ProSafe® Quad WAN Gigabit

SSL VPN Firewall Data Sheet

SRX5308

Ultra High Performance Business-class Firewall Security

The ﬂagship model of the ProSafe ﬁrewall family — the SRX5308 is perfect for even the most

demanding business networks. The SRX5308 features a hardware-accelerated data ﬂow

architecture that allows for 1 Gbps of stateful ﬁrewall throughput. This powerful VPN router

is a high-performance, SNMP-manageable, network solution that furnishes multidimensional

security including denial-of-service (DoS) protection, stateful packet inspection (SPI), URL

keyword ﬁltering, conﬁgurable hardware DMZ port, logging, reporting, and real-time

alerts. QoS, WAN trafﬁc metering, and bandwidth proﬁling gives you granular bandwidth

management capabilities. VLAN support allows you to separate guest trafﬁc from critical

production servers. Four Gigabit LAN ports allows for maximum internal data transfer speeds,

while the four Gigabit WAN ports provide two modes of session-based load-balancing as well

as failover protection to ensure maximum throughput and reliable connectivity to the Internet.

VPNC

CERTIFIED

Basic

Interop

AES

Interop

FEATURES AND BENEFITS

LAN-to-WAN Throughput¹ • Hardware-accelerated 1Gbps LAN-to-WAN ﬁrewall throughput

• 200,000 concurrent connections

Secure Firewall • DoS attack protection

• Block TCP/UDP packet ﬂoods

• Port/service blocking

• Hardware DMZ port

• Web content ﬁlter

Quad Gigabit WAN Ports • 2 modes of session-based WAN load balancing

• WAN failover for maximum uptime

VLAN Support • Create up to 254 individual 802.1Q VLANs

• Allows for secure network segmentation

• Separate guest trafﬁc from critical production servers

SSL and IPsec VPN Remote Access • SSL VPN – clientless remote access, anywhere, anytime

• IPsec VPN – secure site-to-site tunnels and client-based remote access

• Industry-strength encryption algorithms

• IKE authentication protects against unauthorized remote access

• 125 simultaneous IPsec VPN tunnels

• 50 simultaneous SSL VPN tunnels

Bandwidth Management • Control end user bandwidth consumption with Bandwidth Proﬁles

• Prioritize trafﬁc with Quality of Service (QoS)

• WAN Trafﬁc Metering

Easy to Use • Auto Detect connects to your ISP quickly

• DHCP (client and server) for fast deployment

• Intuitive Web management GUI

• IPsec VPN Wizard allows for easy VPN setup

• SNMP, telnet management support

• SYSLOG and emailed logs enable thorough network monitoring

Reliable NETGEAR Hardware • Industry-grade metal casing

• High-quality electronics

• NETGEAR Lifetime Warranty

ProSafe® Quad WAN Gigabit SSL VPN Firewall SRX5308

PC with GA311

Servers

SRX5308

ProSafe Quad WAN Gigabit

SSL VPN Firewall

SRX5308

ProSafe Quad WAN Gigabit

SSL VPN Firewall

Broadband

modems

VPN Tunnel

encrypts your data

Internet

Broadband

modems

PDA with Web browser

Telecommuter connects with

ProSafe VPN Client Software

(VPN01L or VPN05L)

240-10041-01

240-10129-01

NMS100 ProSafe Network Management System

Everybody’s connecting.

™

Instructions:

This CD should automatically

run when inserted into your

CD-ROM drive. If the CD

does not start automatically,

browse to the CD drive and

click on NMSsetup.exe

Software CD

Version 1.0

Desktop PCs connect with

10/100/1000 Mbps Gigabit

Ethernet PCI Adapter (GA311)

WNDAP350

ProSafe Dual Band

Wireless-N Access Point

Laptop with SSL VPN

Remote Access

via Kiosk or Laptop

Gigabit Ethernet

Fast Ethernet

Desktop PCs connect with

10/100/1000 Mbps Gigabit

Ethernet PCI Adapter (GA311)

GSM7224-200

ProSafe 24-port Gigabit

Managed Switch

STM300

ProSecure Web and Email

Security Appliance

STM150

ProSecure Secure Threat

Management Appliance

GS724TPS

ProSafe 24-port Gigabit

Stackable PoE Smart Switch

TECHNICAL SPECIFICATIONS

PERFORMANCE

LAN-to-WAN Throughput¹ 924 Mbps

IPsec VPN (3DES) Throughput¹ 180 Mbps

SSL VPN Throughput¹ 21 Mbps

Maximum Concurrent Connections 200,000

Maximum Number of VLANs 254

Dedicated IPsec VPN Tunnels 125

Dedicated SSL VPN Tunnels 50

FIREWALL FEATURES

Stateful Packet Inspection (SPI) Port/Service Blocking, Denial-of-service (DoS) Prevention, Stealth Mode, Block TCP Flood, Block UDP Flood,

WAN/LAN Ping Response Control

Firewall Functions Port Range Forwarding, Port Triggering, DNS proxy, MAC Address Cloning/spooﬁng, NTP Support, UPnP, Auto-

Uplink on Switch Ports, L3 Quality of Service (QoS),LAN-to-WAN and WAN-to-LAN(ToS), Bandwidth Proﬁling

Content Filtering Web Components (Proxy, Java, ActiveX, Cookies), Web Keyword Blocking, Trusted Domains

User Authentication for VPN Active Directory, LDAP, Radius, WIKID, MIAS, NT Domain, Local User Database

PCI Compliance Two Factor

Authentication Support •

VoIP SIP ALG Compatibility List Linksys SPA-901, Linksys SPA-941, SNOM M3, Cisco 7940G, X-Lite 3.0 (software for phones),

D-Link DPH-140S, Grandstream GXP-2000, Polycom SoundStation 6000, Siemens C450, Aastra 51i

VPN Pass Through IPsec, PPTP, L2TP

FIREWALL FEATURES

WAN Modes NAT, Classical Routing

ISP Address Assignment DHCP, Static IP Assignment, PPPoE, PPTP

NAT Modes 1-1, NAT, PAT

Routing Static, Dynamic, RIPv1, RIPv2

DHCP DHCP Server, DHCP Relay

DDNS DynDNS.org, TZO.com, Oray.net, 3322.org

VLANs 802.1Q

Quad-WAN Fail-over •

WAN Load Balancing Modes Weighted Load Balancing, Round Robin

VPN

IPsec Encryption/Authentication 56-bit DES, 168-bit 3DES, AES(128, 192, 256 bit)/SHA-1, MD5

Key Exchange IKE, Manual Key, Pre-shared Key, PKI, X.509 v3

IPsec NAT Traversal (VPN Passthrough) •

IPsec Access Modes Client-to-site, Site-to-site

IPsec VPN Wizard •

350 E. Plumeria Drive

San Jose, CA 95134-1911 USA

1-888-NETGEAR (638-4327)

E-mail: [email protected]

www.NETGEAR.com

PowerShift, ProSafe, ProSecure, RAIDar, RAIDiator, X-RAID, RangeMax, ReadyNAS and Smart Wizard are trademarks of NETGEAR, Inc. in

the United States and/or other countries. Mac and the Mac logo are trademarks of Apple Inc., registered in the U.S. and other countries.

Other brand names mentioned herein are for identiﬁcation purposes only and may be trademarks of their respective holder(s). Information

*Basic technical support provided for 90 days from date of purchase.

¹Throughput measured in a lab environment. Actual performance may vary.

D-SRX5308-0

ProSafe® Quad WAN Gigabit SSL VPN Firewall SRX5308

TECHNICAL SPECIFICATIONS

VPN

SSL Version Support SSLv3, TLS1.0

SSL Encryption Support DES, 3DES, ARC4, AES(ECB, CBC, XCBC, CNTR)128, 256 bit

SSL Message Integrity MD5, SHA-1, MAC-MD5/SHA-1, HMAC-MD5/SHA-1

SSL Certiﬁcate Support RSA, Difﬁe-Hellman, Self

SSL VPN Platforms Supported Windows 2000/XP/Vista/Windows 7 (32, 64 bit), MAC OS X 10.4+

MANAGEMENT

Management Interface Options HTTP/HTTPS, SNMP v2c, Telnet

Logging Accepted Packets, Dropped Packets, System, Source MAC ﬁlter, Session Limit, Bandwidth Limit, SSl VPN, IPsec VPN

Log Delivery Email Delivery, Syslog

Diagnostics Ping, DNS Lookup, Trace Route

Maintenance Save/restore Conﬁguration, Restore to Factory Defaults, Firmware Upgrades via Web Browser, Display Statistics

HARDWARE

Gigabit RJ45 Ports WAN/LAN 4/4

DMZ Interfaces (Conﬁgurable) 1

Flash Memory/RAM 64 MB/512 MB

Certiﬁcations VPNC (Basic, AES Interop)

Major Regulatory Compliance Environment: RoHS, China RoHS Safety: CE/LVD, cUL EMI: FCC

Part 15 Class A, CE mark commercial, C-Tick Class A, VCCI

Storage and Operating Temperatures Operating Temperature: 0˚ - 45˚C (32˚-113˚ F)

Storage Temperature: -20˚ – 70˚ C (-4˚ – 158˚ F)

Humidity Operation 90% Maximum Relative, Storage 95% Maximum Relative

Electrical Speciﬁcations AC 100-240V, 50/60 Hz Universal Input, DC 5V/5A Output Internal Power Supply

Dimensions (W x H x D) cm 33 x 4.3 x 20.9

Dimensions (W x H x D) in 13 x 1.7 x 8.2

Weight kg/lb 2.1/4.6

System Requirements Cable, DSL, or Wireless Broadband Modem, Internet Service, Network Card for Each Connected PC,

Network Software (e.g. Windows), Internet Explorer 5.0 or Higher or Mozilla Firefox 1.0 or Higher

Package Contents ProSafe Quad WAN Gigabit Firewall (SRX5308), Ethernet Cable, Power Cable, Rackmount Kit, Rubber

Feet, Installation Guide, Warranty/Support Information Card, Resource CD With Single User ProSafe

VPN Client Software License

Warranty Lifetime

ORDERING INFORMATION

North America SRX5308-100NAS

Europe SRX5308-100EUS

Asia SRX5308-100AJS

ACCESSORIES

ProSafe Client Software VPN01L (1-User), VPN05L (5-User)

ProSafe Network Management Software NMS100

PROSUPPORT SERVICE PACKS

OnCall 24x7, Category 1 PMB0331-100 (US), PMB0331 (non-US)

XPressHW, Category 1 PRR0331
