Nexcom EBC340 Manual de usuario

Single Board Computer

EBC340

User’s Manual

Apr.-01-2009 Build

User’s Manual is subject to change without prior notice.

For any update, please visit our website: www.nexcom.com

EBC340 User’s Manual 2 Table of Content

Preface

This publication, including all photographs, illustrations and software, is protected under international copyright laws,

any means without the prior written consent from NEXCOM International Co., Ltd.

Disclaimer

The information in this document is subject to change without prior notice and does not represent commitment from

NEXCOM International Co., LTD. However, users may update their knowledge of any product in use by constantly

checking its manual posted on our website: http://www.nexcom.com. NEXCOM shall not be liable for direct, indirect,

special, incidental, or consequential damages arising out of the use of any product, nor for any infringements upon

the rights of third parties, which may result from such use. Any implied warranties of merchantability of fitness for any

particular purpose is also disclaimed.

Acknowledgements

The EBC 340 series is a trademark of NEXCOM international CO., LTD. All other product names mentioned herein

are registered trademarks of their respective owners.

Regulatory Compliance Statements

This section provides the FCC compliance statement for Class A devices and describes how to keep the system CE

compliant.

Federal Communications Commission (FCC) For Class A Device

This equipment has been tested and verified to comply with the limits for a Class A digital device, pursuant to Part 15

of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. Operation of this equipment in a residential area (domestic environment) is likely to cause

EBC340 User’s Manual 3 Table of Content

harmful interference, in which case the user will be required to correct the interference (take adequate measures) at

their own expense.

CE Certification

The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE

marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE

compliance also requires proper cable and cabling techniques.

Safety Information

Before installing and using the EBC340, note the following precautions:

Read all instructions carefully. Do not place the unit on an unstable surface, cart, or stand.

Follow all warnings and cautions in this manual.

As parts replaced for sure that your service technician uses parts specified by the manufacturer.

Avoid using the system near water, in direct sunlight, or near a hearing device.

WARNINGS

Read and adhere to all warnings, cautions, and notices in this guide and the

documentation supplied with the chassis, power supply, and accessory modules. If

the instructions for the chassis and power supply are inconsistent with these

instructions or the instructions for accessory modules, contact the supplier to find

out how you can ensure that your computer meets safety and regulatory

requirements.

CAUTION

Electrostatic discharge (ESD) can damage NSA components. Do the described

procedures only at an ESD workstation. If no such station is available, you can

provide some ESD protection by wearing an antistatic wrist strap and attaching it to

a metal part of the computer chassis.

EBC340 User’s Manual 4 Table of Content

Table of Content

Preface……………...……………..……………………………………….………….……..……………..2

Disclaimer………………………..………………………………..………………………………………..2

Acknowledgements……………………………………………..………………………..………..…..……2

Regulatory Compliance Statements……………………..…………………………………….……………2

Federal Communications Commission (FCC) For Class A Device……………..……….…………..…..…2

CE Certification………………………………………………………………………….……….………...3

Safety Information……………………………………………………………………….………..………..3

Table of Content……………………………………………………………………………………....…….4

Chapter 1 General Information

1.1 Specification…………………………………………………….…………………………………….. 7

1.2 Power Consumption Measurement……………………………………………………………………..9

1.3 Board Layout…………………………………………………………………….… ………………… 10

1.4 Board Dimensions……………………………………………………….……… …….………...…… 10

Chapter 2 Jumper Setting

2.1 Before You Begin……………………………………………..….……………………………………12

2.2 Precautions………………………………………………………………………………………...…..12

2.3 Setting Jumpers………………………………………………………………………………………..13

2.4 Location of Jumpers……………………………………………………………………………….…..14

2.5 Function of Jumpers and Connectors…………….………………………………………………........15

Chapter 3 Expansion

3.1 System Memory…………………………………………………………………………………..…….30

3.2 Installing Compact Flash……………….……...………………………………………..…………….. 31

Chapter 4 BIOS Setting

4.1 Entering Setup………………………………………………………………………………………….33

4.2 Getting Help……………………………………………………………………………………………33

4.3 The Main Menu………………………………………………………………………………………...35

EBC340 User’s Manual 5 Chapter 1

Chapter 1

General Information

EBC340 User’s Manual 6 Chapter 1

Block Diagram







EBC340 User’s Manual 7 Chapter 1

1.1 Specification

CPU Support

Intel® Atom™ Processor N270 1.6GHZ

Main Memory

1 x DDR2 SO-DIMM Socket (up to 2GB SO-DIMM memory)

Chipset

Intel 82945GSE Graphic Controller Hub (GMCH)

Intel® 82801GBM ICH7 Mobile (ICH7-M)

Display

Intel® 945GSE integrated 3D graphic engine GMA950

Support Dual Independent Display: CRT+LVDS

CRT: 1 x DB15 VGA CON

LVDS: 1x DF13 20-pin connector

Analog VGA interface:

Resolution up to 1600x1200 at 85 Hz, 2048x1536 at 75Hz

LVDS interface:

Support 18-bit single channel LVDS, resolution up to 1600x1200

CCFL interface:

1 x CCFL for LCD Panel Backlight Inverter

Storage

SATA: 1x Serial ATA ports

U-DOC : By option

CF: 1x Compact Flash Socket

Expansion

1x PCI-104 Slot

Audio

Realtek ALC888 CODEC for High Definition

1x Mic-In / 1x Line out Phone Jack

On board LAN

LAN Chip: Realtek RTL8111C-GR PCI Express Gigabit Ethernet

Support Boot From LAN (PXE)

1x RJ45 connector w/ LED

I/O Interface

Parallel port :1 x Parallel Port 26-pin Box header

Serial port: 4 ports, 1x DB9 port, three 2x5-pin Box headers

SIO2 support RS232/422/485 w/10pin Box header

USB 2.0 : 6 ports, 2x edge ports and 2 ports by Jst connector

EBC340 User’s Manual 8 Chapter 1

8 GPIO lines via header (GPI 0~3 and GPO 0~3)

1 x Power LED and 1 x HDD Active LED Pin header

1 x DB15 VGA port

1x Keyboard/Mouse pin header

Onboard Buzzer / SMBus 2.0 /Reset SW

Power Input

Support AT mode only

6-pin power connector for +5V / +12V power in

3-pin Jst connector with PS_ON# directly connected to GND for ATX power supply

(Without power on push button function)

System Management

Monitoring of 4 voltages (Vcore,+12V, +3.3V, +1.5V)

2 Temperatures (CPU, System)

On board RTC

On chip RTC with battery back up / External Li-ion Battery

RTC Torrance less than 2sec (24 hours) under 25˚C

BIOS

Award system BIOS

8M bits SPI ROM

Environment

Operating temperatures: 0°C to 60°C

Storage temperatures:-20˚C to 85˚C

Relative Humidity: Operating 10%~90%, non-condensing

Certifications

CE

FCC Class A

EBC340 User’s Manual 9 Chapter 1

1.2 Power Consumption Measurement

Power Type

+12V

+5v +12v-to-Vcore

DC/DC

+12v-to-1.8v

DC/DC

+12v-to-0.9v

DC/DC

5v-to-1.5v

DC/DC

5v-to-1.05v

DC/DC

+12v-to-3.3v

DC/DC

Consumed watts

18W

34.75W

4.4W 5.544W 0.9W 5.79W 7.581W 19W

Consumed currents (Item A )

1.5A

6.95A

0.367A 0.462A 0.075A 1.158A

1.5162A

1.584A

Actually required currents

(Item A/0.80 )

0.46A 0.578A 0.01A 1.448A

1.896A 1.98A

12v needed

4.528A

5v needed

10.294A

EBC340 User’s Manual 10 Chapter 1



1.3 Board Layout

Figure 1.2: Overview of EBC 340

1.4 Board

Dimensions

Figure 1.3: Mechanical Drawing of the EBC 340
