POE101

Power Over Ethernet Adapters

Connectivity, Power, Ethernet – Right Where You

Need It

Get power for your NETGEAR 802.11b Access Point where you need it! NETGEAR's

Power Over Ethernet Adapters make it easy for you to extend the reach of your wireless

local network. They provide an ideal way to locate an access point in a building ceiling

or attic for optimal radio coverage – closer to an antenna – without requiring a nearby

AC power outlet. Consisting of a base unit and a terminal unit, this useful set of

adapters can extend the placement of a wireless access point by up to 328 feet (100

meters) using standard Category 5 Ethernet cable. At the same time, the adapters

protect the access point or other device from potential power surge damage.

Gives you the freedom to mount your wireless access points or other devices virtually

anywhere inside your building, including areas where you may not have power and/or

Ethernet access, so you can make the most of your wireless or Ethernet network. Supports

distances up to 328 feet.

Reduces signal loss through an antenna cable and eliminates the threat of power surge damage

to your connected devices.

Thorough testing ensures quality and dependable operability, which NETGEAR backs up

with a 2-year warranty.

Far-Reaching

Protective

Unfailing

Everybody’s Connecting.

™

• Help is there when you need it!

NETGEAR provides 24x7

telephone and e-mail technical

support in English, with selected

local language support during

office hours.

Desktop PCs

Cable/DSL

Modem

24 volt

power supply

Cable/DSL

Web Safe

Router RP614

ME102 802.11b

Wireless Access Point

POE101

Terminal unit

POE101

Base unit

Internet

NETGEAR

4500 Great America Parkway

Santa Clara, CA 95054 USA

Phone: 1-888-NETGEAR

E-mail: [email protected]

www.NETGEAR.com

Netgear Logo, the Gear Guy, and

Everybody’s connecting are trademarks or

registered trademark of Netgear, Inc. in

the United States and/or other countries.

Microsoft, Windows, and the Windows

logo are trademarks, or registered trade-

marks of Microsoft Corporation in the

United States and/or other countries.

Other brand and product names are

trademarks or registered trademarks of

their respective holders. Information is

subject to change without notice. All

rights reserved.

D-POE101-0

System Requirements

-Two straight through Ethernet cables, not included

with the NETGEAR POE101:

•One short cable from an Ethernet hub or

switch to the POE101 base unit

•One long cable (up to 328 feet) for connecting

from base unit to a terminal unit

-One 5V DC powered NETGEAR Access Point

(one set of POE101 Adapters per Access Point

is required)

Package Contents

-Power over Ethernet base unit

-Power over Ethernet terminal unit

-Installation guide

-Localized AC power cable

-100~240 V AC to 24V DC 30W power adapter

-Two 2-foot DC power cables

-One 2-foot Ethernet cable

-Wall mount kit

-Warranty card

-Support information card

Related Products

-ME102 802.11b Wireless Access Point

Technical Specifications

•POE Base unit:

-Power input: 24V DC

-10/100 Mb LAN IN

-10/100 Mb LAN OUT with 24V DC power

•POE Terminal unit:

-Power output: 5V DC 2.5A max.

-10/100 Mb LAN IN with 24V DC power

-10/100 Mb LAN OUT

•AC power adapter:

-Input: 100~240V AC 0.85A 50~60 Hz

-Output: 24V DC 1.5A

•Cables:

-Ethernet cable with RJ-45 connectors for terminal

to access point

-DC power cable for terminal unit to NETGEAR

ME102 (North American version)

-DC power cable for terminal unit to all other

NETGEAR 5V DC powered devices

-Localized AC power cable for wall to power adapter

•Physical Dimensions:

-Base and Terminal units: 3-1/8" (8.0 cm) x

3-1/16" (7.8 cm) x 13/16" (5.0 cm)

-Power adapter: 3-3/4" (9.6 cm) x 1-5/8"

(4.15 cm) x 1-1/8" (2.9 cm)

•Weight:

-Base unit: 2.4 oz (68 grams)

-Terminal unit: 2.7 oz (76 grams)

-Power adapter: 5.4 oz (153 grams)

•Warranty:

-2 year limited warranty (GE)

-1 year limited warranty (NA)
