NETGEAR XET1001 - Powerline Network Adapter Manual de usuario

)NSTALLATION'UIDE

XET1001 85 Mbps Wall-Plugged Ethernet Adapter

3

12

6

45

May 2008

Safety Warning: The socket-outlet shall be installed near the equipment and shall be easily accessible.

This symbol was placed in accordance with the European Union Directive 2002/96 on the

Waste Electrical and Electronic Equipment (the WEEE Directive). If disposed of within the

European Union, this product should be treated and recycled in accordance with the laws of

your jurisdiction implementing the WEEE Directive.

© 2008 by NETGEAR, Inc. All rights reserved. NETGEAR and the NETGEAR logo are registered

trademarks of NETGEAR, Inc. in the United States and/or other countries. Other brand and product

names are trademarks or registered trademarks of their respective holders. Information is subject to

change without notice.

LEDs and Ethernet Port

To set the security on your Powerline adapters, see the User Manual, located on your

XET1001 Resource CD.

LED Description

Power • Solid. The electrical power is on.

•Off. There is no electrical power.

Powerline • Solid. The adapter is connected to a Powerline network.

•Blinking. The adapter is sending or receiving data.

•Off. The adapter has not found any other compatible Powerline devices

using the same encryption key.

Ethernet • Solid. The Ethernet port is linked, but there is no activity.

•Blinking. There is traffic between an Ethernet port and the Powerline

network.

•Off. There is no Ethernet connection.

Powerline

Ethernet

Power

Ethernet port

LED

LED

LED

Troubleshooting Tips

Technical Support

Thank you for selecting NETGEAR products. After completing installation, register your

product at http://www.NETGEAR.com/register.

Registration on the website or over the phone is required before you can use our telephone

support service. The phone numbers for worldwide regional customer support centers are on

the Warranty and Support Information card that came with your product.

Go to http://www.NETGEAR.com/support for product updates and Web support.

Power LED is off. Make sure that power is supplied to the electrical outlet, and that the

Powerline devices is not plugged into an extension cord, power strip,

or surge protector.

Powerline LED is

off. • Make sure that the Powerline devices are plugged into outlets with

power.

• Move the Powerline device to a closer location.

• If you have set network security, make sure that all Powerline

devices are using the same encryption key.

• Reset the devices to factory default settings. Refer to the User

Manual for instructions.

Ethernet LED is

not blinking. • Make sure that your router and modem are on and working correctly.

• Make sure that the Ethernet cables are working and securely

plugged into the devices.

• Reset the devices to factory default settings. Refer to the User

Manual for instructions.
