Update-Backup-Analysis FST-2XT FST-2XTs 3
Contents
1 General 5
1.1 Abbreviations, characters and symbols used 5
1.2 Notation 5
1.3 Further information 6
1.4 How to contact us 6
2 Hardware requirements 7
2.1 Serial interface cable (null modem cable) for FST 7
3.1 SavingrmwareupdateontheUSBstick 8
3.2 CopyingtheFSTrmwareupdatetotheFST-2XT 9
3.3 CopyingtheGSTrmwareupdatetotheGST-XT 10
4 Conguration 11
4.1 Saving/loadingthecongurationinternallyontheFST 11
4.2 SavingthecongurationontheUSBstick,loadingfromtheUSBstick 11
5 Recording 12
5.1 FST Recording 12
5.1.1 SavingFSTrecordingsontheUSBstick 12
5.2 GST-XTRecording 12
5.2.1 EnableGST-XTRecording 13
5.2.2 CheckingGST-XTRecordingStatus 13
5.2.3 SavingGST-XTrecordingsontheUSBstick 14
5.2.4 Relevant menu items 14
5.2.5 Others 14
5.3 Evaluating recordings via EleVision Light 15
5.3.1 Downloading EleVision Light software 15
5.3.2 Visualising recordings with EleVision Light 16
6 LONmodules 19
6.1 UpdatingwithUSBstick 19
6.2 DownloadingLonModuleCentersoftware 19
6.3 UpdatingwithLonModuleCentersoftware 20
7 FST-2XTandFST-2XTsRecovery 22
7.1 FST-2XT-RecoverySoftware 22
7.2 RunFST-Recovery 24
7.3 FAQs 26
7.4 Program sequence. Overview 26
7.5 Program structure 27
4Update-Backup-Analysis FST-2XT FST-2XTs
8 Errorlist 28
8.1 SaveerrorlistontheUSBstick 28
8.2 Visualisingtheerrorlist 28
9.1 Controlsystemfailure 28
9.2 TheFSTapplicationdoesnotstart 29
9.3 Errormessages 30
General
Update-Backup-Analysis FST-2XT FST-2XTs 5
1 General
This manual is a supplement to the FST-2XT manual and the FST-2XT Installation and Commissioning
Manual. It is limited exclusively to the description of the aspects relevant to the function.
The safety guidelines of the FST-2XT manual and the FST Installation and Commissioning manual always
apply.
1.1 Abbreviations, characters and symbols used
Symbol /
abbreviation Meaning
► Operational instructions
Perform the tasks that follow this symbol in the specied order.
Warning notice
This symbol is located in front of safety-relevant information
Information notice
This symbol is located in front of relevant information.
1.2 Notation
Notation Meaning
Bold ›Designations of menus, options, buttons, check boxes, input and display
elds, display areas, navigation areas, software functions
›Keyboard commands
Italics ›Designations of folders, screen windows, screen areas, work areas, tabs,
software dialogs
›Operating level, parameters, paths, operating modes, and input and dis-
play values
›System messages
›Cross references
<italics in pointed
brackets>
›Place holders for le names.
LCD font ›System messages of the controller
General
6Update-Backup-Analysis FST-2XT FST-2XTs
1.3 Further information
The following documents, among others, are available for the FST control system and its components:
›ADM Manual
›EAZ 256 Manual
›EAZ TFT.45.110.210 Manual
›EN81-20 Manual
›FPM Manual
›FST-2XT/s Manual
›FST-2XT MRL Manual
›FST Installation & Commissioning Manual
›GST-XT Manual
›LCS Manual
›RIO Manual
›SAM Manual
›UCM-A3 Manual
These and other up to date manuals can be found in the download area of our website at
https://www.newlift.de/downloads-311.html
1.4 How to contact us
If, after referring to this manual, you still require assistance, our service line is there for you:
Phone +49 89 – 898 66 – 110
E-mail [email protected]
Mon. - Thurs.: 8:00 a.m. – 12:00 p.m. and 1:00 p.m. – 5:00 p.m.
Fr: 8:00 a.m. – 3:00 p.m.
Hardware requirements
Update-Backup-Analysis FST-2XT FST-2XTs 7
2 Hardware requirements
›PC with MS Windows operating system
›Internet access
›Free USB port
›USB stick, max. 32 GB (with FAT32 le system)
2.1 Serial interface cable (null modem cable) for FST
The cable is required for the following programs:
›FST Editor
›Elevision Light
›Lon Modul Center
Technical data
1 2 3 4 5
6 7 8 9
1 2 3 4 5
6 7 8 9
Connections A and B - SUB-D socket to SUB-D socket
Pinning
Pin Conductor color
connection A
Conductor color
connectionB
AssignmentA-B
1 black orange 1-4
2 brown red 2-3
3 red brown 3-2
4 orange black 4-1
5 yellow yellow 5-5
6 - - not assigned
7 green blue 7-8
8 blue green 8-9
9 violet violet 9-9
socket black black S-S
Hardware requirements
8Update-Backup-Analysis FST-2XT FST-2XTs
3 Firmware
3.1 SavingrmwareupdateontheUSBstick
►Connect the USB stick to the PC.
Wait until the operating system has detected the USB stick as a removable disk.
►Create a new folder on the removable disk with the folder name update.
Payattentiontospellingandcapitalisation.Useonlylower-caseletters.
You must request the rmware update le from our service line in advance.
There are two ways to obtain the rmware update:
1. via E-mail
2. via Link NEW LIFT Cloud
►Save the rmware update le that you received in the newly created update folder on the USB stick.
At https://www.newlift.de/downloads-311.html you will nd the following relevant les for download:
›Information on version differences
FST-2XTchanges-customer-EN.pdf
›This document
hb_Update-Backup-Analysis_fst2XT_XTs_2020_09_en.pdf
DoNOTextractthelewiththe.tar extension into the update folder!
►Wait until the le has been completely stored in the update folder on the USB stick.
►Remove the USB stick from the PC.
Hardware requirements
Update-Backup-Analysis FST-2XT FST-2XTs 9
3.2 CopyingtheFSTrmwareupdatetotheFST-2XT
►Save existing conguration:
»Save the conguration le internally
„4.1 Saving / loading the conguration internally on the FST“ on page 11.
If necessary, also:
»Save the conguration le on the USB stick.
„4.2 Saving the conguration on the USB stick, loading from the USB stick“ on page 11
►Use the controller fuse to switch the control system OFF and ON.
►Set the Auxiliary Mode switch of the FST-2XT to ON.
►Plug the USB stick with the rmware update into port X41 of the FST-2XT.
The message USBStick OK appears briey on the screen.
►In the menu of the FST controller, call up MAIN MENU/System/Update FST.
This menu item is only displayed if the USB stick is plugged in.
►Select option Upd. f. USBStick.
►Select YES to start the update.
After a few seconds, the FST-2XT update screen appears.
The update may take up to 4 minutes.
Following a successful update, the message UPDATE COMPLETE appears briey on the screen.
If the update could not be completed successfully:
e.g., if the FST controller restarts immediately after briey displaying the update screen:
►Use the controller fuse to switch the control system OFF and ON.
►Repeat update procedure.
The FST-2XT restarts following a successful update.
►Check the software version by pressing the SHIFT + ENTER buttons.
The following information appears:
--- FST information ---
HW Vers. :XXX-XXX
SW Vers. :V2.000 - XXXX
:tt/mm/jjjj
Boot Ver. :X.X.X.XX
DRV Vers. :XXXX
If the displayed SW version or the DRV version does not match the current software version:
repeat the update process.
►Press the ENTER button to exit the menu item again.
Hardware requirements
10 Update-Backup-Analysis FST-2XT FST-2XTs
3.3 CopyingtheGSTrmwareupdatetotheGST-XT
►Plug the USB stick with the GST rmware update into port X12 of the GST-XT.
The message GST USBStick OK appears briey on the screen of the FST.
►Save existing conguration:
»In the menu of the FST controller, call up MAIN MENU/GST-Menu/Configuration/
GST-Config -> USB.
»Select YES.
The conguration data is stored on the USB stick in automatically created subdirectories. The
message: GST Config XFER OK! appears briey on the screen.
►Copying the GST rmware update to the GST-XT:
»In the menu of the FST controller, call up MAIN MENU/GST-Menu/Configuration/Update
GST f. USB.
»Select YES to start the update.
The message GST WAITING TO RESET
appears briefly on the screen.The entire update process of the GST rmware takes
approximately 50 seconds (25 seconds for the update and 25 seconds for the automatic restart of
the GST-XT).
During the update process, the LEDs of the GST-XT illuminate continuously in sequence.
Following a successful update, the message GST USBStick OK appears briey on the screen.
►Check the software version by pressing the SHIFT + ENTER buttons:
»Scroll the screen until the following information appears.
---GST Information ---
GST SW Vers. :V2.0X0 - XXXX
:tt/mm/jjjj
If the displayed SW version does not match the current software version:
repeat the update process.
►Press the ENTER button to exit the menu item again.
