NetPing 995S2 Manual de usuario
[ENG] NetPing Supply Voltage Sensor 995S2, User
guide
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -
2
Содержание
[ENG] [995S2] Introduction......................................................................................... 4
[ENG] [995S2] Disclaimer and Copyright ................................................................... 5
[ENG] [995S2] Overview and Key Features ................................................................ 6
[ENG] [995S2] Connectors and Indication Elements................................................. 9
View from above................................................................................................................................. 9
Side view........................................................................................................................................... 10
The type of output contacts ............................................................................................................ 11
[ENG] [995S2] Installation and Connection ............................................................. 12
Connection Order............................................................................................................................. 12
Sensor Connection Diagrams.......................................................................................................... 13
NetPing 2/PWR-220 v3/ETH, NetPing 2 IP PDU ETH 53R14, NetPing 2 IP PDU GSM3G 203R15.................................... 13
UniPing server solution v3, UniPing server solution v4/SMS......................................................................................... 14
NetPing IO v2.................................................................................................................................................................... 15
NetPing 8/PWR-220 v4/SMS............................................................................................................................................. 16
[ENG] [995S2] Shipping Kit of the Device................................................................. 18
[ENG] [995S2] Warranty ............................................................................................ 19
[ENG] [995S2] Safety Precautions ............................................................................ 20
[ENG] [995S2] Operating and storage conditions.................................................... 21
[ENG] [995S2] Additional Documents and Links ..................................................... 22
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -
–
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Introduction
[ENG] [995S2] Introduction
–
[ENG] [995S2] Introduction
This guide will help you to get to know the features of the NetPing Supply Voltage Sensor 995S2, get an idea of its
functionality and technical specifications, and prepare the device for operation.
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Disclaimer and Copyright
[ENG] [995S2] Disclaimer and Copyright
–
[ENG] [995S2] Disclaimer and Copyright
The information, contained in this document, can be changed by a manufacturer without a prior notice.Although
every effort was made to make the information in this document accurate and without errors, a manufacturer is not
liable for their possible presence and for the consequences that may result from the errors herein. A manufacturer is
not liable if supplied equipment, software and this user guide does not correspond to expectations of a user and
his/her opinion about where and how to use all the above.All copyrights on supplied devices, described in this User
Guide, as well as firmware and software of devices and this User Guide belong to NetPing global Ltd. Сopying,
replication and translation of this user guide to other languagesare not allowed without a prior written permission
of a rightholder. Copying, replication, changing, disassembling of provided software are not allowed without a
prior written permission of a rightholder. For the part of software that is provided in source codes, there is a
separate license agreement, which defines an order of its use and modification. Other trademarks used in this
description belong to corresponding rightholders.
Developer and manufacturer:
NetPing east Co Ltd.
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Overview and Key Features
[ENG] [995S2] Overview and Key Features
–
[ENG] [995S2] Overview and Key Features
The physical configuration of the device is shown in the photo:
Bottom view:
View from above:
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Overview and Key Features
[ENG] [995S2] Overview and Key Features
–
Device specifications Meaning
Threshold response (valid only for
995S2modification, intended for 220 V
network)
178–193 V
Threshold release (valid only for
995S2modification,intended for 220 V
network)
155–175 V
Supply voltage required for the correct
operation of internal components and
maintain operability
70–250 В50/60 Hz
Overvoltage impulses up to 350 V for a duration of 50 ms, not more than 2 times per
minute
Number of network voltage measuring
channels
1 pc.
Operating Temperature Range -30 ° С... +50 ° С(without moisture condensation, normal
humidity)
The type of output/condition of the contacts Аdry contact, switching (N.C. and N.O. contacts), voltage up to
24 V, current up to 0.5 A
The case/the degree of case protection plastic/IP20
Indication available
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Overview and Key Features
[ENG] [995S2] Overview and Key Features
–
Device specifications Meaning
Weight 101 gram
Device dimentions 89 х50 х31
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Connectors and Indication Elements
[ENG] [995S2] Connectors and Indication Elements
–
[ENG] [995S2] Connectors and Indication Elements
View from above
The sensor operation indicator is on when it is connected to the power supply.
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Connectors and Indication Elements
[ENG] [995S2] Connectors and Indication Elements
–
Side view
