New Air AI-250W Manual de usuario

AI-250W

50-Pound Portable

Ice Maker

OWNERS MANUAL

Read and save these instructions.

http://www.NewAir.com

A Name You Can Trust

Trust has to be earned and we will earn yours. Customer happiness is the

focus of our business.

From the factory to the warehouse, from the sales floor to your home, the

whole NewAir family promises to provide you with innovative products,

exceptional service, and support when you need it the most.

Count on NewAir.

As a proud NewAir owner, welcome to our family. There are no robots here,

real people shipped your product and real people are here to help you.

Thank you for your purchase and remember NewAir is A Name You Can

Trust.

Call us today at 855-963-9247

Or email support@newair.com

For future reference, we recommend you attach a copy of your sales receipt here and

record the following information. You will need this information if it becomes

necessary to contact the manufacturer for service inquiries.

Date of Purchase:

Serial Number:

Model Number:

Connect with us online.

A Name You Can Trust

READ AND SAVE THESE INSTRUCTIONS

TABLE OF CONTENTS

Table of Contents..........................................................................................................................3

Product Specifications......................................................................................................3

Important Safety Information.......................................................................................................4

For Your Safety................................................................................................................. 4

Getting to Know Your Ice Maker.................................................................................................7

Operating Procedures and Maintenance.................................................................................. 8

Unpacking Your Ice Maker.............................................................................................. 8

Connecting Your Ice Maker.............................................................................................8

Using Your Ice Maker.......................................................................................................8

Maintenance and Cleaning..........................................................................................................9

Electrical Schematic Diagram..................................................................................................... 9

Troubleshooting.......................................................................................................................... 10

Limited Manufacturer’s Warranty............................................................................................. 11

PRODUCT SPECIFICATIONS

Model No.:

AI-250W

Voltage:

110-120V

Frequency:

60Hz

Current:

2.25A

Refrigerant:

R134a

Net Weight:

21.6lbs

Dimensions:

13.58” x 15.75” x 13.7”

Certifications:

ETL

http://www.NewAir.com

IMPORTANT SAFETY INFORMATION

Please read the following instructions carefully before using this ice maker and keep this

user manual for future reference. Safety precautions shall be followed failure to obey

the safety precautions will result in possible harm to you and will void the

manufacturer’s warranty. In order to prevent any hazards, please follow all safety

precautions.

FOR YOUR SAFETY

WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY

PRECAUTIONS SHOULD BE FOLLOWED TO REDUCE THE RISK OF

FIRE, ELECTRIC SHOCK, AND INJURY TO PERSONS OR PROPERTY.

READ ALL INSTRUCTIONS BEFORE USING THIS ICE MAKER.

1. This appliance can be used by children that are eight years old and above and

persons with reduced physical, sensory, or mental capabilities, or lack of

experience and knowledge, if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning and user

maintenance shall not be done by children without supervision

2. Do not place hands or objects on or near the ice maker’s evaporator when it is in

operation.

3. Do not operate the appliance if the cord is damaged. If the supply cord is

damaged, it must be replaced by the manufacturer in order to avoid a hazard.

4. Connect the ice maker to proper outlets only. There should be no other appliance

plugged into the same outlet. Be sure that the plug is fully inserted into the

receptacle.

5. Do not run the cord over carpeting or other heat insulators. Do not cover the

cord. Keep the cord away from traffic areas and do not submerge in water.

6. Unplug the ice maker before cleaning or making repairs.

7. Exercise caution and use reasonable supervision when appliance is used near

children.

8. Do not clean your ice maker with flammable fluids. The fumes can create a fire

hazard or explosion.

9. Do not tip over.

A Name You Can Trust

10. If the ice maker is brought indoors from outdoors during the winter time, give it a

few hours to warm up to room temperature before plugging it in.

11. Fill with portable water only.

12. Do not store explosive substances, such as aerosol cans with a

flammable propellant, in this appliance.

13. This appliance is intended to be used in household and similar applications,

such as: Staff kitchen areas in shops, offices, and other working environments;

Farm houses and by clients in hotels, motels, and other residential type

environments; Bed and breakfast type environments; Catering and similar non-

retail applications.

14.Before using this product, place the machine on a platform.

15. Please keep the ice maker stewing 24 hours after receiving the machine.

16. Please make sure that the rear drain is firmly plugged before adding water to the

water tank.

17. The ice cube will be relatively small at first, but this is not a defect.

18. Do not use near hot objects or in dirty air.

19. Do not immerse the machine in water or use it in places where the machine may

be splashed in water or in the bathroom.

20. Do not dismantle or modify the machine.

21. Stop using the machine immediately when an exception or failure occurs.

22. Do not touch the ice making section of this product, and do not open the lid

when in use.

23. Please pull out the plug by holding the front insulation part of the plug, do not

pull the wire.

24. Please periodically clean the dust off the power head.

25. Do not plug the power plug when your hands are wet.

http://www.NewAir.com

26. Disconnect the power supply and drain out the remaining water from the rear

drain when the ice machine has not been used for a while.

27. The ice cubes of the first cycle may have an odor due to water quality. This is

not a defect. After several times, the smell will disappear. We suggest you use an

ice maker cleaning agent or citric acid to clean it before you use. Please do not

use the ice cubes with an odor to avoid physical discomfort or other diseases.

28. Do not damage the cooling circuit (the piping).

29. Do not damage the power cord and the power plug.

30. Do not use damaged power plugs or loose sockets.

31.Please don't repair or fix the broken power cord by oneself. Please contact the

after-sales service when the power cord is damaged.

A Name You Can Trust

GETTING TO KNOW YOUR ICE MAKER

1. Ice Scoop: To remove the ice.

2. Infrared Detecting Ice Full Transducer: The ice

wards off the infrared receiving and the display

panel would lit when the ice is full.

3. Ice Basket: Stores the ice.

4. Top Cover: With a transparent window to allow

interior visibility.

5. The Ventilation Mesh: The object must be more

than six inches away from anything to ensure the

smooth wind.

6. Water Drain Cap: To drain the water from the

tank.

7. Maximum Water Level: Add water below the ice basket.

8. Indication Light:

ON/OFF: The ice making time is five to eight minutes depending on the

ambient temperature.

RUN: Power on reminder.

ICE FULL: To remind you that the storage of the ice basket is full and to

remove the ice or turn it off immediately.

ADD WATER: To remind you to add water into the tank or check if the

waterway is in good condition.

http://www.NewAir.com

OPERATING PROCEDURES AND MAINTENANCE

UNPACKING YOUR ICE MAKER

1. Remove all exterior and interior packaging. Make sure that the ice basket and

ice scoop are included. If any part or accessory is missing, please contact our

customer service department.

2. Clean the interior with lukewarm water and a soft cloth. Remove the ice basket

and wash it in warm water.

3. Clean the evaporator rods using a water/vinegar solution.

4. Find a location for your ice maker that is protected from direct sunlight and you

will need six inches of space between the back and sides of your ice maker and

the wall.

CONNECTING YOUR ICE MAKER

Improper use of the grounded plug can result in the risk of electrical

shock. If the power cord is damaged, please call our customer service

department.

1. This unit should be properly grounded for your safety.

2. Plug the appliance directly into an appropriate 120V AC outlet that is properly

installed and grounded in accordance with all local codes and ordinances.

USING YOUR ICE MAKER

1. Press the “ON/OFF” button after plugging in the ice maker machine and it will

begin to run. Tip: You can use drinking water.

2. Open the cover, remove the ice basket and pour water into the tank, make sure it

does not surpass the maximum water level. Put the ice basket back into the

machine and close the lid. Tip: Keep the water below the ice basket.

3. While the ice maker is on, check the water level periodically. If the water pump

cannot inject water, the ice maker will stop automatically and the “WATER”

indicator will be on. Press the “ON/OFF” button, fill water up to the level mark

and press the “ON/OFF” button again.

A Name You Can Trust

4. The ice maker automatically stops working when the ice basket is full. The “ICE

FULL” indicator will lit when the ice bucket is full. To restart ice making, please

remove the ice and then press “ON/OFF”.

5. Change the water in the water reservoir every twenty- four hours to ensure a

reasonable hygiene level. If the unit is not in use for a few days, drain all the

water in the tank reservoir and refill before operating again.

6. Minimum water level is 1.5” and the max water level is 3”. The “ADD WATER”

indicator will lit when the water level is low. To restart, please add water and then

press “ON/OFF” button.

MAINTENANCE AND CLEANING

Before using your ice maker, it is strongly recommended that you clean it thoroughly.

1. Remove the ice basket.

2. Turn the drain cap to drain out the water.

3. Clean the interior with diluted detergent, warm water, and a soft cloth.

4. The outside of the ice maker should be cleaned regularly with a diluted detergent

and warm water.

5. Dry the interior and exterior with a soft cloth.

6. Close the drain cap.

7. When the machine is not in use, open the drain cap to drain water completely

from the water reservoir.

ELECTRICAL SCHEMATIC DIAGRAM

http://www.NewAir.com

TROUBLESHOOTING

Problem

Possible Causes

Solution

“ADD WATER” indicator

is on.

Water level is low.

Stop the ice maker, fill

water, and restart.

“ICE FULL” indicator is

on.

The ice basket is full.

The ice sensor is broken.

The ice scoop is stuck.

Remove the ice from the

basket.

Press “ON/OFF” to start the

ice maker forcibly or

sensor.

Check if ice is blocking the

ice shovel and remove the

ice.

Ice cubes stick together.

The ice making cycle is too

long.

The part of the evaporator

rods in the ice box is too

large.

The water temperature in

the inner tank is too low.

Stop the ice maker and

restart when the ice blocks

melt.

Change the water in the

reservoir. Use water

between 46oF and 89oF.

Ice is full but the light is

off.

The location of the ice

maker’s light is too strong

and it effects the infrared

detection.

Move the ice maker near a

darker location.

Ice making cycle is

normal but there is no

ice.

Ambient temperature or

water temperature is too

high.

Please operate the ice

maker below ambient

temperature of 89oF and

use cold water.

Refrigerant liquid leakage.

Contact customer service.

The pipe in the cooling

system is blocked.

Contact customer service.

Note: The noises are normal when operating this ice maker: a click sound when the

machine was turned on or off; a boiling, gurgling, or knocking sound when refrigerant is

circulating through the pipes; loud click sound when ice cubes are dropped into the

bucket.

Otros manuales para AI-250W

Tabla de contenidos

Otros manuales de Máquina de hielo de New Air

New Air

New Air NIM026MBN0 Manual de usuario

New Air

New Air AI-350S Manual de usuario

New Air

New Air AI-215 Series Manual de usuario

New Air

New Air AI-420SS Manual de usuario

New Air

New Air NCI080SS00 Manual de usuario

New Air

New Air AI-100R Manual de usuario

New Air

New Air NIM030SS00 Manual de usuario

New Air

New Air NIM026MS00 Manual de usuario

New Air

New Air AI-100BK Manual de usuario

New Air

New Air AI-150SS Manual de usuario

New Air

New Air AI-200 Series Manual de usuario

New Air

New Air AI-215SS Manual de usuario

New Air

New Air NIM026SSN0 Manual de usuario

New Air

New Air AI-250W Manual de usuario

New Air

New Air CLEARICE40 Manual de usuario

New Air

New Air AI-215SS Manual de usuario

New Air

New Air AI-215R Manual de usuario

New Air

New Air AI-500ss Manual de usuario

New Air

New Air AI-400 Series Manual de usuario

New Air

New Air AI-210 Series Manual de usuario

New Air

New Air AI-100 Series Manual de usuario

New Air

New Air AI-215 Series Manual de usuario

New Air

New Air AI-100 Series Manual de usuario

New Air

New Air NIM044BS00 Manual de usuario

Manuales populares de Máquina de hielo de otras marcas

Hoshizaki

Hoshizaki KMD-460MWJ Manual de usuario

Sub-Zero

Sub-Zero 315I Instrucciones de uso

Unold

Unold 48945 Manual de usuario

Kenmore

Kenmore 2217402A Manual de usuario

Cornelius

Cornelius WM600 Instrucciones de funcionamiento

GE XPIO43SCSS Manual de usuario

Hoshizaki

Hoshizaki KMD-901MAH Manual de usuario

Whynter

Whynter FIM-450HA Manual de usuario

U-Line

U-Line UMCR014-SC01A Manual de instalación

Andrew James

Andrew James AJ000522 Manual de usuario

Scotsman

Scotsman CME1356 Manual de usuario

Scotsman

Scotsman ACM 25 Manual de usuario

Kärcher

Kärcher IP 120 Manual de usuario

U-Line

U-Line SS1095 Manual de usuario

Maytag

Maytag MIM1554WRS - Ice Maker Manual de usuario

Hoshizaki

Hoshizaki KM-630MAH Manual de usuario

Princess

Princess Yonanas Manual de usuario

Unold

Unold 48946 Manual de usuario
