial use.
Nikon
ScanTouch 210 User's Manual vii
Contents
1. Overview ................................................................. 1
2. Before Operating the Scanner...............................2
2.1 Power Supply Precautions ........................................ 2
2.2 Handling Precautions ................................................ 4
2.3 If You Notice Anything Abnormal ..............................7
2.4 Storage and Operating Locations..............................7
2.5 Transportation Precaution ....................................... 10
3. Parts Identification ............................................... 11
3.1 Inspection...................................................................... 11
3.2 Components.................................................................. 11
3.3 Main Body..................................................................... 13
A Closer Look ............................................................... 13
Rear View ..................................................................... 14
Unlocking the Scanner.................................................. 15
4. Connecting the Scanner ......................................16
4.1 Before Connection ........................................................ 16
4.2 Connecting the Power Cord.......................................... 17
4.3 Connecting the SCSI Cable .......................................... 19
Connecting to the Macintosh computer.........................20
Connecting to the IBM PC/AT or compatible computer.20
SCSI Chain Connection with Other Devices .................21
4.4 Setting the SCSI ID....................................................... 23
Contents
Nikon
ScanTouch 210 User's Manualviii
5. Operation .............................................................. 24
5.1 Turning on the Power.................................................... 24
5.2 Setting a Document ...................................................... 26
6. Maintenance.......................................................... 29
6.1 Static Electricity Precautions ...................................29
6.2 Cleaning........................................................................ 30
7. Troubleshooting ................................................... 31
Appendix: Specifications....................................34
Index...................................................................... 36
Contents
