Newland SPEEDATA SD35 Manual de usuario
SD35 User Guide
SD35 User guide V1.0
2
Appearance
SD35 User guide V1.0
3
Keypad
Volume key
Scan key
Scanning
key
Power key
Home key
Back key
Enter key
Resent key
Function
keys
Screen off
key
Scan key
OK key
SD35 User guide V1.0
4
Virtual Keyboard
When the device is turned for the first time ,please Click “Setting”
-> ”system ”->”Languages&Input”->”Physical Keyboard”,and enable “Show
Virtual keyboard”.Then you can use “Virtual Keyboard”and”Physical Keyboard”
at the same time.
Quick setup
You can click the iron in the lower right corner to enter the “Change keyboard”
interface to enable “Show virtual keyboard”.
Click “Setting”->”system”->”Languages&Input”-”Virtual Keyboard”,then click
“manage keyboard”,you can manage the virtual keyboard.
SD35 User guide V1.0
5
Physical Keyboard
When the device is turned on for the first time,the default input of the physical
keyboard is numbers.You can switch between numbers and uppercase and
lowercase by pressing the “aA”key.
Note:Please refer to the “physical key definition” for how to use the function
keys.
SD35 User guide V1.0
6
SIM Card
1 Both SIM cards use standard Nano-SIM cards. Please use professional
equipment to open the SIM card warehouse, so as not to damage the
equipment and affect the protection performance.
2 When the SIM1 card is placed, the SIM1 card is placed horizontally in the
upper right corner of the second layer of the slot, which is flat with the slot, and
the SIM1 card is successfully placed.
3 When the SIM2 card is placed, the SIM2 card is placed horizontally in the
upper left corner of the first layer of the slot, which is flat with the slot, and the
SIM2 card is successfully placed.
4 Memory card slot, maximum expandable 128G memory card.
SD35 User guide V1.0
7
Charging&Attention
1 Please use the supplied charger and USB (Type-C) cable. Otherwise, the
fast charging mode cannot be enabled. Using a non-original charger and a
USB charging cable may result in long charging time and repeated restarts,
and affect the battery life.
2 It is recommended not to operate the devices while charging, and not to
cover objects on the device and charger.
3 When the device is in low power, there will be an indicator light and a desktop
pop-up reminder. Please charge as soon as possible to avoid affecting normal
use.
4 Please ensure that the power is about 50% when store the equipment for a
long time. Please place the equipment in a suitable environment with dry
temperature to avoid equipment failure caused by long-term storage.
5 In case of damage to the battery, charging head and charging cable, please
contact us in time to purchase, do not repair it yourself, so as to avoid danger
and cause extra loss.
Charging indicator status
Device charging indicator
Red light blinking:low-battery.
Red light on:charging in process.
Green light on:fully charged.
Cradle indicator status
Red light on:extra-battery charging in process.
Green light on:extra-battery fully charged.
Power on&Power off&Restart
SD35 User guide V1.0
8
1 When the device is powered off, press and hold the power button for 2
seconds.And the device will boot into the Android operating system. It takes a
long time to initialize the device. Please wait patiently.
2 When the device is powered on, press and hold the power button for 2
seconds. The system will pop-up menu and display two options:”Power off”,
and “Restart”. Choose ”Power off”or “Restart”.
3 When the device is abnormal or unable to operate, press and hold the red
power button for more than 15 seconds to force restart the device.
Locking and Unlocking the device
Lock the device:Brief press the power button on the right side of device,if no
operation is performed on the device for a preset period of time,the device will
lock automatically.You can change how long it takes the device lock.
Unlock the device:Brief press the power button on the right side of device and
slide the screen upward.If no screen method is set,you can directly enter the
system interface.If the screen method is set,you need to enter an unlock
password or pattern to enter.
Unlocking method settings:settings->Security&location->Screen
lock,Choose the unlock method you need.
SD35 User guide V1.0
9
Note:If you select”pattern Unlock”,please pay attention to the prompts during
setting, whether you want to use the pattern to unlock when you turn on the
device, select "Yes", you need to use the pattern you set to unlock after
restarting the device.
*If you accidentally forget the unlock pattern or password,please contact
us.*
Home Screen
Swipe up anywhere on the main screen to enter the application drawer to view
all applications.
SD35 User guide V1.0
10
Open an app:Tap to open an app.
Add an app iron to the home screen:Swipe up on the main screen interface
to see all applications.Tap and hold your desired app and then drag it on the
home screen.
Installing App:Use one of the following methods to install a new app on the
device.
1 Download an APK file from APP town,and install it.(Only the programs
uploaded by us, the overseas version may not have this in the future, so it is
not recommended.)
2 Install third-party app stores yourself.
3 Connect device to PC with the supplied cable.The computer transfers the
application installation package to the device, then the device opens the file
manager to find the installation package and install it. (Note that the file suffix
is .apk, it can be installed directly.)
Uninstalling APP:Long press your desired APP iron,click “App info” to enter
the app info,then click uninstall.
