NetApp H410S Manual
215-14249_A0
NetApp H-series Element storage nodes
Installation and Setup Instructions
Prepare for installation |Stage 1
Access online
You provide
In the box
Configure
the node
4
Create a
new cluster
5
Prepare
for installation
Install
hardware
Cable
the node
1 2 3
Power cables
(Two per chassis)
Rack space (order dependent)
H410S: 2U per chassis
H610S: 1U per chassis
Monitor with a
VGA connection
and keyboard with
a standard USB
connection
SFP28/SFP+
direct-attach cables
or transceivers
Any operating
system (OS) client
with a browser
H610S storage node
(order dependent)
• End User License Agreement
• Hardware Universe (HWU)
• NetApp HCI Documentation Center
• NetApp HCI Resources page
• NetApp SolidFire Resources page
• SolidFire and Element 11.3 Documentation Center
Slide rail kit
Chassis
(for H410S nodes)
HCI
UID
UID
UID
UID
NODE D
NODE D
NODE C
NODE C
NODE A
NODE A
NODE B
NODE B
A0 A1 A2 A3 A4 A5 B0 B1 B2 B3 B4 B5 C0 C1 C2 C3 C4 C5 D0 D1 D2 D3 D4 D5
USB stick (optional)
H410S storage nodes: Optional,
for out-of-band management
H610S: Required for out-of-band
management and cluster management
CAT5e or higher cable
with RJ45 connector
H410S storage node
(order dependent)
Steps 3 and 4 do not apply if you are installing H610S nodes.
1Install the rails.
2
3
4
Install the chassis.
See Rail Kit Installation instructions.
Note:
• Ensure that you have installed the rack according to the safety instructions from the manufacturer.
• Ensure that the rack is stabilized. The heaviest equipment should be at the bottom of the rack.
• Follow proper grounding practices to avoid risk of electric shock.
• Follow proper airflow and cooling requirements to prevent hardware from overheating.
• Installing the chassis requires two people.
Install hardware |Stage 2
An H410S cluster requires a minimum for four nodes in a chassis. If you are expanding
your existing installation, you need a minimum of one node and one chassis.
Steps 1 and 2 do not apply if you are adding a new node to an existing two rack unit (2U), four-node chassis.
Install nodes in the chassis.
Install drives for storage nodes.
CHASSIS BACK VIEW
Node A
Node B
Node C
Node D
Node B Node C Node DNode A
SSD -E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
S
SD-
E
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1
.9 T
B
1. 9 T B
CHASSIS FRONT VIEW
H410S
LIFTING HAZARD
CAUTION
40.5 lb (18.4 kg)
H610S
LIFTING HAZARD
CAUTION
Approximately
70 lb (31.75 kg)
The installation graphic
is only for illustrative
purposes. Your actual
node might dier based
on what you ordered.
Connect the node to a 1GbE network using
two RJ45 connectors.
Connect the node to a 10/25GbE network using
two SFP28 or SFP+ cables.
Connect the node to a 1GbE network using an
RJ45 connector in the IPMI port.
Connect both power cables to the node.
Plug the power cables to a suitable power
outlet. Press the power button at the front of
the chassis.
Note: It takes approximately five minutes and 30 seconds
for the node to boot.
10/25GbE cables
1GbE cables
1GbE cable
Power cables
FRONT
VIEW
REAR
VIEW
10/25GbE SFP+
or SFP28 cables
for iSCSI
1GbE RJ45 cable
for out-of-band
management
1GbE RJ45 cables
for management
H610S storage node
If the airflow vents at the rear of the chassis are blocked by cables or labels, it can lead to premature
component failures due to overheating.
1Cable the node
If you are adding nodes to an existing installation, ensure that the cabling and network
configuration of the nodes that you add are identical to the existing installation.
Cable the node |Stage 3
Connect two CAT5e or higher cables in ports
A and B for management connectivity.
Connect two SFP28/SFP+ cables or transceivers
in ports C and D for storage connectivity.
(Optional, recommended)
Connect a CAT5e cable in the IPMI port for
out-of-band management connectivity.
10/25GbE cables
1/10GbE cables
Port D IPMI
Port CPort A
Port B
H410S storage node
Cable the node |Stage 3 cont.
2Connect the power cords to the two power supply units
per chassis and plug them into 240V PDU or power outlet.
This step does not apply if you are adding a new node to an existing chassis.
3Power on the nodes. FRONT VIEW
HCI
UID
UID
UID
UID
NODE D
NODE D
NODE C
NODE C
NODE A
NODE A
NODE B
NODE B
A0 A1 A2 A3 A4 A5 B0 B1 B2 B3 B4 B5 C0 C1 C2 C3 C4 C5 D0 D1 D2 D3 D4 D5
UID
UID
NODE A
NODE A
NODE B
NODE B
A0 A1 A2 A3 A4 A5 B0 B1 B2 B3 B4 B5 C0 C1 C2 C3
It takes approximately six minutes for the node to boot.
Steps 2 and 3 do not apply if you are installing H610S nodes.
Configure the node |Stage 4
Required only for H610S nodes.
Attach a keyboard and monitor
to the node.
Note: Ensure that the node is powered on.
In the terminal user interface (TUI) that is
displayed, configure the network and cluster settings
for the node by using the on-screen navigation.
Note: You must get the IP address of the node from the TUI. You need this in Stage 5.
After you save the settings, the node is in a pending state, and can be added to a cluster.
See the NetApp Element Software Setup Guide for configuration instructions. You can
access the latest version of the Setup Guide from the NetApp SolidFire Resources page.
Configure out-of-band management using the
Baseboard Management Controller (BMC).
i. Use a web browser and navigate to the default BMC IP address: 192.168.0.120
ii Log in using the following default credentials: User name: root Password: calvin
iii From the node management screen, navigate to Settings > Network Settings, and
configure the network parameters for the out-of-band management port.
See How to access BMC and change IP address on H610S.
1
2
3
Create a new cluster |Stage 5
HCI
UID
UID
NODE D
NODE D
NODE C
NODE C
D2 D3 D4 D5
1
2
From a client on the same network as the newly
configured node, access the NetApp Element
software UI by entering the node’s IP address.
Enter the required information in the Create a New Cluster window.
See the NetApp Element Software Setup Guide for instructions. You can access the latest version
of the Setup Guide from the NetApp SolidFire Resources page.
