NetComm V220

Two Phone port VoIP Adaptor

V220 VoIP technology

NetComm’s V220 VoIP Telephone Adaptor has been

designed for residential and small business users to deliver

predictable real-time voice quality over the Internet. It

connects directly to any broadband modem and service

(Cable or DSL) plus an account with a VoIP Service Provider.

A standard analogue telephone (desktop or cordless) is

connected to the FXS (Phone) ports on the back of the V220,

allowing the user to route calls over the Internet to anywhere

in the world using VoIP, signiﬁcantly reducing or even

eliminating long distance call charges.

KEY FEATURES

Make and receive VoIP calls from two telephone handsets

Two FXS (Phone) telephone ports and 1 LAN port

Simple web-based setup and conﬁguration

Supports advanced Call services – Caller ID, Call On-Hold, Call Forward,

Call Waiting and Transfer – service provider dependent*

*Note: The availability of some listed call features are dependent on the service supported by your VoIP service provider. Please consult them for further information.

NETCOMM LIMITED ABN 85 002 490 486 PO Box 1200, Lane Cove NSW 2066 Australia

P: 02 9424 2070 F: 02 9424 2010 E: [email protected] W: www.netcomm.com.au

Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Speciﬁcations are

subject to change without notice. Images shown may vary slightly from the actual product.

NetComm V220

Two Phone port VoIP Adaptor

TECHNICAL SPECIFICATIONS

NETWORK PROTOCOL

• SIP v1 (RFC2543), v2(RFC3261)

• IP/TCP/UDP/RTP/RTCP

• IP/ICMP/ARP/RARP/SNTP

• TFTP Client/DHCP

• Client/ PPPoE Client

• HTTP Server

• DNS Client

• NAT/DHCP Server

TONE

• Ring Tone

• Ring Back Tone

• Dial Tone

• Busy Tone

• Programming Tone

CODEC

• G.711: 64k bit/s (PCM)

• G.723.1: 6.3k / 5.3k bit/s

• G.726: 16k / 24k / 32k / 40k bit/s (ADPCM)

• G.729A: 8k bit/s (CS-ACELP)

• G.729B: adds VAD & CNG to G.729

PHONE FUNCTION

• Volume Adjustment

• Speed dial key

• Phone book

• Flash

VOICE QUALITY

• VAD: Voice activity detection

• CNG: Comfortable noise generator

• LEC: Line echo canceller

• Packet Loss Compensation

• Adaptive Jitter Buffer

IP ASSIGNMENT

• Static IP

• DHCP

• PPPoE

CALL FUNCTION

• Call Hold

• Call Waiting

• Call Forward

• Caller ID

• 3-way conference

SECURITY

• HTTP 1.1 basic/digest authentication for Web setup

• MD5 for SIP authentication (RFC2069/RFC 2617)

DTMF FUNCTION

• In-Band DTMF

• Out-of Band DTMF

• SIP Info

NAT TRAVERSAL

• STUN

SIP SERVER

• Registrar Server

• Outbound Proxy

CONFIGURATION

• Web Browser

• IVR/Keypad

FIRMWARE UPGRADE

• TFTP

• HTTP

AUTO PROVISIONING

• HTTP

• FTP

• TFTP

MODEM & FAX MODES

• G.711 fax/modem pass-through with fax/modem detection

• T.38 support

INTERFACE

• 1 WAN port interface

• 1 LAN port interface

• 2 VOIP port interface (FXS)

Internet

ADSL Modem

PC connected

to LAN port

Phone Connected

to Phone 2 Port

Phone Connected

to Phone 1 Port

V220

Typical ADSL ConﬁgurationADSL Conﬁguration
