Nextorch Magic MAX II Manual de usuario
Magic MAX
Ⅱ
R
OPERATOR’S MANUAL
FLASHLIGHT
5,6
,3,4
Battery safety guide... . . ...........1 1
3
For using one NT123A battery
+
-
Step 1: Remove the lamp assembly by screwing
it anti-clockwise.
Step 2: Insert the battery correctly by placing
the negative side in first.
Step 3: Screw the lamp assembly on.
For using 2 X AA alkaline batteries
3
Screw off the lamp assembly and
take the NT123A battery off.
Screw off the plastic covers from
the extra barrel.
Screw off the extra barrel on to the
original barrel.
4
convenience
Place two AA batteries into the barrel,
then screw the tailcap on.
Barrel the NT123A and take care of it.
56
LITHIUM BATTERY
NT123A
RUBBER
TAILCAP
CAUDAL PAN
1W LUXEON LED
O-RING O-RING
BARREL
BRAINPAN
REFLECTOR
POLYCARBONATE LENS
7
Magic MAX ⅡFlashlight Features
Magic MAX Ⅱ
Aerospace grade aluminum with
mil-spec type Ⅲhard anodized finish
Anti-scratch polycarbonate
2 AA: 240 minutes
1 NT123A: 150 minutes
Length 92mm
Barrel diameter 22mm
Head diameter 27mm
1 NT123A 3V Lithium Battery or
2 AA 1.5V Alkaline Batteries
Product Model
Bulb
Battery
Material
Lens’ Material
Runtime
Dimensions
weight
Special Features
Augment
dimensions
55g（Original）
80g（With extra barrel）
LUXEON 1W LED
Max 35 lumens
Length 155mm
(with extra barrel)
Barrel diameter 22mm
Head diameter 27mm
Compact size,multi-power supply,
Click tailcap,patented anti-rolling
struture,watertight structure,
hard anodized type Ⅲfinish.
BATTERY
Original
Original:
Unscrew the lamp assembly, put the NT123A battery into the barrel with
proper polarity, and install the lamp assembly back on to the barrel.
With extra barrel:
Unscrew the tailcap, put the AA batteries into the barrel with proper polarity,
and install the tailcap back on to the barrel.
Press the rubber tailcap until you hear audible click to turn your flashlight
on. You can turn it off in the same way.
With extra barrel
long
Thank you for choosing NexTORCH
flashlight. It produces
not only brilliant, extraordinary white light, but also a lot of heat.
In case of damaging your flashlight and the things around the
flashlight, please pay attention to the following:
1.
Do not put the head of flashlight straight on the flat,
which would damage the bulb
.
2. Do not shine the eyes straight as the powerful light could
cause a permanent injury.
3. Do not dismantle the bulb assembly.
NOTICE
NexTORCH guarantees that all products under NexTORCH brand
are free from manufacture defects. NexTORCH will repair or
replace any defective products,Please contact your local dealer
or e-mail to
This warranty excludes the following:
1). Failure of product due to misuse and/or lack of maintenance.
2). Internal water damage.
NexTORCH LIFETIME WARRANTY
4
DISMANTLE
