FW Update Instructions

122HD

The following upgrade guide is in relation to updating the firmware by copying an update file to the SD card via the supplied USB cable.

Download the latest version of firmware for

the NBDVR122HD via the Support &

Downloads page for your Dash Cam. Download Here

The firmware update will be saved to your

PC as a file called ‘FW122HDA. This will usually

be located within the downloads folder on

your computer.

You won’t be able to open thisNote:

file on your computer.

Download Here

FWXXXX.bin

Windows Mac

Open

Open With

Move to Trash

Get Info

Rename

Compress “FWXXXX.bin”

Burn “FWXXXX.bin” to Disc...

Duplicate

Make Alias

Quick Look “FWXXXX.bin”

Clean Up Selection

Show View Options

Copy “FWXXXX.bin”

Right click (CMD & click if using a mac)

on the bin file inside the downloads folder

and select the option that says ‘Copy’.

Open with

Scan with Windows Defender...

Give access to

Add to archive...

Add to “FW122A.rar”

Compress and email...

Compress to “FW122A.rar” and email

Restore previous versions

Send to

Cut

Create Shortcut

Delete

Rename

Properties

Copy

Go to the Dash Cam Setup Menu (Press

the Menu button twice when the camera

is not recording) and select the option

that says Format SD Card’, press the ‘OK’

button to confirm.

Format SD Card

Time & Date

Language

Screen Saver

Setup Menu

Back Enter

Format SD Card

Time & Date

Language

Screen Saver

Setup Menu

Back Enter

Turn off the Dash Cam and remove the SD

card. Insert the SD Card into your computer

using an SD Card Reader.

Once the contents of the card are displayed,

right click in the white space and select

the option that says ‘Paste’.

This will copy the file from your downloaded

zip file and place it onto the SD card

where it can be read by the Dash Cam

View

Sort by

Group by

Refresh

Customize this folder...

Paste

Paste Shortcut

Undo Move Crtl+Z

Give access to

New

Properties

New Folder

Get Info

View

Clean Up

Clean Up By

Arrange By

Show View options

Paste Item

Click on your SD card as it appears within

File Explorer/Finder to view the contents

of the card.

The Dash Cam should the appear as a

storage device called ‘NEXTBASE’ within File

Explorer (Windows) or Finder (Mac).

Please ensure that the bin file is NOT

renamed in anyway, the update will fail if

the file appears as FW122HDA(1).bin,

for example.

FWXXXX.bin

Once you have copied ‘FW122HDA.bin’ to

the SD Card you can now remove it from

your computer.

With the Dash Cam turned off insert the

SD Card into the Dash Cam until it clicks

into place.

122HD

After the update has installed your Dash

Cam will restart and display the PC

Connection Screen.

Select the ‘Power On’ option using the ‘OK’

button to continue.

Access Files

Power On

PC Connection

Enter

Access Files

Power On

PC Connection

Enter

After the Dash Cam has restarted open

the Setup Menu (by pressing the ‘Menu’

button twice) and scroll down to ‘System Info’.

Press the ‘OK’ button to select this option

and the Firmware version will be displayed.

System Info - Page 1

Back Enter

122HD

Check Updates: www.nextbase.com

System Info - Page 1

Back Enter

122HD

Check Updates: www.nextbase.com

After the Dash Cam has shut down

completely, plug it back into your PC and

select ‘Power On’.

The update should begin automatically.

Firmware Updating...

Update takes approx 1 minute

Do not disconnect power!

Firmware Updating...

Update takes approx 1 minute

Do not disconnect power!
