Newport CONEX-CC Manual de usuario
CONEX-CC
Single-Axis DC Motion
with Controller/Driver
Controller GUI
Manual
V2
.0.x
CONEX-CC Controller GUI Manual
©2017 by Newport Corporation, Irvine, CA. All rights reserved.
Original instructions.
No part of this document may be reproduced or copied without the prior written
approval of Newport Corporation. This document is provided for information only, and
product specifications are subject to change without notice. Any change will be
reflected in future publishings.
EDH0277En1041 — 10/17 ii
CONEX-CC Controller GUI Manual
Table of Contents
1.0 Introduction .................................................................................................. 1
1.1 Purpose .............................................................................................................................1
1.2 Overview ..........................................................................................................................1
1.3 Controller State Diagram..................................................................................................2
2.0 Installation..................................................................................................... 3
2.1 Install CONEX-CC Graphical User Interface...................................................................3
2.2 Launch GUI ......................................................................................................................3
3.0 Getting Started.............................................................................................. 4
3.1 Discover Instruments........................................................................................................4
4.0 User Interface................................................................................................ 5
4.1 Configuration....................................................................................................................5
4.2 Main..................................................................................................................................8
4.3 Tracking..........................................................................................................................10
4.4 Diagnostics .....................................................................................................................12
4.5 About ..............................................................................................................................13
Service Form ........................................................................................................ 15
iii EDH0277En1041 — 10/17
CONEX-CC Controller GUI Manual
EDH0277En1041 — 10/17 iv
CONEX-CC Controller GUI Manual
1.0 Introduction
1.1 Purpose
The purpose of this document is to provide instructions on how to use the
CONEX-CC Controller graphical user interface (GUI).
1.2 Overview
The CONEX-CC Controller GUI is a graphical user interface, that allows the user to
interact with the CONEX-CC controller that is connected to stages with DC motors
and encoder feedback. The user can initiate moves, change the state of the controller,
adjust parameters, etc.
Single
-Axis DC Motor
Controller/Driver
CONEX
-CC
1 EDH0277En1041 — 10/17
CONEX-CC Controller GUI Manual
1.3 Controller State Diagram
The CONEX-CC controller is defined by the following state diagram.
NOTE
The position tracking is available only from the controller version 2.0.0
Controller’s LED display:
NOT REFERENCED: If everything is OK then SOLID ORANGE.
NOT REFERENCED: If hardware faults or wrong parameters then SOLID RED.
NOT REFERENCED: If end of runs then SLOW BLINK ORANGE.
CONFIGURATION: SLOW BLINK RED.
READY / READY T: SOLID GREEN.
DISABLE / DISABLE T: SLOW BLINK GREEN.
HOMING: FAST BLINK GREEN.
MOVING: FAST BLINK GREEN.
TRACKING: FAST BLINK GREEN.
EDH0277En1041 — 10/17 2
CONEX-CC Controller GUI Manual
2.0 Installation
2.1 Install CONEX-CC Graphical User Interface
Following are steps to install CONEX-CC GUI.
•For 32 bit, Select and launch “CONEX-CC Utility Installer Win32.exe”. For 64
bit, Select and launch “CONEX-CC Utility Installer Win64.exe”.
•A window opens up showing Install welcome page.
•Click on “Next”.
•A window opens up allowing destination folder selection. By default it is showing
C:\.
•Click on “Next”.
•Ready to install window opens up. Click “Install”.
•Then installation starts, wait for completion. Click on “Finish” to finalize the
installation.
32 bit installer will be installed “Newport.CONEXCC.CommandInterface.dll” in
GAC_32 folder and 64 bit installer will be installed the dll in GAC_64 folder.
NOTE
LabVIEW user can add reference of command interface dll from GAC during VI
creation.
2.2 Launch GUI
From Windows “START” menu, select “All Programs\Newport\Motion
Control\CONEX-CC\CONEXCC Utility”.
3 EDH0277En1041 — 10/17
CONEX-CC Controller GUI Manual
3.0 Getting Started
3.1 Discover Instruments
Start the Controller GUI from Newport\MotionControl\CONEX-CC.
Next, click on “Discover” button and the number of instruments discovered will
appear. This window allows the user to select a com port where the desired instrument
is connected.
NOTE
When more than one CONEX-CC instrument is connected, this window allows
the user to switch the instruments between X and Y axes. To discern a com port
for a specific instrument, note their COM number in the Device Manager when
the connection is added.
Next, click “Launch Applet” button.
EDH0277En1041 — 10/17 4
CONEX-CC Controller GUI Manual
4.0 User Interface
4.1 Configuration
The Configuration tab allows the user to view and / or change information related to
the logging configuration and the instrument settings. Read only values are displayed
for the log file name and the log file path. The logging level may be changed to any of
the settings in the drop-down list on the right hand side. Trace is the most detailed of
the settings and when this setting is selected the Controller GUI logs everything.
Critical Error is the least detailed of the settings and when this setting is selected the
Controller GUI will only log errors that are defined to be critical.
The polling interval defines the number of milliseconds between each time the
Controller GUI polls the CONEX-CC for the latest information. The user may change
the polling interval by entering a value. Diagnostics Delay defines the time delay in
milliseconds between each command sent from a text file.
InstrumentType and NoOfInstruments display the name and number of connected
instruments.
The Save button allows to save the current settings to the configuration file.
5 EDH0277En1041 — 10/17
CONEX-CC Controller GUI Manual
Configurable settings
The following table describes all the settings that can be changed by the user.
Parameter
Description
Values
Default
LoggingConfiguration
Level
Logging level.
Trace is the most detailed of the settings and when this
setting is selected the Controller GUI logs everything.
Critical Error is the least detailed of the settings and when
this setting is selected the Controller GUI will only log
errors that are defined to be critical.
Trace
Detail
Equipment Message
Info
Warning
Error
Critical Error
Trace
InstrumentInformation
PollingInterval
The polling interval defines the number of milliseconds
(delay) between each time the Controller GUI polls the
instrument for the latest information.
An Integer
200
NbDigits
Number of fractional digits after the decimal point.
An Integer
6
Diagnostic
Delay
The delay defines the number of milliseconds between each
sent command from a text file.
An Integer
5
MemorizePositionsRollingBuffer
Buffer Depth
BufferDepth defines the maximum number of
analog I/O values displayed in the chart.
Positions
Positions is a list of memorized positions. The format is
“Name of positions #1; X position #1; Y position #2…”
Models\InstrumentInfo
XAxis
XAxis defines the instrument for X axis.
None = no instrument for X axis
Instrument 1
Instrument 2
None
Instrument 1
YAxis
YAxis defines the instrument for Y axis.
None = no instrument for Y axis
Instrument 1
Instrument 2
None
Instrument 2
CommunicationChannel
The communication channel
USB
USB
InstrumentType
Specifies type of instrument connected to computer
Name of instrument
NoOfInstruments
Specifies number of instruments connected to computer
An Integer
0 if nothing is
connected
TrackingConfiguration
XDirection
The axis direction for X axis.
Normal
Inverse
Normal
YDirection
The axis direction for Y axis.
Normal
Inverse
Normal
StartedSensibility
The started sensibility defines the zoom level of the
tracking panel after Controller GUI launching.
An Integer (1<20)
4
MinimumAmplitudeX
The minimum amplitude for X axis.
A Double
0.001
MaximumAmplitudeX
The maximum amplitude for X axis.
A Double
20
MinimumAmplitudeY
The minimum amplitude for Y axis.
A Double
0.001
MaximumAmplitudeY
The maximum amplitude for Y axis.
A Double
20
IncrementalStep
The maximum incremental step when the tracking is in
incremental displacement mode.
A Double
0.05
EDH0277En1041 — 10/17 6
